teachscape MINI CAMERA KIT Quick Start Manual

Advertisement

Quick Links

YOUR KIT CONSISTS OF:

• Tripod
• Microphone
• Wide-angle lens
• Camera Clip
Note: If your camera device does not have a
microphone input, you will not be able to use
the microphone.
MINI CAMERA KIT

SET UP TRIPOD

1
The tripod base and extension pole
come preassembled. Your kit includes
a camera clip and a wide-angle lens.
Screw the camera clip onto the tripod.
SET UP
2
MICROPHONE
The microphone components
consist of a microphone with an
adjustable gooseneck, a windscreen,
a microphone base, and an audio
cable.
SET UP
3
WIDE-ANGLE LENS
Pull off Mobi-Lens protective cap.
(Mobi-Lens protective caps are
NOT twist-off)

SET UP CAMERA

4
Insert your camera into the
camera clip by inserting it up
and into the clip.

QUICK START GUIDE

Tripod
Mobi-Lens
Wide Angle
Camera Clip
Insert the included alkaline battery into
the microphone base.
Then, plug the neck of the microphone
and the audio cable into the microphone
base.
Press the power button on the base.
The LED light will indicate if the
microphone is on.
Remove secure lens backing. (Do not
discard lens backing as it protects the
Mobi-Lens when it is not in use)
Position Wide Angle Mobi-Lens with your
device camera eye, making sure that
Mobi-Lens is aligned and centered with
the camera eye.
Insert the 3.5mm plug on your
audio cable into the microphone
input of your camera device.
VERSION 3.0
To make the base more stable, loosen
the ring on the tripod base and extend
the legs.
Microphone
Neck
Audio Cable
