Page 1 2 0 1 4 200 Convertible O W N E R ’ S M A N U A L...
Page 2 With respect to any Vehicles Sold in Canada, the name Chrysler This manual illustrates and describes the operation of features Group LLC shall be deemed to be deleted and the name Chrysler and equipment that are either standard or optional on this Canada Inc.
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5 INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..6 HOW TO USE THIS MANUAL ....4 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained tech- Congratulations on selecting your new Chrysler Group nicians and genuine parts, and cares about your satisfac- LLC vehicle. Be assured that it represents precision tion.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ To Disarm The System ....20 A WORD ABOUT YOUR KEYS ... . .12 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Battery Replacement ....27 OCCUPANT RESTRAINTS ....40 ▫...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Supplemental Restraint System (SRS) — SAFETY TIPS ......92 Air Bags .
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your authorized dealer.
Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 NOTE: • If you try to remove the key before you place the shift lever into PARK, the key may become trapped tempo- rarily in the ignition switch lock cylinder. If this occurs, place the shift lever in PARK, rotate the key to the right slightly, then remove the key as described.
Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles equipped with the Electronic Vehicle WARNING! (Continued) Information Center (EVIC), the power window • Never leave children alone in a vehicle, or with switches, radio, hands–free system (if equipped), and access to an unlocked vehicle.
Page 17: Key-In-Ignition Reminder
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key-In-Ignition Reminder The system uses ignition keys which have an embedded electronic chip (transponder) to prevent unauthorized Opening the driver’s door when the key is in the ignition vehicle operation. Therefore, only keys that are pro- sounds a chime signal to remind you to remove the key.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE an invalid key to start the engine. Either of these condi- All of the keys provided with your new vehicle have tions will result in the engine being shut off after two been programmed to the vehicle electronics.
Page 19: Customer Key Programming
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 NOTE: When having the Sentry Key® Immobilizer 3. Insert the second valid key into the ignition switch. System serviced, bring all vehicle keys with you to an Turn the ignition switch to the ON/RUN position authorized dealer.
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Repeat this procedure to program up to eight keys. If you VEHICLE SECURITY ALARM — IF EQUIPPED do not have a programmed Sentry Key® contact your The Vehicle Security Alarm monitors the doors and trunk authorized dealer for details.
Page 21: To Arm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 horn after three minutes, turn off all of the visual signals 3. The Vehicle Security Light in the instrument cluster after 15 minutes, and then the Vehicle Security Alarm will will flash for 16 seconds. This shows that the Vehicle rearm itself.
Page 22: To Disarm The System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disarm The System of the previously described arming sequences has oc- curred, the Vehicle Security Alarm will arm regardless of Either press the UNLOCK button on the RKE transmitter whether you are in the vehicle or not. If you remain in the or insert a valid Sentry Key®...
Page 23: Illuminated Entry - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 ILLUMINATED ENTRY — IF EQUIPPED NOTE: • The front courtesy overhead console and door cour- The courtesy lights will turn on when you press the unlock button on the Remote Keyless Entry (RKE) trans- tesy lights will turn on if the dimmer control is in the mitter or open any door.
Page 24: To Unlock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • The line of transmission must not be blocked with metal objects when using the RKE transmitter. • Inserting the key into the ignition switch disables all buttons on the RKE transmitter. RKE Transmitter With Integrated Key To Unlock The Doors Press and release the UNLOCK button on the RKE...
Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Remote Key Unlock, Driver Door/All Doors First 2. Release both buttons at the same time. Press 3. Test the feature while outside of the vehicle by press- This feature lets you program the system to unlock either ing the LOCK/UNLOCK buttons on the RKE trans- the driver’s door or both doors on the first press of the mitter with the ignition in the LOCK position and the...
Page 26 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flash Lights With Lock 3. Test the feature while outside of the vehicle by press- ing the LOCK/UNLOCK buttons on the RKE trans- The feature will cause the turn signal lights to flash when mitter with the ignition in the LOCK position and the the doors are locked or unlocked with the RKE transmit- key removed.
Page 27: To Lock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 (EVIC). Refer to “Electronic Vehicle Information Center (Customer-Programmable Features)” in “Understand- (EVIC)/Personal Settings (Customer-Programmable Fea- ing Your Instrument Panel” for further information. tures)” in “Understanding Your Instrument Panel” for • For vehicles not equipped with the EVIC, perform the further information.
Page 28: Convertible Top Operation Button - If Equipped
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If there is no key in the ignition switch, pressing headlights turn on, the park lights will flash, the horn the LOCK button on the RKE transmitter while you are in will pulse on and off, and the Illuminated Entry system the vehicle will activate the Vehicle Security Alarm.
Page 29: Battery Replacement
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Battery Replacement The recommended replacement battery is CR2032. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate • Do not touch the battery terminals that are on the back housing or the printed circuit board. 1.
Page 30: General Information
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, military base, and some This device complies with part 15 of FCC rules and with mobile or CB radios. RS-210 of Industry Canada.
Page 31: How To Use Remote Start
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 • System not disabled from previous remote start event How To Use Remote Start • Vehicle theft alarm not active All of the following conditions must be met before the engine will remote start: WARNING! •...
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Start Abort Message On Electronic Vehicle To Enter Remote Start Mode Information Center (EVIC) — If Equipped The following messages will display in the EVIC if the Press and release the REMOTE START button vehicle fails to remote start or exits remote start prema- on the RKE transmitter twice within five sec- turely:...
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 • If an engine fault is present the vehicle will start and NOTE: To avoid unintentional shut downs, the system then shut down 10 seconds later. will disable the one-time press of the remote start button for two seconds after receiving a valid remote start Remote start will also cancel if any of the following occur: request.
Page 34: Door Locks
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS If the door lock knob is down when you shut the door, the door will lock. Make sure the keys are not inside the Manual Door Locks vehicle before closing the door. To lock each door, push the door lock knob on each door trim panel downward.
Page 35: Power Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 WARNING! (Continued) • Do not leave the key fob in or near the vehicle, or in a location accessible to children. A child could operate power windows, other controls, or move the vehicle. Power Door Locks A door lock switch is located on the driver and passenger door trim panel.
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE auto door lock feature can be enabled or disabled by your Auto Unlock Door On Exit Programming authorized dealer. Please see your authorized dealer for The Automatic Unlock Doors On Exit feature can be service.
Page 37: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 4. A single chime will indicate the completion of the programming. NOTE: This feature will not be functional until the vehicle has been driven and the shift lever returned to the PARK position. 5.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Smart Glass Feature • If a fluttering noise is heard from the rear seat belts The door window will lower slightly if the window is fully up when opening the door. The window will return while driving with the windows down, safely bring to its full up position after closing the door.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 For vehicles not equipped with the Electronic Vehicle To reactivate the window Smart Glass Feature, perform Information Center (EVIC), the power window switches the following steps after vehicle power is restored. will remain active for 45 seconds after the ignition switch 1.
Page 40: Wind Buffeting
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE passenger door, press and release the window LOCK Wind Buffeting button (setting it in the down position). To enable the Wind buffeting can be described as the perception of window control, press and release the window LOCK pressure on the ears or a helicopter-type sound in the button again (setting it in the up position).
Page 41: Trunk Safety Warning
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 NOTE: The convertible top must be either closed and With the ignition switch in the ON/RUN position, the latched or open and latched to release the trunk. word “dECK” will display in the odometer indicating the trunk is open.
Page 42: Trunk Internal Emergency Release
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended. Once in the trunk, young children may not be able to escape, even if they entered through the rear seat. If trapped in the trunk, children can die from suffocation or heat stroke.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 • Advanced Front Air Bags for driver and front passen- all the way out and then adjusting the belt to the desired length to restrain a child seat or secure a large item in a seat •...
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some simple steps you can take to minimize the ride properly buckled up in the rear seat. Never allow risk of harm from a deploying air bag: children to slide the shoulder belt behind them or under their arm.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 4. Do not lean against the door or window. If your WARNING! (Continued) vehicle has side air bags, and deployment occurs, the • Being too close to the steering wheel or instrument side air bags will inflate forcefully into the space panel during Advanced Front Air Bag deployment between you and the door.
Page 46: Lap/Shoulder Belts
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle up even though you are an excellent driver, even lock and reduce the risk of you striking the inside of the on short trips. Someone on the road may be a poor driver vehicle or being thrown out.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 2. The seat belt latch plate is on the outboard side of the WARNING! (Continued) front seat, next to your arm. Grasp the latch plate and • Wearing your belt in the wrong place could make pull out the belt.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click.” • A belt that is buckled into the wrong buckle will not protect you properly.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 WARNING! (Continued) • A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed posi- • A lap belt worn too high can increase the risk of tion.
Page 51: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Lap/Shoulder Belt Untwisting Procedure which are used to secure a child restraint system. For additional information, refer to “Installing Child Re- Use the following procedure to untwist a twisted lap/ straints Using The Vehicle Seat Belt” under the “Child shoulder belt.
Page 52: Automatic Locking Retractor Mode (Alr) - If Equipped
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE to retract completely in this case and then carefully pull How To Engage The Automatic Locking Mode out only the amount of webbing necessary to comfort- 1. Buckle the combination lap and shoulder belt. ably wrap around the occupant’s mid-section.
Page 53: Energy Management Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Seat Belt Pretensioners WARNING! The seat belts for both front seating positions are • The belt and retractor assembly must be replaced if equipped with pretensioning devices that are designed to the seat belt assembly Automatic Locking Retractor remove slack from the seat belt in the event of a collision.
Page 54: Supplemental Active Head Restraints (Ahr)
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Active Head Restraints (AHR) This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in These head restraints are passive, deployable compo- certain types of rear impacts.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a collision.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Grasp the deployed AHR from the rear seat. 1 — Downward Movement Hand Positioning Points On AHR 2 — Rearward Movement 2. Position the hands on the top of the deployed AHR at a comfortable position.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 AHR In Reset Position 3 — Final Downward Movement To Engage Locking Mechanism NOTE: 4. The AHR front soft foam and trim half should lock • If you have difficulties or problems resetting the Active into the back decorative plastic half.
Page 58: Enhanced Seat Belt Use Reminder System (Beltalert®)
5 mph (8 km/h), by blinking the Seat Belt BeltAlert® can be enabled or disabled by your autho- Reminder Light and sounding an intermittent chime. rized dealer. Chrysler Group LLC does not recommend Once the sequence starts, it will continue for the entire deactivating BeltAlert®.
