Indel CR 63F INOX Installation & Operating Instructions Manual

Isotherm cruise & drawer marine freezers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation & operating instructions
Isotherm Cruise & Drawer marine freezers
Type: CR 63F INOX, CR 65F, CR 65F INOX, CR 90F, CR 90F INOX,
DR 55F INOX
Indel Marine USA, Inc.
3400 Gateway Drive
Unit 107
Pompano Beach, FL 33069
Tel +1 954 984 8448, +1 800 422 9711
Fax +1 954 979 2533
E-mail: info@indelmarineusa.com
www.indelmarineusa.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR 63F INOX and is the answer not in the manual?

Questions and answers

Summary of Contents for Indel CR 63F INOX

  • Page 1 Installation & operating instructions Isotherm Cruise & Drawer marine freezers Type: CR 63F INOX, CR 65F, CR 65F INOX, CR 90F, CR 90F INOX, DR 55F INOX Indel Marine USA, Inc. 3400 Gateway Drive Unit 107 Pompano Beach, FL 33069...

  • Page 2: Table Of Contents

    Installation & operating instructions Table of contents Introduction General Safety and precautions Environmental markings Operation Temperature setting thermostat User tips Defrosting Maintenance Battery voltage sensor Installation instructions Ventilation Door front Reverse door swing Electrical connections Electrical wire dimensions Operation with converter Wiring diagram Technical data Trouble shooting...

  • Page 3: Introduction General

    1. Introduction 1.2 Safety and precautions 1.1 General For your own and others safety, read this fi rst. Isotherm freezers are specially designed to operate in tough marine environments. They are fi tted with a fully Danger! When connected to mains power, ensure hermetic, leak-free compressor, they offer the lowest that the power supply is equipped with an earth possible power consumption and noise level.

  • Page 4: Operation

    2. Operation - Start up the freezer if possible 6 - 8 hours before it shall be loaded with frozen food. - Load the food inside the freezer in such a way, air The freezers are equipped with a standard mechanical can circulate to equalize the temperature.

  • Page 5: Battery Voltage Sensor

    3.1 Battery voltage sensor 4.2 Door front panel The front panels on the doors can be replaced or addition- To protect the batteries from becoming completely al standard front panels in white, teak, mahogany or cherry discharged, a battery voltage sensor switches off the can be mounted on top of the standard panel.

  • Page 6: Electrical Connections

    4.4 Electrical connections/wiring Wiring diagram converter connection When connecting the freezer electrically, it is important that following points are considered: Always use cables of suffi cient area. The area in the following table should be regarded as a minimum. * Always connect the freezer directly to the battery or to the battery main switch on the plus circuit.
  • Page 7 DR 55 F INOX 1. Electronic unit 12/24 volt 2. Battery 3. Fan condenser 4. Inner fan 5. Thermostat 6. Fuse 15A-12V / 7,5A-24V 001241 CR 90 F, CR 90 F INOX 1. Electronic unit 12/24 volt 2. Battery 3. Fan 4.

  • Page 8: Technical Data

    Wrong fuse size. Check fuse, 15 A-12 V / 7,5 A-24 V Faulty electronic unit. Exchange electronic unit. If a complicated fault does occur, such as requiring specialist assistance, please contact Indel Marine USA or your local marine distributor for advice.

  • Page 9: Installation Dimensions

    7 Installation dimensions CR 65 Freezer & CR 90 Freezer CR 65F 20-11/16 23-3/4 20-1/8 1-9/16 CR 90F 20-11/16 29-1/3 19-7/8 1-9/16 *) B x H = day opening, min dimensions CR 63 Freezer INOX, CR 65 Freezer INOX, CR 90 Freezer INOX CR 63 F INOX 19-1/2 24-5/8...

This manual is also suitable for:
