Summary of Contents for A.R.North America AR610 Blue Clean
- Page 1 AR610 Blue Clean • M AINTENANCE ANUAL Place Stamp Here Warning: This manual must be read before installation or use of the unit. A.R. North America Attn: Pressure Washer Warranty Department 140 - 81st Avenue NE Fridley, MN 55432...
- Page 2 RESSURE ASHER IMITED ARRANTY This product is under warranty to the original retail consumer against defects in material and workmanship for a period of 1 (one) year on machine, 90 days on gun and hose assembly, from the date of retail purchase and is not transferable. Warranty covers replacement parts.
- Page 3 Notes NTRODUCTION The high pressure power-jet cleaner you have purchased is a technologically advanced product designed by one of the leading European manufactures of high-pressure pumps. To obtain the best performance from your unit, read this booklet carefully and follow the instructions each time you use the cleaner.
- Page 4 2.1.11 Do not tamper with or alter the calibration of the safety valve. Pos. Code Description Qty. Pos. Code Description Qty. EXPLOSION HAZARD. 1340700 Black post. casing 680700 Screw 2.1.12 DO NOT alter the original diameter of the spray head nozzle. 1261560 Screw 480480...
- Page 5 AR610 Always use two hands when operating a pressure washer. This will assure complete control of the equipment. Always test the GFCI plug prior to using the cleaner. Never test the pressure of the cleaner against any part of the body. Use the trigger lock whenever the spray gun is not being used for cleaning.
- Page 6 3.1.10 Use the cleaner only with accessories and replacement parts The pump does not operate at the prescribed pressure. authorized by the manufacturer. The use of original accessories Sudden changes in pressure. Excess noise. and replacement parts will ensure safe, trouble-free operation. Water leakages.
- Page 7 Long periods of non-use may lead to the formation of lime scale Connect the high-pressure hose to the water (OUTLET) on the deposits. Working through the hole on the cleaner. rear, RELEASE the motor using a screwdriver (for models with this feature). Then remove the screwdriver and proceed with the restart operations.
- Page 8 Pull the spray gun trigger; push the switch Correct Use of the Rotary Nozzle (Where fi tted) start the motor. 5.6.1 For increased washing power, use the rotary nozzle kit as follows: 5.6.2 Turn off the high pressure cleaner. 5.6.3 Unscrew the adjustable head and fi...
Need help?
Do you have a question about the AR610 Blue Clean and is the answer not in the manual?
Questions and answers
el liquido de limpieza no fluye por la linea de alimentación hacia la lanza
The cleaning liquid may not be flowing through the feed line to the lance on the A.R. North America 610 Blue Clean due to one or more of the following reasons:
- Nozzle is clogged: Clean the nozzle using the tool provided.
- Air is being sucked into the system: Check that water inlet and outlet connections are tight.
- Water filter is clogged: Clean the filter.
- Water supply pressure is low: Fully open the water supply tap.
- Adjustable nozzle is incorrectly positioned: Pull the spray adjuster back (+).
- Water is being suctioned from an external tank instead of the mains: Connect the cleaner to the mains water supply.
- Worn seals or oil seals: Fit new seals.
Check and resolve each of these issues to restore proper flow.
This answer is automatically generated