Page 59: Seat Belts And Pregnant Women
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 NOTE: Although BeltAlert® has been deactivated, the existing belt is not long enough. When it is not required, Seat Belt Reminder Light will continue to illuminate remove the extender, and store it. while the driver’s or front passenger (if equipped with BeltAlert®) seat belt remains unfastened.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE instrument panel, above the glove compartment. The NOTE: These air bags are certified to the new Federal words SRS AIRBAG are embossed on the air bag covers. regulations for Advanced Air Bags. The Advanced Front Air Bags have a multistage inflator design.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 • Knee Impact Bolsters protection for an occupant during a side impact. The SABs are located in the outboard side of the front seats. • Driver Advanced Front Air Bag NOTE: • Passenger Advanced Front Air Bag •...
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The first stage inflator is triggered immediately during an WARNING! (Continued) impact that requires air bag deployment. This low output • Do not put anything on or around the air bag is used in less severe collisions. A higher energy output is covers or attempt to open them manually.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 during a side impact. The SAB is marked with an air bag deploys independently; a left side impact deploys the left label sewn into the outboard side of the front seats. air bag only and a right-side impact deploys the right air bag only.
Page 64: Air Bag Deployment Sensors And Controls
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE properly, and use the appropriate sized child restraint, Along with seat belts and pretensioners, Advanced Front infant restraint or booster seat recommended for the size Air Bags work with the knee impact bolsters to provide and weight of the child.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 including the severity and type of collision. Advanced Seat belts are necessary for your protection in all colli- Front Air Bags are not expected to reduce the risk of sions, and also are needed to help keep you in position, injury in rear, side, or rollover collisions.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE turns on the Air Bag Warning Light, either momentarily Driver And Passenger Advanced Front Air Bag or continuously. A single chime will sound if the light Inflator Units comes on again after initial startup. The Driver and Passenger Advanced Front Air Bag Inflator Units are located in the center of the steering It also includes diagnostics that will illuminate the instru-...
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 The Advanced Front Air Bag gas is vented through the could injure you if you are not seated properly, or if items vent holes in the sides of the air bag. In this way, the air are positioned in the area where the side air bag inflates.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Turn on the interior lights, which remain on as long as • The nylon air bag material may sometimes cause the battery has power or until the ignition key is abrasions and/or skin reddening to the driver and removed.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 continues, see your doctor. If these particles settle on Maintaining Your Air Bag System your clothing, follow the garment manufacturer’s in- structions for cleaning. WARNING! Do not drive your vehicle after the air bags have de- •...
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light WARNING! (Continued) • Do not attempt to modify any part of your air bag You will want to have the air bags ready to system. The air bag may inflate accidentally or may inflate for your protection in a collision.
Page 71: Event Data Recorder (Edr)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 • How various systems in your vehicle were operating; NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint • Whether or not the driver and passenger safety belts Controller (ORC) may also be disabled.
Page 72: Child Restraints
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To read data recorded by an EDR, special equipment is enough for an adult safety belt. Always check the child required, and access to the vehicle or the EDR is needed. seat Owner’s Manual to make sure you have the correct In addition to the vehicle manufacturer, other parties, seat for your child.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 WARNING! In a collision, an unrestrained child can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Recommended Type of Child Child Size, Height, Weight or Age Restraint Small Children Children who are at least two Forward-Facing Child Restraint years old or who have out-grown with a five-point Harness, facing the height or weight limit of their forward in the rear seat of the ve- rear-facing child restraint...
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 The infant carrier is only used rearward-facing in the WARNING! vehicle. It is recommended for children from birth until • Never place a rear facing infant seat in front of an they reach the weight or height limit of the infant carrier. Convertible child seats can be used either rearward- air bag.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE remain in a forward-facing child seat with a harness for WARNING! as long as possible, up to the highest weight or height • Improper installation can lead to failure of an allowed by the child seat. infant or child restraint.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Children Too Large For Booster Seats 3. Does the shoulder belt cross the child’s shoulder between their neck and arm? Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend 4.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Recommendations For Attaching Child Restraints Restraint Type Combined Use any attachment method shown with an “X” Below Weight of the LATCH – LATCH – Child + Child Lower Anchors Seat Belt + Top Lower Anchors Seat Belt Only Restraint...
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Lower Anchors and Tethers for Children (LATCH) Anchors and Tethers for CHildren. The LATCH system Restraint System has three vehicle anchor points for installing LATCH- equipped child seats. There are two lower anchorages located at the back of the seat cushion where it meets the seatback and one top tether anchorage located behind the seating position.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH Positions For Installing Child Restraints In This Vehicle Lower Anchorage Symbol 2 anchorages per seating position Top Tether Anchorage Symbol...
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 LATCH Positions For Installing Child Restraints What is the weight limit (child’s weight + 65 lbs (29.5 kg) Use the LATCH anchorage system until the weight of the child restraint) for using the combined weight of the child and the child LATCH anchorage system to attach the child restraint is 65 lbs (29.5 kg).
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage sym- bols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 tether anchors are underneath access covers in the carpet covering the back of the seat where you see the tether anchorage symbol. Child Tether Anchor C — Attaching Strap D — Tether Anchor Child Tether Access Port Cover LATCH-compatible child restraint systems will be A —...
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE anchorage and a way to tighten the connection to the To Install A LATCH-compatible Child Restraint anchorage. Forward-facing child restraints and some 1. If the selected seating position has a Switchable Auto- rear-facing infant restraints will also be equipped with a matic Locking Retractor (ALR) seat belt, stow the seat tether strap.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 4. Attach the lower hooks or connectors of the child How To Stow An Unused ALR Seatbelt restraint to the lower anchorages in the selected seat- When using the LATCH attaching system to install a ing position.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the seat belt tight around the child restraint so that it is WARNING! not necessary to use a locking clip. The ALR retractor can be “switched” into a locked mode by pulling all of the Improper installation of a child restraint to the webbing out of the retractor and then letting the webbing LATCH anchorages can lead to failure of the re-...
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Lap/Shoulder Belt Systems for Installing Child Restraints in this Vehicle...
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE What is the weight limit (child’s 65 lbs (29.5 kg) The Tether Anchor can be used with weight + weight of the child re- the seat belt until the combined straint) for using the Tether Anchor weight of the child and the child with the seat belt to attach a forward restraint is 65 lbs (29.5 kg).
Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 Installing A Child Restraint with a Switchable 5. To lock the seat belt, pull down on the shoulder part of Automatic Locking Retractor (ALR) the belt until you have pulled all the seat belt webbing out of the retractor.
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. If the child restraint has a top tether strap and the Installing A Child Restraint With A Cinching seating position has a top tether anchorage, connect Latch Plate (CINCH) — If Equipped the tether strap to the anchorage and tighten the tether 1.
Page 91 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 5. If the child restraint has a top tether strap and the facing out, away from the child restraint. Repeat steps 4 seating position has a top tether anchorage, connect to 6, above, to complete the installation of the child the tether strap to the anchorage and tighten the tether restraint.
Page 92 90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Push the tether strap and hook (B) through the access 4. Open the access cover (C) on the carpet covering the port and down into the trunk. Route the tether strap to back of the seat and attach the tether strap hook (D) to provide the most direct path from the child seat to the the anchor.
Page 93: Transporting Pets
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 Transporting Pets While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. Air Bags deploying in the front seat could harm your pet. Wide-open throttle acceleration in low gear can be detri- An unrestrained pet will be thrown about and possibly mental and should be avoided.
Page 94: Safety Tips
92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A new engine may consume some oil during its WARNING! (Continued) first few thousand miles (kilometers) of operation. This • It is extremely dangerous to ride in a cargo area, should be considered a normal part of the break-in and inside or outside of a vehicle.
Page 95: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 Whenever a change is noticed in the sound of the exhaust WARNING! (Continued) system, when exhaust fumes can be detected inside the eventually poison you. To avoid breathing (CO), vehicle, or when the underside or rear of the vehicle is follow these safety tips: damaged, have a competent mechanic inspect the com- •...
Page 96 94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Front seat belt assemblies must be replaced after a feel the air directed against the windshield. See your collision. Rear seat belt assemblies must be replaced after authorized dealer for service if your defroster is inoper- a collision if they have been damaged (i.e., bent retractor, able.
Page 97: Periodic Safety Checks You Should Make Outside
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 WARNING! (Continued) WARNING! (Continued) • Never place or install floor mats or other floor • Always make sure that objects cannot fall into the coverings in the vehicle that cannot be properly driver footwell while the vehicle is moving.
Page 98 96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE lodged in the tread or sidewall. Inspect the tread for cuts Door Latches and cracks. Inspect sidewalls for cuts, cracks and bulges. Check for positive closing, latching, and locking. Check the wheel nuts for tightness. Check the tires Fluid Leaks (including spare) for proper cold inflation pressure.
Page 99: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Emergency Bypass Mode (To Raise The Top CONVERTIBLE TOP OPERATION ..101 Only) ......123 ▫...
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect® Phone — IF EQUIPPED ..128 SEATS ......165 ▫...
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 ▫ Headlights And Parking Lights ... .178 ▫ Interior Lights ..... . .183 ▫...
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ To Resume Speed .....191 CIGAR LIGHTER AND ASH RECEIVER — IF EQUIPPED ......204 ▫...
Page 103: Convertible Top Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 CONVERTIBLE TOP OPERATION WARNING! CAUTION! The convertible top does not provide the structural protection that a reinforced metal roof does and the Failure to follow these cautions may cause interior fabric top cannot be expected to prevent the ejection water damage, stains or mildew on the top material: of the occupants in a collision.
Page 104: Power Convertible Top Usage Precautions
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When operating the power convertible top, the trunk lid Spring-loaded flipper doors, which provide clearance for will pivot at the rear of the vehicle, swing open by the the linkage, close off notches in the quarter trim panels rear window, and then pivot backward.
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 micro-switches verify that operations are complete CAUTION! before allowing the next stage of lowering or raising • Correctly position the cargo shield in the trunk operation. before stowing the top. Doing so closes a switch •...
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! CAUTION! (Continued) • To prevent striking a low ceiling or automatic door Before operating the power top: opener with the top, it is strongly recommended • Always check on top of the tonneau cover area to that you do not operate the power top inside a be sure that it is clear of debris or other items.
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 CAUTION! (Continued) CAUTION! (Continued) • Do not allow the top to remain in the suspended • Do not leave the top lowered for several weeks at a position. After approximately 10 minutes in the time.
Page 108: Cargo Shield
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • When using the power top switch on the center • Before operating the power top, make sure that no console, if potential danger exists while raising the moving parts of the convertible top can injure a person or animal.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Positioning The Cargo Shield For Top Operation Pull the cargo shield toward you to begin unfolding the panels. Grasp the handle in the center of the outermost (top) panel and raise the cargo shield. Then, align and seat the tabs at each end of the cargo shield in the V slots in the trunk liner as shown in the illustration.
Page 110: Power Convertible Top Controls
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE in the trunk trim. Continue folding the upright panel Power Convertible Top Controls forward onto the horizontal panel, then grasp both The power top switch is located on the front of the center panels and lift them to the forward, upright position in console.
