Inalsa Gloria Use & Care Manual page 2

Part's Identifications
9
3
6
7
1
2
8 4
Part No. Part Name
1. Main body
2. Bottom
3. Juicer cover
4. Switch housing
5. Switch buttons
6. Swing locks
7. Spout cover
8. Bottom pad
9. Food pusher
Technical Specification*
Voltage 230V, 50Hz AC
Wattage 450W
Cord plug 2 Core PVC cord with 2 Pin, 6A, 250V plug
Speed control Piano, type two speed control with pulse
*Due to continuous improvements in product, specifications are subject to
change without prior notice.
Important
Do's
1. Before conn ecting the appliance make sure that the mains voltage complies
with the voltage specified.
2. Clear out some space around the machine and keep juicer mixer grinder
away from direct heat and sun.
3. Before operating the juicer ensure that the mesh assembly is properly
seated.
4. Ensure that the juicer cover is properly clamped to the juicer body.
5. Use 1st speed for juicing.
Don'ts
1. Do not use fruits such as bananas & peaches that produce a thick paste that
can clog the juicer mesh.
2. For extracting the juice from citrus fruits like orange, mousmi etc. it is
advisable not to use the food pusher so that seeds pop out automatically.
For best results, it is advised to cut the fruits into two halves and remove
seeds before extracting the juice.
3. Do not feed large sized fruits into the feeder tube by force. This can overload
the motor and juicer mesh may get unbalanced.
4. Do not overload the motor.
5. Never lay a thin plastic sheet or cloth under the basic unit. It may get sucked
up and block the ventilation holes in the base.
6. Do not use any metal object, like knife etc. to clean juicer mesh as it may get
damaged.
7. Do not push fruits into the feeder tube by fingers while it is in operation. If
fruit become clogged in the feeder tube, use pusher to push it down. If it
doesn't work, turn off the motor, unplug the unit, then disassemble the juice
to remove remaining food.
8. The filter mesh is very fine, precisely balanced component and it should not
be subjected to any undue pressure.
9. Do not attempt to repair the juicer at home or allow any unauthorized person
to do it either, in the event of juicer mixer grinder needing attention take it to
the nearest service centre.
Before First Use
1. After unpacking the unit and before any use, make sure the mechanical
parts of the unit and all its attachments are not damaged.
2. Before first use wash the parts of the appliance which comes into contact
with the food material multiple times with warm and soapy water, especially
both the jars by pouring the warm soapy water into the jar followed by
closing the lid and running the main unit at first speed.
How to Use
Juicing
1. Take the main unit and put juicer body (18) on the main unit.
5
Part No. Part Name
10. Blender jar
11. Blender jar lid
12. Blender jar socket
13. B.L. stopper
14. Dry grinder jar
15. Dry grinder jar socket
16. Dry grinder jar lid
17. Spatula
18. Juicer body
2. Press fit the juicing mesh on the motor coupler by slight rotation until you
hear a click sound.
3. Fit the juicer cover (3) on the juicer body (18)
18
13
4. Lock both side swing locks (6).
11
5. Fit spout cover (7) by sliding on juicer body (18).
10
6. Place a container below the spout outlet (7) for collecting juice.
13
16
7. Wash fruits and vegetables and cut it into small pieces so that they can
14
be inserted into the feeder tube easily.
15
8. Plug cord into the AC outlet. Always ensure that the supply voltage is in
accordance with the rated voltage. Before plugging unit into the power
12
source make sure that the switch is at off position and the mesh is
17
securely placed and the juicer cover is securely clamped on the juicer
body by swing locks.
9. Use 1st speed for juicing. For short operation turn the speed control to
pulse position.
10. Insert the fruits into the feeder tube and press them down gently with the
help of food pusher.
11. Once the juicing operation is over, press the switch to "0" position and
unplug the unit
NOTE : To have maximum juicing efficiency from the juicer, it is advisable to :
a) Run the juicer at first speed
b) Clean the juicing mesh frequently under running water with a brush.
In addition for soft and citrus fruits it is advisable to insert fruits slowly and
not pressing these by food pusher.
Blending
1. This jar can be used for liquidizing of fruit juices, soups, cocktails, milk
shakes, purees etc. the minimum capacity of the jar is 1/3 jar and
maximum capacity is 2/3 jar.
2. Fill the jar with the solids to be liquidized such as tomatoes. Fit the jar on
to the main unit.
3. Place the lid on the jar.
4. If needed water can be added. Now switch on the mixer for one minute
and you will get finally blended juices and purees.
5. If ingredients need to be stirred during wet grinding of rice and dal batter.
Stop mixer, insert spatula and stir.
Dry grinding
1. This jar can be used for grinding black pepper, roasted coffee seeds,
turmeric, coriander, red chilies etc. the jar should not be filled more than
½ of the total capacity.
2. Ensure that the jar is absolutely clean and dry.
3. Fill the jar with the ingredients. Place the lid on the top of the jar and fit the
jar on the main unit.
4. During turmeric grinding first break it into smaller pieces before starting
grinding operation.
NOTE : Ingredients can be added during liquidizing, wet / dry grinding
operations by removing the RC cap (13) on the lid.
Overload Protector
The juicer mixer grinder is protected against the sudden overloads. In
case such a situation does occur, your juicer mixer grinder will
automatically turn off. To restart the unit, please wait for 2-3 minutes to
allow the motor to cool down and also remove the cause of overload.
Press the button located at the bottom of the juicer mixer grinder to
restart the unit.
Cleaning and Maintenance
Juicer assembly
1. Make sure the juicer is at "off" position and the plug is disconnected from
outlet before putting on or taking off any part.
2. Release the swing lock downwards and lift the juicer cover.
3. Remove juicer mesh assembly by pulling it up from the base of the juicer
body, holding juicer body with both hands lift it up from the basic unit.
4. Remove spout cover and the juicer body. Remove the pulp collected in
the pulp collector of the juicer body.
5. Clean juicer mesh under the running water.
6. Motor must always be kept dry. Use a damp cloth to clean the motor
housing.
7. Do not use abrasive cleaners or scouring pads on appliance.
8. Dry all parts.
9. Reassemble all parts in proper order and store the appliance in a dry
place.
Blender jar
1. Pour a little soap and water into the jar, close the lid and run it on the main
st
unit at 1 position. This dislodges the food particles lodged inside the jar.
2. Wipe the area along the blades with a wet cloth and then dry.
Dry grinding jar
After dry grinding, remove the contents and wipe the jar with a dry cloth.
