Illuston FLOW'8 Quick Manual

FLOW`8
http://www.illuston.com
Complete your own music with
beautiful illustrations on your tone.
That's the reason behind
Quality components, handy features, sturdy build,
and most importantly, beautiful sound.
True-Stereo processing
Wide dynamic range up to +4㏈u
True-Bypass or Buffer-Bypass with Trails Mode
Expression/Tap pedal connection
8 types of effect model for the perfection
Saving your tone up to 8 presets
- There's no sound. Check cable connections. Your instrument should be connected to the input on the
right side of the pedal, while the amplifier/sound system should be connected to the
output on the left. Check to see if the output level of your instrument is adequately
high. Alternatively, the battery may be out of power.
- Unintended distortion is heard. In case you connect an instrument with a high gain (such as a synthesizer), It can
surpass the maximum input level of +4㏈u resulting in distortion. Please adjust the
instrument's output to an adequate level. This may be caused by the depleted battery.
- Problems with an external power. The pedal needs to be used with a power adapter that outputs constant 9V DC and
can handle at least 150㎃ of current. The polarity of the power jack is center-negative
and the power adapter must be corresponding.
Please note that while the power jack is connected, the battery is cut off and not used.
- Problems with a battery. When powered with a battery, the unit will function only when a mono connector is
plugged into the
Power will drawn from the battery as long as the input jack is engaged, even if you are
not playing any music. You can also check the battery to make sure it is not exhausted.
- LED blinks. This signals a voltage drop in the battery as it reaches the end of its life.
This means that it's about time to change the battery.
Please insert a fresh battery or use an external power source.
- None of these works, help me! Please reach out to customer service at
- Input/Output ¼" Phone Jacks - Stereo (2-Channel) Audio Input/Output and Expression/Tap Input
- Input Impedance 1MΩ
- Output Impedance 600Ω
- Signal-Noise Ratio 85㏈A typical working
- Frequency Response 20㎐ ~ 20k㎐
- Max Input Level +4㏈u
- A/D & D/A 24-bit / 48k㎐
- DSP arithmetic 32-bit processing
- Bypass Switching True-Bypass or Buffer-Bypass with Trails Mode (Selectable)
- Dimensions Width 124㎜ x Depth 104㎜ x Height 38㎜
- Weight 560g (not including battery)
- Output Type 9V DC / 150㎃ / Center Negative
- Current Draw 70㎃
- Battery 9V (6LR61/6F22/FC-1)
- Battery Life approx. 4 hours (with Alkaline Battery)
on the right side of the pedal.
.