Page 111: Lowering The Power Convertible Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Lowering the Power Convertible Top obstruction and the driver is alerted, the convertible top operation can be stopped by releasing the switch. Using The Power Top Switch Using The Remote Keyless Entry Transmitter NOTE: The power top switch will operate when the ignition switch is turned to the ON or ACC position and NOTE: Steps 1 –...
Page 112: Raising The Power Convertible Top
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Raising The Power Convertible Top Manually Closing the power convertible top manually is a compli- Using The Power Top Switch cated and physically demanding procedure, and it re- NOTE: The power top switch will operate when the quires a special tool to do so.
Page 113: Wind Stop - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Wind Stop — If Equipped 3. Lay the small frame (1) flat on top of the large frame (2) and snap the two frames together by engaging the The Wind Stop installs in the backseat area of the vehicle. frame lock (3).
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Pivot the small frame (1) away from the large frame (2) 5. Unfold both stems at the rear of the large frame. until the pivot lock (3) engages to lock the two frames in an L shape.
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 6. Align and insert the stems into the slot in each trim 7. Align the pins at the front of the large frame with the panel. hole in each trim panel. Slide the pins outward until fully extended into each hole.
Page 116: Power Convertible Top Operation And Warning Messages
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Removing And Storing The Wind Stop Power Convertible Top Operation And Warning Messages Reverse the installation procedure to remove, fold, and store the Wind Stop. However, note the following before When the appropriate conditions exist, the PTCM dis- doing so: plays various power convertible top operation and warn- ing messages in the Electronic Vehicle Information Center...
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time CON- Until Op- Until Op-...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time SECURE 9 sec.
Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time CON- Until Op- Until Op-...
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time SPEED 9 sec.
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time TRUNK Continu- DECK...
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time CON- 6 sec.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 EVIC EVIC Odometer Odometer Odometer Odometer Chime Condition Operator Message Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/h]) Time [8 km/h]) Time CON- Until TOP FAIL...
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If you are trying to lower the top and ambient temperature is 0°F (-18°C) or lower, wait until the temperature rises and the top is thawed and dry before operating the power top. A soft top should not be lowered at temperatures below 32°F (0°C).
Page 125: Emergency Bypass Mode (To Raise The Top Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Emergency Bypass Mode (To Raise The Top CAUTION! (Continued) Only) • DO NOT exceed 40 mph (64 km/h). This procedure is only to be used to raise the top when • Using the Emergency Bypass Mode could poten- the top cannot be returned to the UP (raised) position by tially damage the convertible top and should only pressing the POWER TOP switch or is in a position in...
Page 126: Mirrors
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 127: Automatic Dimming Mirror - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light to the left of the button will illuminate to indicate when the dimming feature is activated.
Page 128: Power Mirrors
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors When finished, return the knob to the center “O” (Off) position to guard against accidentally moving a mirror The power mirror control is located on the driver’s door position. trim. Mirror Directions Power Mirror Control To adjust a mirror, turn the control toward the left or right mirror positions indicated.
Page 129: Adjusting Side View Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Adjusting Side View Mirrors WARNING! (Continued) Outside Mirror — Driver Side collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a Adjust the outside mirror to center on the adjacent lane of vehicle seen in the passenger side convex mirror.
Page 130: Vanity Mirror - If Equipped
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE not be equipped with rear window defroster, in this case the heated mirrors will still function as intended. Refer to “Rear Window Features” in “Understanding The Fea- tures Of Your Vehicle” for further information. Vanity Mirror —...
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 mobile phone’s audio is transmitted through your vehi- The Uconnect® Phone is driven through your cle’s audio system; the system will automatically mute Bluetooth® “Hands-Free Profile” mobile phone. your radio when using the Uconnect® Phone. Uconnect®...
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command Button WARNING! (Continued) Actual button location may vary with the ra- laws, including laws regarding phone use. Your at- dio. The individual buttons are described in the tention should be focused on safely operating the “Operation”...
Page 133: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 • For each feature explanation in this section, only the Operation compound form of the voice command is given. You Voice commands can be used to operate the Uconnect® can also break the commands into parts and say each Phone and to navigate through the Uconnect®...
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Help Command To complete the pairing process, you will need to refer- ence your mobile phone Owner’s Manual. The If you need assistance at any prompt, or if you want to Uconnect® website may also provide detailed instruc- know your options at any prompt, say “Help”...
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 • For identification purposes, you will be prompted to Dial By Saying A Number give the Uconnect® Phone a name for your mobile • Press the button to begin. phone. Each mobile phone that is paired should be •...
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The system will prompt you to say the name of the phonebook. Specific Bluetooth® Phones with Phone person you want to call. Book Access Profile may support this feature. See Uconnect® website for supported phones. •...
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 • After the “Ready” prompt and the following beep, say downloaded names can be used. Until then, if avail- able, the previously downloaded phonebook is avail- “Phonebook New Entry.” able for use. • When prompted, say the name of the new entry. Use of •...
Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Next, choose the number designation (home, work, The Uconnect® Phone will allow you to enter up to 32 names in the phonebook with each name having up to mobile, or other) that you wish to edit. four associated phone numbers and designations.
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 • Press the • Note that only the phonebook entry in the current button to begin. language is deleted. • After the “Ready” prompt and the following beep, say • Automatic downloaded phonebook entries cannot be “Phonebook Delete.”...
Page 140: Phone Call Features
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Automatic downloaded phonebook entries cannot be • The selected number will be dialed. deleted or edited. Phone Call Features List All Names In The Uconnect® Phonebook The following features can be accessed through the •...
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Answer Or Reject An Incoming Call — Call in progress. To go back to the first call, refer to “Toggling Currently In Progress Between Calls” in this section. To combine two calls, refer to “Conference Call”...
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Conference Call active call is terminated by the phone far end, a call on hold may not become active automatically. This is cell When two calls are in progress (one active and one on phone-dependent.
Page 143: Uconnect® Phone Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 switched to OFF. Call continuation functionality avail- Uconnect® Phone Features able on the vehicle can be any one of three types: Language Selection • After the ignition is switched to OFF, a call can To change the language that the Uconnect®...
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency Assistance NOTE: • The emergency number dialed is based on the country If you are in an emergency and the mobile phone is reachable: where the vehicle is purchased (911 for the U.S. and Canada and 060 for Mexico).
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 NOTE: You should program the desired Towing Assis- WARNING! tance phone number using the Voice Command system. To do this, press the button and say “Setup,” followed by To use you Uconnect® Phone System in an emer- “Towing Assistance.”...
Page 146 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Working With Automated Systems “Send,” is also to be used for navigating through an automated customer service center menu structure, and This method is used in instances where one generally has to leave a number on a pager. to press numbers on the mobile phone keypad while navigating through an automated telephone system.
Page 147 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 • Some paging and voice mail systems have system time • After the “Ready” prompt and the following beep, say out settings that are too short and may not allow the one of the following: use of this feature.
Page 148: Advanced Phone Connectivity
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE dialing a number with your paired Bluetooth® mobile In order to un-mute the Uconnect® Phone: phone, the audio will be played through your vehicle’s • Press the button. audio system. The Uconnect® Phone will work the same •...
Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 If you would like to connect or disconnect the Bluetooth® Select Another Mobile Phone connection between your mobile phone and the This feature allows you to select and start using another Uconnect® Phone System, follow the instructions de- phone paired with the Uconnect®...
Page 150: Things You Should Know About Your Uconnect® Phone
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say Phone Voice Training feature may be used. To enter this “Setup Phone Pairing.” training mode, follow one of the two following proce- dures: •...
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 • Speak normally without pausing, just as you would This procedure may be repeated with a new user. The system will adapt to the last trained voice only. speak to a person sitting a few feet/meters away from you.
Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When navigating through an automated system such • In a convertible vehicle, system performance may be as voice mail, or when sending a page, at the end of compromised with the convertible top down. speaking the digit string, make sure to say “Send.”...
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 • In a convertible vehicle, system performance may be • After the “Ready” prompt and the following beep, say compromised with the convertible top down. “SMS Read” or “Read Messages.” • Uconnect® Phone will play the new text message for Recent Calls you.
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To send a message, press the button while the 9. Call me later system is listing the message and say “Send.” 10. Thanks Uconnect® Phone will prompt you to say the name or 11.
Page 155 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Turn Voice Text Reply Incoming Announcement ON/ Bluetooth® Communication Link Mobile phones have been found to lose connection to the Uconnect® Phone. When this happens, the connection Turning the Voice Text Reply Incoming Announcement can generally be reestablished by switching the phone OFF will stop the system from announcing the new off/on.
Page 156 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155...
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Voice Commands Voice Commands Primary Alternate (s) Primary Alternate (s) zero call cancel three confirmation prompts four continue five delete dial seven download eight edit nine emergency star (*) English plus (+) erase all pound (#) Espanol add location...
Page 160 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate (s) Primary Alternate (s) help previous home record again language redial list names return to main menu return or main menu list phones select phone select mobile send mute set up...
Page 161: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 General Information VOICE COMMAND — IF EQUIPPED This device complies with Part 15 of the FCC rules and Voice Command System Operation RSS 210 of Industry Canada. Operation is subject to the The Uconnect® Voice Command system allows following conditions: you to control your AM, FM radio, disk player, •...
Page 162 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE will be interrupted, and after the beep, you can add or WARNING! (Continued) change commands. This will become helpful once you laws. Your attention should be focused on safely start to learn the options. operating the vehicle.
Page 163: Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 Commands Main Menu The Voice Command system understands two types of Start a dialogue by pressing the Voice Command commands. Universal commands are available at all button. You may say “Main Menu” to switch to the times.
Page 164 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Menu Radio” (to switch to the radio menu) Radio AM • “Main Menu” (to switch to the main menu) To switch to the AM band, say “AM” or “Radio AM.” In this mode, you may say the following commands: Satellite Radio •...
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Disc Mode Bluetooth® Streaming (BT) Mode To switch to the disc mode, say “Disc.” In this mode, you To switch to Bluetooth® Streaming (BT) mode, say may say the following commands: “Bluetooth Streaming.” In this mode, you may say the following commands: •...
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Main menu setup” or – “Delete” (to delete the recording) • “Switch to setup” • “Play Memos” (to play previously recorded memos) — During the playback you may press the Voice Com- In this mode, you may say the following commands: mand button to stop playing memos.
Page 167: Voice Training
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 Voice Training SEATS For users experiencing difficulty with the system recog- Seats are a part of the Occupant Restraint System of the nizing their voice commands or numbers the Uconnect® vehicle. Voice “Voice Training” feature may be used. WARNING! 1.
Page 168: Power Seats
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Seats WARNING! The power seat switch is on the outboard side of the seat • Adjusting a seat while driving may be dangerous. near the floor. Use the switch to move the seat up, down, Moving a seat while driving could result in loss of forward, rearward, or to tilt the seat.
Page 169: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Adjusting The Seat Forward Or Rearward Heated Seats — If Equipped The seat can be adjusted both forward and rearward. On some models, the front driver and passenger seats Push the seat switch forward or rearward, the seat will may be equipped with heaters in both the seat cushions move in the direction of the switch.
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE minutes of continuous operation. If LOW-level heating is WARNING! selected, the system automatically turns the heater and • Persons who are unable to feel pain to the skin the indicator light OFF after a maximum of 30 minutes of continuous operation.
Page 171: Recliner Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 Recliner Adjustment The recliner control is on the outboard side of the seat. To recline the seat, lean forward slightly and lift the lever. Then lean back to the position desired and release the lever.
Page 172: Lumbar Support - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lumbar Support — If Equipped WARNING! This feature allows you to increase or decrease the • Adjusting a seat while the vehicle is moving is amount of lumbar support. The lumbar support lever is dangerous.
Page 173: Easy Entry System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Easy Entry System When returning the seat to its normal position, the memory feature restores the seat position and seatback The Easy Entry lever is located on upper seat belt anchor recline position to their current settings. cover.
Page 174: Active Head Restraints - Front Seats
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When AHRs deploy during a rear impact, the front half WARNING! of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. The head restraints for all occupants must be prop- This system is designed to help prevent or reduce the erly adjusted prior to operating the vehicle or occu- extent of injuries to the driver and front passenger in...
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Push Button Active Head Restraint (Normal Position) For comfort the Active Head Restraints can be tilted forward and rearward. To tilt the head restraint closer to the back of your head, pull forward on the bottom of the head restraint.
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • In the event of deployment of an Active Head Re- straint, refer to “Occupant Restraints/Resetting Active Head Restraints (AHR)” in “Things to Know Before Starting Your Vehicle” for further information. WARNING! • Do not place items over the top of the Active Head Restraint, such as coats, seat covers or portable DVD players.
Page 177: Head Restraints - Rear Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 TO OPEN AND CLOSE THE HOOD WARNING! (Continued) Two latches must be released to open the hood. • Active Head Restraints may be deployed if they are struck by an object such as a hand, foot or loose 1.
Page 178 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Move to the outside of the vehicle and lift the second- ary latch underneath the center front edge of the hood and raise the hood. Hood Prop Rod Before closing the hood, make sure to stow the prop rod in its proper location.
Page 179: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 passing light, fog lights, instrument panel light dimming CAUTION! and turn signals. The multifunction lever is located on the left side of the steering column. To prevent possible damage, do not slam the hood to close it.
Page 180: Headlights And Parking Lights
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights And Parking Lights Automatic Headlights — If Equipped Turn the end of the multifunction lever to the first detent Turning the end of the multifunction lever to the third for parking light operation. Turn to the second detent for detent (AUTO), will activate the automatic headlight headlight operation.
Page 181: Headlights With Wipers (Available With Automatic Headlights Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 With the engine running and the multifunction lever in Headlight Time Delay the AUTO position, the headlights will turn on and turn There is also a feature that delays turning off the vehicle off based on the surrounding light levels.
Page 182: Turn Signals
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside Move the multifunction lever up or down and the arrows light bulb.
Page 183: Flash-To-Pass
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 Flash-To-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will turn on the high beam headlights until the lever is released. NOTE: If the multifunction lever is held in the flash-to- pass position for more than 15 seconds, the high beams will shut off.
Page 184: Daytime Running Lights (Drl) - If Equipped
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights (DRL) — If Equipped Rotate the center portion of the lever upward to the next detent position to brighten the odometer and radio when The front turn signal lamps will turn on as Daytime the parking lights or headlights are on.
Page 185: Interior Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Interior Lights Two courtesy/reading lights are located in the bottom of the rearview mirror. You can turn these lights on and off from the switches in the mirror or from the dimmer control in the multifunction lever. These lights are also controlled automatically by the Illuminated Entry Sys- tem.
Page 186: Battery Saver Feature
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Battery Saver Feature To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on because a door is open.
Page 187: Intermittent Wiper System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 CAUTION! • Turn the windshield wipers off when driving through an automatic car wash. Damage to the windshield wipers may result if the wiper control is left in any position other than off. •...
Page 188: Windshield Washers
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE regulate the wipe interval from a minimum of one cycle Windshield Washers every second to a maximum of approximately 18 seconds To use the washer, pull the windshield wiper/washer between cycles. control lever toward you and hold it for as long as washer spray is desired.
Page 189: Mist Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 WARNING! (Continued) the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use. Mist Feature Push down on the wiper control lever to activate a single wipe to clear the windshield of road mist or spray from a passing vehicle.
Page 190: Tilt/Telescoping Steering Column
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE column) is placed in the AUTO position. In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature. The headlights with wipers feature can be turned on or off through the Electronic Vehicle Information Center (EVIC) —...
Page 191: Electronic Speed Control - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 column in position, pull the lever upward until fully engaged. WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle.
Page 192: To Activate
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the same time. If this occurs, the Electronic Speed Control To Set A Desired Speed System can be reactivated by pushing the Electronic Turn the Electronic Speed Control ON. When the vehicle Speed Control ON/OFF button and resetting the desired has reached the desired speed, press the SET (-) button vehicle set speed.
Page 193: To Resume Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 To Resume Speed decrease until the button is released. Release the button when the desired speed is reached, and the new set speed To resume a previously set speed, push the RES (+) will be established.
Page 194: Garage Door Opener - If Equipped
192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On steep hills, a greater speed loss or gain may occur so The HomeLink® buttons, located on either the overhead it may be preferable to drive without Electronic Speed console, headliner or sunvisor, designate the three differ- Control.
Page 195: Before You Begin Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 For more efficient programming and accurate transmis- sion of the radio-frequency signal it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink® system.
Page 196: Programming A Rolling Code
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manu- factured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener.
Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) 5. At the garage door opener motor (in the garage), away from the HomeLink® button you wish to pro- locate the “LEARN” or “TRAINING” button. This can gram while keeping the HomeLink®...
Page 198: Programming A Non-Rolling Code
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To program the remaining two HomeLink® buttons, Programming A Non-Rolling Code repeat each step for each remaining button. DO NOT For programming Garage Door Openers manufactured erase the channels. before 1995. Reprogramming A Single HomeLink® Button 1.
Page 199: Canadian/Gate Operator Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 5. Press and hold the programmed HomeLink® button 3. Without releasing the button proceed with “Program- and observe the indicator light. ming A Non-Rolling Code” Step 2 and follow all • If the indicator light stays on constantly, program- remaining steps.
Page 200 198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If the indicator light stays on constantly, program- 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you wish to pro- ming is complete and the garage door/device should gram while keeping the HomeLink®...
Page 201: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 3. Without releasing button proceed with The HomeLink® Universal Transceiver is disabled when “Canadian/Gate Operator Programming” Step 2 and the Vehicle Security Alarm is active. follow all remaining steps. Troubleshooting Tips Using HomeLink® If you are having trouble programming HomeLink®, To operate, press and release the programmed here are some of the most common solutions:...
Page 202: General Information
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information WARNING! This device complies with FCC rules Part 15 and Industry • Your motorized door or gate will open and close Canada RSS-210. Operation is subject to the following while you are programming the universal trans- two conditions: ceiver.
Page 203: Electrical Power Outlets
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 • The term IC before the certification/registration num- ber only signifies that Industry Canada technical speci- fications were met. ELECTRICAL POWER OUTLETS There are two 12 Volt (13 Amp) electrical power outlets on this vehicle. Both of the power outlets are protected by a fuse.
Page 204 202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE A second power outlet is located inside the center con- NOTE: To ensure proper operation a MOPAR® knob sole. and element must be used. CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts.
Page 205 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 206: Cigar Lighter And Ash Receiver - If Equipped
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — IF CAUTION! EQUIPPED • Many accessories that can be plugged in draw An optional ash receiver is available from your autho- power from the vehicle’s battery, even when not in rized dealer and will fit in the center console front use (i.e., cellular phones, etc.).
Page 207: Rear Seat Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 Front Cupholders Rear Cupholders Rear Seat Cupholders WARNING! Cupholders for the rear seat occupants are located in the If containers of hot liquid are place in the cupholder, armrests. Each cupholder is capable of holding up to a 20 they can spill when the door is closed, burning the oz.
Page 208: Storage
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Glovebox Storage Compartment The glovebox storage compartment is located on the right side of the instrument panel. To open the glovebox, pull outward on the latch handle located on the front of the glovebox.
Page 209 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 comfort. The center console can be used for storage and is also equipped with an electrical power outlet. Refer to “Power Outlets” in “Understanding The Feature of Your Vehicle” for further information. Center Console Storage The top compartment holds small items, such as a pen and note pad, while the larger bottom compartment will hold CDs and alike.
Page 210: Cargo Area Features
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: CARGO AREA FEATURES • A notch in the front of the console base allows for use The 60/40 split-folding rear seat provides cargo-carrying versatility. The seatbacks fold down easily by pulling of a cellular phone while it is plugged into the power nylon tabs between the seatbacks and the bolsters.
Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 Always place cargo evenly on the cargo floor. Put heavier WARNING! (Continued) objects as low and as far forward as possible. Place as • The cargo area in the rear of the vehicle (with the much cargo as possible in front of the rear axle.
Page 212: Ski Pass-Through
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ski Pass-Through REAR WINDOW FEATURES There is a ski pass-through door located behind the rear Rear Window Defroster seat armrest that allows longer items, such as snow skis, to be stored in the rear cargo area. Lower the armrest and The rear window defroster button is located on pull downward on the latch to open the ski pass-through the climate control (Mode) knob.
Page 213 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ EVIC Main Menu .....239 INSTRUMENT PANEL FEATURES ..216 ▫...
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL SETTING THE ANALOG CLOCK ...247 Uconnect® 130 WITH SATELLITE RADIO ..257 ▫ Operating Instructions — Radio Mode..257 Uconnect®...
Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 ▫ Controlling The iPod® Or External USB Device CD/DVD DISC MAINTENANCE ...282 Using Radio Buttons ....275 RADIO OPERATION AND MOBILE PHONES .
Page 218: Instrument Panel Features
216 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 6 — Radio 11 — Storage Compartment 2 — Side Window Demister Outlet 7 — Passenger Airbag 12 — Climate Control 3 — Instrument Cluster 8 — Glove Compartment 13 —...
Page 219: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 217 INSTRUMENT CLUSTER...
Page 220: Instrument Cluster Descriptions
218 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS removes this heat. You can also turn the Temperature control to maximum heat, the Mode control to Floor and 1. Temperature Gauge the Fan control to High. This allows the heater core to act The temperature gauge shows engine coolant tempera- as a supplement to the radiator and aids in removing heat ture.
Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 5. Low Fuel Light If jump starting is required, refer to “Jump Starting Procedures” in “What To Do In Emergencies”. When the fuel level drops to approximately 2.0 7. Air Bag Warning Light gallons (7.6 Liters), the fuel symbol will light and a single chime will sound.
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL flash or remain on continuously. Refer to “Occupant 10. Engine Temperature Warning Light Restraints” in “Things To Know Before Starting Your This light warns of an overheated engine condi- Vehicle” for further information. tion. As engine coolant temperatures rise and the 9.
Page 223 UNDERSTANDING YOUR INSTRUMENT PANEL 221 11. Brake Warning Light If brake failure is indicated, immediate repair is neces- sary. This light monitors various brake functions, including brake fluid level and parking brake WARNING! application. If the brake light turns on it may indicate that the parking brake is applied, that Driving a vehicle with the brake light on is danger- the brake fluid level is low, or that there is a problem with...
Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL off unless the parking brake is applied or a brake fault is NOTE: You must apply the brakes before shifting from detected. If the light does not illuminate, have the light PARK. inspected by an authorized dealer. 14.
Page 225 UNDERSTANDING YOUR INSTRUMENT PANEL 223 The two trip odometers show individual trip mileage. To switch from odometer to trip odometers, press and SET CARgO SHIELd ..The Convertible Top Cargo Shield Must Be Put In The Stowed Position release the Trip Odometer button.
Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If the instrument cluster is equipped with the HOTOIL optional Electronic Vehicle Information Center (EVIC), When this message is displayed there is a engine oil then all warnings including ”Low Tire,” “Door Ajar” and over-temperature condition.
Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 225 the problem continues, the message will appear the next the oil change indicator system (after performing the time the vehicle is started. See your authorized dealer scheduled maintenance) perform the following proce- service center as soon as possible. dure: CHANgE OIL 1.
Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL 15. Cruise Indicator — If Equipped 17. Electronic Throttle Control (ETC) Indicator Light This indicator shows that the Electronic Speed This light informs you of a problem with the Control System is ON. Electronic Throttle Control (ETC) system. If a problem is detected, the light will come on 16.
Page 229 UNDERSTANDING YOUR INSTRUMENT PANEL 227 18. Park/Headlight ON Indicator — If Equipped 21. Front Fog Light Indicator — If Equipped This indicator will illuminate when the park This indicator will illuminate when the front fog lights or headlights are turned on. lights are on.
Page 230 228 UNDERSTANDING YOUR INSTRUMENT PANEL the conventional brake system will continue to operate running, a malfunction has been detected in the ESC normally provided that the BRAKE warning light is not on. system. If this light remains on after several ignition cycles, and the vehicle has been driven several miles If the ABS light is on, the brake system should be serviced (kilometers) at speeds greater than 30 mph (48 km/h), see...
Page 231 UNDERSTANDING YOUR INSTRUMENT PANEL 229 • The ESC system will make buzzing or clicking sounds Accordingly, when the low tire pressure telltale illumi- when it is active. This is normal; the sounds will stop nates, you should stop and check your tires as soon as when ESC becomes inactive following the maneuver possible, and inflate them to the proper pressure.
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL illuminated. This sequence will continue upon subse- CAUTION! (Continued) quent vehicle start-ups as long as the malfunction exists. equipped on your vehicle. Undesirable system opera- When the malfunction indicator is illuminated, the sys- tion or sensor damage may result when using re- tem may not be able to detect or signal low tire pressure placement equipment that is not of the same size, as intended.
Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 Certain conditions, such as a loose or missing gas cap, WARNING! poor fuel quality, etc., may illuminate the light after engine start. The vehicle should be serviced if the light A malfunctioning catalytic converter, as referenced stays on through several of your typical driving cycles.
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL NEUTRAL and run the engine at idle or faster until the 28. High Beam Indicator light turns off. This light indicates that the headlights are on high beam. Pull the turn signal lever toward the steer- CAUTION! ing wheel to switch the headlights to low beam.
Page 235: Mini-Trip Computer - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 233 MINI-TRIP COMPUTER — IF EQUIPPED Control Buttons The Mini-Trip Computer is located in the instrument cluster and features a driver-interactive trip information and temperature display. NOTE: The system will display the last known outside temperature when starting the vehicle and may need to be driven several minutes before the updated tempera- ture is displayed.
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL RESET Button Trip A To reset the display shown, turn the ignition switch to the Shows the total distance traveled for Trip A since the last ON position, then press and hold the RESET button reset.
Page 237: Electronic Vehicle Information Center (Evic) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 235 ELECTRONIC VEHICLE INFORMATION CENTER The EVIC consists of the following: (EVIC) — IF EQUIPPED • Compass Heading Display (N, S, E, W, NE, NW, SE, The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the •...
Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL • MENU Button The system allows the driver to select information by pressing the following buttons mounted on the steering Press and release the MENU button to advance wheel: the display to each of the EVIC Main Menu features.
Page 239: Electronic Vehicle Information Center (Evic) Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 237 • SELECT Button • RKE (Remote Keyless Entry) Battery Low (with a single chime) Press and release the SELECT Button to accept • Personal Settings Not Avail – Vehicle Not in Park a selection. The SELECT Button also resets various Trip Functions.
Page 240: Oil Change Required - If Equipped
238 UNDERSTANDING YOUR INSTRUMENT PANEL • Remote start aborted — Hood ajar • Check TPM System (with a single chime) Refer to Tire Pressure Monitoring System in Starting and Operat- • Remote start aborted — Trunk ajar ing . • Remote start aborted — Fuel low Oil Change Required —...
Page 241: Evic Main Menu
UNDERSTANDING YOUR INSTRUMENT PANEL 239 • Average Fuel Economy 1. Turn the ignition switch to the ON position (Do not start the engine.) • Distance to Empty 2. Fully depress the accelerator pedal slowly three times • Tire Pressure Status display within 10 seconds.
Page 242 240 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The system will display the last known outside Manual Compass Calibration temperature when starting the vehicle and may need to If the compass appears erratic or inaccurate, and the be driven several minutes before the updated tempera- variance has been properly set, you may wish to manu- ture is displayed.
Page 243 UNDERSTANDING YOUR INSTRUMENT PANEL 241 large metal or metallic objects) until the “CAL” indi- cator turns off. The compass will now function nor- mally. Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences, the variance should be set for the zone where the vehicle is driven, per the zone map.
Page 244: Average Fuel Economy
242 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press and release the DOWN button until “Compass Distance To Empty (DTE) Variance” and the current Variance Value displays in Shows the estimated distance that can be traveled with the EVIC. the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous 4.
Page 245: Tire Psi
UNDERSTANDING YOUR INSTRUMENT PANEL 243 Tire PSI Elapsed Time Press and release the MENU button until Tire PSI is Shows the total elapsed time of travel since the last reset. displayed. Elapsed time will increment when the ignition switch is in the RUN or START position.
Page 246: Evic Units Selection (Units In Display)
244 UNDERSTANDING YOUR INSTRUMENT PANEL EVIC Units Selection (UNITS IN Display) Personal Settings (Customer-Programmable Features) Displays the units used for the Outside Temperature, Average Fuel Economy, Distance to Empty and Tire Personal Settings allows the driver to set and recall Pressure features.
Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 Auto Unlock On Exit Flash Lamp with LOCK When ON is selected and the transaxle is in the PARK or When ON is selected, the front and rear turn signals will NEUTRAL position, all doors will unlock when the flash when the doors are locked or unlocked with the driver’s door is opened.
Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL headlights will also turn off when the wipers are turned Illumin. Approach off if they were turned on by this feature. To make your When this feature is selected, the headlights will activate selection, press the SELECT button until ON or OFF and remain on for up to 90 seconds when the doors are appears.
Page 249: Setting The Analog Clock
UNDERSTANDING YOUR INSTRUMENT PANEL 247 SETTING THE ANALOG CLOCK Uconnect® 730N/430/430N CD/DVD/HDD/NAV — IF EQUIPPED To set the analog clock, located at the top center of the instrument panel, press and hold the button in until the Refer to your Uconnect® Supplement Manual for de- setting is correct.
Page 250: Uconnect® 130
248 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® 130 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping.
Page 251 UNDERSTANDING YOUR INSTRUMENT PANEL 249 another selection. Holding either button will bypass 5. To exit, press any button/knob, or wait five seconds. stations without stopping, until you release it. RW/FF TIME Button Pressing the RW (Rewind) or FF (Fast Forward) buttons Press the TIME button to alternate display of the time causes the tuner to search for the next frequency in the and radio frequency.
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the AM/FM Button mid-range tones.
Page 253: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 251 display window. Each button can be set for SET 1 and Operation Instructions — CD MODE For CD And SET 2 in both AM and FM. This allows a total of 12 AM MP3 Audio Play and 12 FM stations to be stored into pushbutton memory.
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio CAUTION! (Continued) ON, the unit will switch from radio to CD mode and • Dual-media disc types (one side is a DVD, the begin to play when you insert the disc.
Page 255: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 253 SEEK Button AM/FM Button Press the right SEEK button for the next selection on the Press the button to select either AM or FM mode. CD. Press the left SEEK button to return to the beginning SET/RND Button (Random Play Button) of the current selection, or return to the beginning of the Press this button while the CD is playing to activate...
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Media (Disc Types) display the file name and folder name, and will assign a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 257 UNDERSTANDING YOUR INSTRUMENT PANEL 255 Supported MP3 File Formats MPEG Sampling Fre- Bit Rate (kbps) Specification quency (kHz) The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 MPEG-1 Audio 48, 44.1, 32 320, 256, 224, extension may cause playback problems.
Page 258: Operation Instructions - Auxiliary Mode
256 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a When a medium containing MP3 data is loaded, the single-session disc, enable the “Disc at Once” option radio checks all files on the medium.
Page 259: Uconnect® 130 With Satellite Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 257 TIME Button (Auxiliary Mode) Operating Instructions — Radio Mode Press this button to change the display to time of day. The NOTE: The ignition switch must be in the ON or ACC time of day will display for five seconds (when ignition is position to operate the radio.
Page 260 258 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With Press and release the SEEK buttons to search for the next Uconnect Phone” message will display on the radio listenable station in AM/FM mode.
Page 261 UNDERSTANDING YOUR INSTRUMENT PANEL 259 Clock Setting Procedure starting at Step 2. For vehicles not equipped with satellite radio, press the SETUP button and then follow the above 1. Press and hold the TIME button until the hours blink. procedure, starting at Step 2. 2.
Page 262 260 UNDERSTANDING YOUR INSTRUMENT PANEL Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob a fifth time and FADE will display. Turn the TUNE/SCROLL control Push the rotary TUNE/SCROLL control knob and BASS knob to the left or right to adjust the sound level between will display.
Page 263 UNDERSTANDING YOUR INSTRUMENT PANEL 261 16-Digit Character 16-Digit Character Program Type Program Type Display Display No program type or un- None Public Public defined Rhythm and Blues R & B Adult Hits Adlt Hit Religious Music Rel Musc Classical Classicl Religious Talk Rel Talk Classic Rock...
Page 264 262 UNDERSTANDING YOUR INSTRUMENT PANEL station with the same selected Music Type name. The AM/FM Button Music Type function only operates when in the FM Press the button to select either AM or FM mode. mode. SET/RND Button — To Set the Pushbutton If a preset button is activated while in the Music Type Memory (Program Type) mode, the Music Type mode will be...
Page 265: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 263 and 12 FM stations to be stored into pushbutton memory. Operation Instructions — CD MODE for CD and The stations stored in SET 2 memory can be selected by MP3 Audio Play pressing the pushbutton twice. NOTE: Every time a preset button is used, a corresponding •...
Page 266 264 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio CAUTION! (Continued) ON, the unit will switch from radio to CD mode and • Dual-media disc types (one side is a DVD, the begin to play when you insert the disc.
Page 267: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 265 SEEK Button AM/FM Button Press the right SEEK button for the next selection on the Press the button to select either AM or FM mode. CD. Press the left SEEK button to return to the beginning SET/RND Button (Random Play Button) of the current selection, or return to the beginning of the Press this button while the CD is playing to activate...
Page 268 266 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Media (Disc Types) display the file name and folder name, and will assign a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 269 UNDERSTANDING YOUR INSTRUMENT PANEL 267 Supported MP3 File Formats MPEG Sampling Fre- Bit Rate (kbps) Specification quency (kHz) The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 MPEG-1 Audio 48, 44.1, 32 320, 256, 224, extension may cause playback problems.
Page 270: List Button (Cd Mode For Mp3 Play)
268 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a When a medium containing MP3 data is loaded, the single-session disc, enable the “Disc at Once” option radio checks all files on the medium.
Page 271: Uconnect® (Satellite Radio) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 269 Press the INFO button once more to return to elapsed AUX audio sounds distorted, turn the device’s volume time priority mode. down. Press and hold the INFO button for three seconds or TIME Button (Auxiliary Mode) more and the radio will display song titles for each file.
Page 272 270 UNDERSTANDING YOUR INSTRUMENT PANEL System Activation To access the ESN/SID, refer to the following steps: Sirius Satellite Radio service is pre-activated, and you ESN/SID Access may begin listening immediately to the one year of audio With the ignition switch in the ON/RUN or ACC posi- service that is included with the factory-installed satellite tion and the radio on, press the SETUP button and scroll radio system in your vehicle.
Page 273 UNDERSTANDING YOUR INSTRUMENT PANEL 271 decreased performance. Larger luggage items such as Operating Instructions - Uconnect® (Satellite) bikes should be placed as far rearward as possible, within Mode the loading design of the rack. Do not place items directly NOTE: The ignition switch must be in the ON/RUN or on or above the antenna.
Page 274 272 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button MUSIC TYPE Button Pressing the INFO button will cycle the display informa- Pressing this button once will turn on the Music Type tion between Artist, Song Title, and Composer (if avail- mode for five seconds. Pressing the MUSIC TYPE button able).
Page 275: Ipod®/Usb/Mp3 Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 273 • Display Sirius ID number — Press the AUDIO/ pushbutton memory. The channels stored in SET 2 SELECT button to display the Sirius ID number. This memory can be selected by pressing the pushbutton number is used to activate, deactivate, or change the twice.
Page 276: Connecting The Ipod® Or External Usb Device
274 UNDERSTANDING YOUR INSTRUMENT PANEL iPod® control supports Mini, 4G, Photo, Nano, 5G iPod® and iPhone® devices. Some iPod® software versions may not fully support the iPod® control features. Please visit Apple’s website for software updates. NOTE: • If the radio has a USB port, refer to the appropriate Uconnect®...
Page 277: Using This Feature
UNDERSTANDING YOUR INSTRUMENT PANEL 275 NOTE: If the audio device battery is completely dis- Controlling The iPod® Or External USB Device charged, it may not communicate with the iPod®/USB/ Using Radio Buttons MP3 control system until a minimum charge is attained. To get into the iPod®/USB/MP3 control mode and Leaving the audio device connected to the iPod®/USB/ access a connected audio device, either press the “AUX”...
Page 278 276 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it clockwise (forward) by one click, while during play mode will jump to the next track in the playing a track, skips to the next track or press the list, or press the VR button and say Next or Previous VR button and say Next Track.
Page 279: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 277 • Turning it clockwise (forward) and counterclockwise SCAN button again. During Scan mode, pressing the << SEEK and SEEK>> buttons will select the previous (backward) scrolls through the lists, displaying the and next tracks. track detail on the radio display. Once the track to be played is highlighted on the radio display, press the •...
Page 280 278 UNDERSTANDING YOUR INSTRUMENT PANEL • Preset 4 – Genres • MUSIC TYPE button: The MUSIC TYPE button is • Preset 5 – Audiobooks another shortcut button to the genre listing on your audio device. • Preset 6 – Podcasts •...
Page 281: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 279 device first, then it will get streamed to the Uconnect® WARNING! phone system. Seven devices can be paired to the Uconnect® phone system, but just one can be selected Do not plug in or remove the iPod® or external USB and played.
Page 282: Steering Wheel Audio Controls - If Equipped
280 UNDERSTANDING YOUR INSTRUMENT PANEL Previous Track STEERING WHEEL AUDIO CONTROLS — IF EQUIPPED Use the SEEK DOWN button, or press the VR button on the radio and say “Previous Track,” to jump to the previous music track on your cellular phone. Browse Browsing is not available on a Bluetooth Streaming Audio (BTSA) device.
Page 283: Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 281 The remote sound system controls are located on the rear Radio Operation surface of the steering wheel, at the three and nine Pressing the top of the switch will SEEK up for the next o’clock positions. listenable station, and pressing the bottom of the switch will SEEK down for the next listenable station.
Page 284: Cd/Dvd Disc Maintenance
282 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD DISC MAINTENANCE NOTE: If you experience difficulty in playing a particular disc, it may be damaged (i.e., scratched, reflective coating To keep a CD/DVD in good condition, take the following removed, a hair, moisture or dew on the disc) oversized, precautions: or have protection encoding.
Page 285: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 283 CLIMATE CONTROLS The Manual Temperature Controls consist of a series of outer rotary dials and inner push knobs. The air conditioning and heating system is designed to make you comfortable in all types of weather. Blower Control Manual Heating And Air Conditioning Rotate this control to regulate the...
Page 286 284 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Air Conditioning Control Press this button to engage the Air Con- Rotate this control to regulate the tem- ditioning. A light will illuminate when perature of the air inside the passenger the Air Conditioning system is engaged. compartment.
Page 287 UNDERSTANDING YOUR INSTRUMENT PANEL 285 select Panel, Bi-Level or Floor mode and move the NOTE: The center instrument panel outlets can be aimed temperature control to the desired temperature. so that they are directed toward the rear seat passengers for maximum airflow to the rear. Mode Control (Air Direction) •...
Page 288 286 UNDERSTANDING YOUR INSTRUMENT PANEL • Mix • Recirculation Control Air is directed through the floor, defrost, and side Pressing the Recirculation Control button will window demist outlets. This setting works best in temporarily put the system in recirculation cold or snowy conditions that require extra heat to the mode.
Page 289: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 287 • The A/C will engage automatically to prevent fogging Automatic Temperature Control (ATC) — If when the recirculation button is pressed and the mode Equipped control is set to panel or Bi-Level. • Recirculated air is not allowed in Defrost modes. If the Recirculation button is pressed while in Defrost mode, the LED indicator will flash several times then go out.
Page 290 288 UNDERSTANDING YOUR INSTRUMENT PANEL Operation of the system is quite simple. the “O” (OFF) position on the blower control stops the system completely and closes the outside air intake. 1. Turn the Mode Control knob (on the right) and the Blower Control knob (on the left) to AUTO 72°F (22°C) is the recommended setting for maximum comfort for the average person;...
Page 291 UNDERSTANDING YOUR INSTRUMENT PANEL 289 the radiator and through the condenser. Fabric front Manual Operation fascia protectors may reduce airflow to the condenser, This system offers a full complement of manual override reducing air conditioning performance. features, which consist of Blower Preferred Automatic, •...
Page 292 290 UNDERSTANDING YOUR INSTRUMENT PANEL...
Page 293 UNDERSTANDING YOUR INSTRUMENT PANEL 291 • Floor The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and •...
Page 294 292 UNDERSTANDING YOUR INSTRUMENT PANEL • Air Conditioner Control NOTE: • When the ignition switch is turned to the LOCK Press this button to turn on the air conditioning during manual operation position, the recirculation feature will be cancelled. only. When the air conditioning is •...
Page 295: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 293 • Most of the time, when in Automatic Operation, you Blower Control can temporarily put the system into Recirculation Mode by pressing the Recirculation button. However, For full automatic operation or for under certain conditions, while in Automatic Mode, automatic blower operation, turn the the system is blowing air out the defrost vents.
Page 296 294 UNDERSTANDING YOUR INSTRUMENT PANEL coolant that meets the requirements of Chrysler Material Window Fogging Standard MS-12106 and 50% water is recommended. Interior fogging on the windshield can be quickly re- Refer to “Maintenance Procedures” in “Maintaining Your moved by turning the mode selector to Defrost. The Mix Vehicle”...
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 Side Window Demisters A/C Air Filter — If Equipped A side window demister outlet is located at each end of The A/C Filter prevents most dust and pollen from the instrument panel. These non-adjustable outlets direct entering the cabin.
Page 298 296 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...
Page 299: Starting And Operating
STARTING AND OPERATING CONTENTS ▫ Four-Speed Automatic Transmission — If STARTING PROCEDURES ....301 Equipped ......305 ▫...
Page 300 298 STARTING AND OPERATING ▫ ESC Activation/Malfunction Indicator Light And DRIVING THROUGH WATER ... . .322 ESC OFF Indicator Light ....336 ▫...
Page 301 STARTING AND OPERATING 299 ▫ Run Flat Tires – If Equipped ....354 FUEL REQUIREMENTS ....370 ▫...
Page 302 300 STARTING AND OPERATING ▫ Fuel Requirements ....376 ▫ Gross Vehicle Weight Rating (GVWR) ..382 ▫...
Page 303: Starting Procedures
STARTING AND OPERATING 301 STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the • Do not leave the key fob in or near the vehicle, or inside and outside mirrors, fasten your seat belt, and if in a location accessible to children, and do not present, instruct all other occupants to buckle their seat leave the ignition of a vehicle equipped with...
Page 304: Extreme Cold Weather (Below -20°F Or −29°C)
302 STARTING AND OPERATING Tip Start ENGINE BLOCK HEATER — IF EQUIPPED Do not press the accelerator. Turn the ignition key briefly The engine block heater warms the engine, and permits to START position, and release it. The starter motor will quicker starts in cold weather.
Page 305: Automatic Transmission
STARTING AND OPERATING 303 AUTOMATIC TRANSMISSION WARNING! • It is dangerous to shift out of PARK or NEUTRAL CAUTION! if the engine speed is higher than idle speed. If Damage to the transmission may occur if the follow- your foot is not firmly pressing the brake pedal, the ing precautions are not observed: vehicle could accelerate quickly forward or in re- •...
Page 306: Key Ignition Park Interlock
304 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure • Never leave children alone in a vehicle, or with those in and near the vehicle. As with all vehicles, access to an unlocked vehicle. Allowing children to you should never exit a vehicle while the engine is be in a vehicle unattended is dangerous for a running.
Page 307: Brake/Transmission Shift Interlock System
STARTING AND OPERATING 305 when the ignition is in the LOCK position, and once Four-Speed Automatic Transmission — If removed, the transmission is locked in PARK. Equipped The transmission gear position display (located in the NOTE: If a malfunction occurs, the system will trap the instrument cluster) indicates the transmission gear range.
Page 308 306 STARTING AND OPERATING Gear Ranges the transmission locking mechanism may make it diffi- cult to move the shift lever out of PARK. As an added DO NOT race the engine when shifting from PARK or precaution, turn the front wheels toward the curb on a NEUTRAL into another gear range.
Page 309 STARTING AND OPERATING 307 WARNING! (Continued) WARNING! (Continued) • It is dangerous to shift out of PARK or NEUTRAL locked in PARK, securing the vehicle against un- if the engine speed is higher than idle speed. If wanted movement. • When leaving the vehicle, always remove the igni- your foot is not firmly pressing the brake pedal, the vehicle could accelerate quickly forward or in re- tion key and lock your vehicle.
Page 310 308 STARTING AND OPERATING • Look at the transmission gear position display and CAUTION! verify that it indicates the PARK position. • Before moving the shift lever out of PARK, you • With brake pedal released, verify that the shift lever must turn the ignition switch from the OFF posi- will not move out of PARK.
Page 311 STARTING AND OPERATING 309 DRIVE (D) WARNING! This range should be used for most city and highway Do not coast in NEUTRAL and never turn off the driving. It provides the smoothest upshifts and down- ignition to coast down a hill. These are unsafe shifts, and the best fuel economy.
Page 312 310 STARTING AND OPERATING During cold temperatures, transmission operation may will improve performance and extend transmission life be modified depending on engine and transmission by reducing excessive shifting and heat build-up. The 3 temperature as well as vehicle speed. This feature im- range should also be used when descending steep grades proves warm up time of the engine and transmission to to avoid brake system distress.
Page 313 STARTING AND OPERATING 311 PARK, REVERSE, and NEUTRAL will continue to oper- NOTE: Even if the transmission can be reset, we recom- ate. The Malfunction Indicator Light (MIL) may be illu- mend that you visit your authorized dealer at your minated.
Page 314: Six-Speed Automatic Transmission - If Equipped
312 STARTING AND OPERATING • the engine coolant has reached an adequate tempera- is not shifting into Overdrive when cold. This is normal. ture, Shifting between the DRIVE and 3 ranges, when the transmission is sufficiently warm, will demonstrate that •...
Page 315 STARTING AND OPERATING 313 Only shift from DRIVE to PARK or REVERSE when the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when shifting between these gears. The transmission shift lever has PARK, REVERSE, NEU- TRAL, DRIVE, and AutoStick®...
Page 316 314 STARTING AND OPERATING NOTE: After selecting any gear range, wait a moment to downhill grade and away from the curb on an uphill allow the selected gear to engage before accelerating. grade. This is especially important when the engine is cold. WARNING! PARK (P) •...
Page 317 STARTING AND OPERATING 315 WARNING! (Continued) WARNING! (Continued) • It is dangerous to shift out of PARK or NEUTRAL locked in PARK, securing the vehicle against un- if the engine speed is higher than idle speed. If wanted movement. • When leaving the vehicle, always remove the igni- your foot is not firmly pressing the brake pedal, the vehicle could accelerate quickly forward or in re- tion key and lock your vehicle.
Page 318 316 STARTING AND OPERATING • Look at the transmission gear position display and CAUTION! verify that it indicates the PARK position. • Before moving the shift lever out of PARK, you • With brake pedal released, verify that the shift lever must turn the ignition switch from the OFF posi- will not move out of PARK.
Page 319 STARTING AND OPERATING 317 DRIVE (D) WARNING! This range should be used for most city and highway Do not coast in NEUTRAL and never turn off the driving. It provides the smoothest upshifts and down- ignition to coast down a hill. These are unsafe shifts, and the best fuel economy.
Page 320 318 STARTING AND OPERATING During cold temperatures, transmission operation may PARK, REVERSE, and NEUTRAL will continue to oper- be modified depending on engine and transmission ate. The Malfunction Indicator Light (MIL) may be illu- temperature as well as vehicle speed. This feature im- minated.
Page 321 STARTING AND OPERATING 319 • The engine coolant has reached an adequate tempera- NOTE: Even if the transmission can be reset, we recom- mend that you visit your authorized dealer at your ture. earliest possible convenience. Your authorized dealer has •...
Page 322: Autostick® - If Equipped
320 STARTING AND OPERATING is not shifting into Overdrive when cold. This is normal. gear being used. Moving the shift lever to the left (-) Using the AutoStick® shift control, when the transmis- triggers a downshift and to the right (+) an upshift. The sion is sufficiently warm, will demonstrate that the current gear will be displayed in the instrument cluster.
Page 323: Driving On Slippery Surfaces
STARTING AND OPERATING 321 • The transmission will automatically upshift when nec- AutoStick® position at any time without taking your foot essary to prevent engine over-speed. off the accelerator pedal. • If a requested downshift would cause the engine to WARNING! over-speed, that shift will not occur.
Page 324: Traction
322 STARTING AND OPERATING 2. Slow down if the road has standing water or puddles. WARNING! 3. Replace the tires when tread wear indicators first Rapid acceleration on slippery surfaces is dangerous. become visible. Unequal traction can cause sudden pulling of the 4.
Page 325: Flowing/Rising Water
STARTING AND OPERATING 323 Flowing/Rising Water CAUTION! • Always check the depth of the standing water WARNING! before driving through it. Never drive through Do not drive on or across a road or path where water standing water that is deeper than the bottom of is flowing and/or rising (as in storm run-off).
Page 326: Power Steering
324 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause damage • Driving through standing water limits your vehi- to your vehicle’s drivetrain components. Always cle’s traction capabilities. Do not exceed 5 mph inspect your vehicle’s fluids (i.e., engine oil, trans- (8 km/h) when driving through standing water.
Page 327 STARTING AND OPERATING 325 If for some reason the power assist is interrupted, it will WARNING! still be possible to steer your vehicle. Under these condi- tions, you will observe a substantial increase in steering Continued operation with reduced power steering effort, especially at very low vehicle speeds and during assist could pose a safety risk to yourself and others.
Page 328: Power Steering Fluid Check
326 STARTING AND OPERATING Power Steering Fluid Check WARNING! Checking the power steering fluid level at a defined Fluid level should be checked on a level surface and service interval is not required. The fluid should only be with the engine off to prevent injury from moving checked if a leak is suspected, abnormal noises are parts and to ensure accurate fluid level reading.
Page 329: Parking Brake
STARTING AND OPERATING 327 PARKING BRAKE possible. To release the parking brake, pull the lever up slightly, press the center button, then lower the lever Before leaving the vehicle, make sure that the parking completely. brake is fully applied. Also, be certain to leave the transmission in PARK.
Page 330 328 STARTING AND OPERATING from the curb on an uphill grade. Apply the parking WARNING! (Continued) brake before placing the shift lever in PARK, otherwise • Never leave children alone in a vehicle, or with the load on the transmission locking mechanism may access to an unlocked vehicle.
Page 331: Anti-Lock Brake System (Abs)
STARTING AND OPERATING 329 computer to modulate the hydraulic pressure to prevent WARNING! (Continued) wheel lock-up and avoid skidding on slippery surfaces. • Do not leave the key fob in or near the vehicle, or in a location accessible to children. A child could WARNING! operate power windows, other controls, or move •...
Page 332 330 STARTING AND OPERATING If the “Anti-Lock Brake Warning Light” is on, the brake WARNING! (Continued) system should be serviced as soon as possible to restore • The capabilities of an ABS-equipped vehicle must the benefits of anti-lock brakes. If the “Anti-Lock Brake never be exploited in a reckless or dangerous Warning Light”...
Page 333: Electronic Brake Control System
STARTING AND OPERATING 331 ABS is activated during braking under certain road or WARNING! stopping conditions. ABS-inducing conditions can in- clude ice, snow, gravel, bumps, railroad tracks, loose The Anti-Lock Brake System contains sophisticated debris, or panic stops. electronic equipment that may be susceptible to interference caused by improperly installed or high You also may experience the following when the brake output radio transmitting equipment.
Page 334: Anti-Lock Brake System (Abs)
332 STARTING AND OPERATING systems work together to enhance vehicle stability and WARNING! (Continued) control in various driving conditions and are commonly very slippery surfaces, or hydroplaning. The capa- referred to as ESC. bilities of an ABS-equipped vehicle must never be Anti-Lock Brake System (ABS) exploited in a reckless or dangerous manner which could jeopardize the user’s safety or the safety of...
Page 335: Brake Assist System (Bas)
STARTING AND OPERATING 333 This feature remains active even if TCS and ESC are in WARNING! the “Partial Off” mode. Refer to “Electronic Stability • The BAS cannot prevent the natural laws of phys- Control (ESC)” in this section of this manual. ics from acting on the vehicle, nor can it increase Brake Assist System (BAS) braking efficiency beyond that afforded by the...
Page 336 334 STARTING AND OPERATING the brake of the appropriate wheel to assist in counter- WARNING! (Continued) acting the over/under steer condition. Engine power nor can it increase the traction afforded by prevailing may also be reduced to help the vehicle maintain the road conditions.
Page 337 STARTING AND OPERATING 335 Full On This is the normal operating mode for ESC. Whenever the vehicle is started the ESC system will be in this mode. This mode should be used for almost all driving situa- tions. ESC should only be turned to “Partial Off” for specific reasons as noted below.
Page 338: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
336 STARTING AND OPERATING ESC Activation/Malfunction Indicator Light And WARNING! ESC OFF Indicator Light When in “Partial Off” mode, the TCS functionality of ESC (except for the limited slip feature described in The “ESC Activation/Malfunction Indicator the TCS section) has been disabled and the “ESC Off Light”...
Page 339 STARTING AND OPERATING 337 • The ESC system will make buzzing or clicking sounds flashes when TCS is active. If the “ESC Activation/ Malfunction Indicator Light” begins to flash during ac- when it is active. This is normal; the sounds will stop celeration, ease up on the accelerator and apply as little when ESC becomes inactive following the maneuver throttle as possible.
Page 340: Tire Safety Information
338 STARTING AND OPERATING TIRE SAFETY INFORMATION NOTE: Tire Markings • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 341 STARTING AND OPERATING 339 • Temporary spare tires are designed for temporary • High flotation tire sizing is based on U.S. design emergency use only. Temporary high pressure com- standards and it begins with the tire diameter molded pact spare tires have the letter “T” or “S” molded into into the sidewall.
Page 342 340 STARTING AND OPERATING EXAMPLE: R = Construction code — R means radial construction — D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol —...
Page 343: Tire Identification Number (Tin)
STARTING AND OPERATING 341 EXAMPLE: Load Identification: ..blank..= Absence of any text on the sidewall of the tire indicates a Standard Load (SL) tire Extra Load (XL) = Extra load (or reinforced) tire Light Load (LL) = Light load tire C, D, E, F, G = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load—...
Page 344 342 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation — This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 345: Tire Terminology And Definitions
STARTING AND OPERATING 343 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after Cold Tire Inflation Pressure the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 346: Tire Loading And Tire Pressure
344 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. B-Pillar Location for Tire And Loading Information Placard...
Page 347 STARTING AND OPERATING 345 Tire And Loading Information Placard This placard tells you important information about the: 1) Number of people that can be carried in the ve- hicle. 2) Total weight your vehicle can carry. 3) Tire size designed for your vehicle. 4) Told tire inflation pressures for the front, rear, and spare tires.
Page 348 346 STARTING AND OPERATING NOTE: Under a maximum loaded vehicle condition, Steps For Determining Correct Load Limit gross axle weight ratings (GAWRs) for the front and rear 1. Locate the statement “The combined weight of occu- axles must not be exceeded. For further information on pants and cargo should never exceed XXX lbs or GAWRs, vehicle loading, and trailer towing, refer to XXX kg”...
Page 349 STARTING AND OPERATING 347 5. Determine the combined weight of luggage and cargo NOTE: being loaded on the vehicle. That weight may not • The following table shows examples on how to calcu- safely exceed the available cargo and luggage load late total load, cargo/luggage, and towing capacities capacity calculated in Step 4.
Page 350 348 STARTING AND OPERATING...
Page 351: Tires - General Information
STARTING AND OPERATING 349 Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 352: Tire Inflation Pressures
350 STARTING AND OPERATING stability of the vehicle and can produce a feeling of WARNING! (Continued) sluggish response or over responsiveness in the steering. • Unequal tire pressures from one side of the vehicle NOTE: to the other can cause the vehicle to drift to the right or left.
Page 353 STARTING AND OPERATING 351 judgement when determining proper inflation. Tires Check tire pressures more often if subject to a wide range may look properly inflated even when they are under- of outdoor temperatures, as tire pressures vary with inflated. temperature changes. •...
Page 354: Tire Pressures For High Speed Operation
352 STARTING AND OPERATING Tire Pressures For High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds and WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 355: Tire Types
STARTING AND OPERATING 353 Consult an authorized tire dealer for tire repairs and Summer Or Three Season Tires – If Equipped additional information. Summer tires provide traction in both wet and dry Damaged Run Flat tires, or Run Flat tires that have conditions, and are not intended to be driven in snow or experienced a loss of pressure should be replaced imme- on ice.
Page 356: Run Flat Tires - If Equipped
354 STARTING AND OPERATING Snow tires generally have lower speed ratings than what Run Flat mode. A Run Flat mode occurs when the tire was originally equipped with your vehicle and should inflation pressure is of/or below 14 psi (96 kPa). Once a not be operated at sustained speeds over 75 mph Run Flat tire reaches the run flat mode it has limited (120 km/h).
Page 357 STARTING AND OPERATING 355 Compact Spare Tire – If Equipped CAUTION! The compact spare is for temporary emergency use only. Because of the reduced ground clearance, do not take You can identify if your vehicle is equipped with a your vehicle through an automatic car wash with a compact spare by looking at the spare tire description on compact, full size or limited-use temporary spare the Tire and Loading Information Placard located on the...
Page 358 356 STARTING AND OPERATING Do not install more than one compact spare tire and spare tire needs to be replaced. Since it is not the same as wheel on the vehicle at any given time. your original equipment tire, replace (or repair) the original equipment tire and reinstall on the vehicle at the WARNING! first opportunity.
Page 359: Tire Spinning
STARTING AND OPERATING 357 Tire Spinning WARNING! When stuck in mud, sand, snow, or ice conditions, do not Limited-use spares are for emergency use only. In- spin your vehicle’s wheels above 30 mph (48 km/h) or stallation of this limited-use spare tire affects vehicle for longer than 30 seconds continuously without stop- handling.
Page 360: Tread Wear Indicators
358 STARTING AND OPERATING Tread Wear Indicators These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth Tread wear indicators are in the original equipment tires becomes 1/16 in (2 mm). When the tread is worn to the to help you in determining when your tires should be tread wear indicators, the tire should be replaced.
Page 361: Replacement Tires
STARTING AND OPERATING 359 Information placard or the Vehicle Certification Label for WARNING! the size designation of your tire. The Load Index and Speed Symbol for your tire will be found on the original Tires and the spare tire should be replaced after six equipment tire sidewall.
Page 362: Tire Chains (Traction Devices)
360 STARTING AND OPERATING WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 363: Tire Rotation Recommendations
STARTING AND OPERATING 361 TIRE ROTATION RECOMMENDATIONS The suggested rotation method is the “rearward cross” shown in the following diagram. This rotation pattern The tires on the front and rear of your vehicle operate at does not apply to some directional tires that must not be different loads and perform different steering, driving, reversed.
Page 364: Tire Pressure Monitor System (Tpms)
362 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) also increase as the vehicle is driven - this is normal and there should be no adjustment for this increased pres- The Tire Pressure Monitor System (TPMS) will warn the sure. driver of a low tire pressure based on the vehicle recom- mended cold placard pressure.
Page 365 STARTING AND OPERATING 363 to be driven for up to 20 minutes above 15 mph CAUTION! (24 km/h) in order for the TPMS to receive this informa- • The TPMS has been optimized for the original tion. equipment tires and wheels. TPMS pressures and For example, your vehicle may have a recommended warning have been established for the tire size cold (parked for more than three hours) placard pressure...
Page 366: Base System
364 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, NOTE: and the TPMS will monitor the actual tire pressure in • The TPMS is not intended to replace normal tire care the tire. and maintenance, or to provide warning of a tire failure or condition.
Page 367 STARTING AND OPERATING 365 Tire Pressure Monitoring Low Pressure Warnings Check TPMS Warning The “Tire Pressure Monitoring Telltale Light” will flash The “Tire Pressure Monitoring Telltale Light” will on and off for 75 seconds and then remain on solid when illuminate in the instrument cluster, a LOW a system fault is detected.
Page 368: Premium System - If Equipped
366 STARTING AND OPERATING 5. Using wheels/tires not equipped with TPM sensors. 4. For each subsequent ignition key cycle, a chime will sound and the “Tire Pressure Monitoring Telltale NOTE: Light” will flash on and off for 75 seconds and then 1.
Page 369 STARTING AND OPERATING 367 monitor tire pressure levels. Sensors, mounted to each Tire Pressure Monitoring Low Pressure Warnings wheel as part of the valve stem, transmit tire pressure readings to the Receiver Module. The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster and a chime NOTE: It is particularly important for you to check the will sound when tire pressure is low in one or more of the...
Page 370 368 STARTING AND OPERATING The vehicle may need to be driven for up to 20 minutes 1. Jamming due to electronic devices or driving next to above 15 mph (24 km/h) in order for the TPMS to receive facilities emitting the same Radio Frequencies as the this information.
Page 371 STARTING AND OPERATING 369 The system still needs to be serviced as long as the 3. After driving the vehicle for up to 20 minutes above CHECK TPM SYSTEM message is displayed. 15 mph (24 km/h), the “Tire Pressure Monitoring Telltale Light”...
Page 372: General Information
370 STARTING AND OPERATING • This device must accept any interference received, 5. Once you repair or replace the original road tire, and reinstall it on the vehicle in place of the compact spare, including interference that may cause undesired op- the TPMS will update automatically.
Page 373: Reformulated Gasoline
STARTING AND OPERATING 371 Light spark knock at low engine speeds is not harmful to Reformulated gasolines contain oxygenates and are spe- your engine. However, continued heavy spark knock at cifically blended to reduce vehicle emissions and im- high speeds can cause damage and immediate service is prove air quality.
Page 374: E-85 Usage In Non-Flex Fuel Vehicles
372 STARTING AND OPERATING • Operate in a lean mode. CAUTION! (Continued) • OBD II “Malfunction Indicator Light” on. blends may result in starting and drivability prob- lems, damage critical fuel system components, cause • Poor engine performance. emissions to exceed the applicable standard, and/or •...
Page 375: Mmt In Gasoline
STARTING AND OPERATING 373 MMT In Gasoline Materials Added To Fuel MMT (Methylcyclopentadienyl Manganese Tricarbonyl) All gasoline sold in the United States is required to is a manganese-containing metallic additive that is contain effective detergent additives. Use of additional blended into some gasoline to increase octane. Gasoline detergents or other additives is not needed under normal blended with MMT provides no performance advantage conditions and they would result in additional cost.
Page 376: Carbon Monoxide Warnings
374 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to Carbon monoxide (CO) in exhaust gases is deadly. overheat. If you notice a pungent burning odor or Follow the precautions below to prevent carbon some light smoke, your engine may be out of tune monoxide poisoning:...
Page 377: Flexible Fuel (3.6L Engine Only) - If Equipped
STARTING AND OPERATING 375 WARNING! (Continued) • Guard against carbon monoxide with proper main- tenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. FLEXIBLE FUEL (3.6L ENGINE ONLY) —...
Page 378: Ethanol Fuel (E-85)
376 STARTING AND OPERATING WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury. Never have any smok- ing materials lit in or near the vehicle when remov- ing the fuel filler tube cap (gas cap) or filling the tank.
Page 379: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
Chrysler Group LLC engines. Use MOPAR® or an when the ambient temperature is below 32°F (0°C). equivalent oil meeting the specification MS-6395.
Page 380: Starting
378 STARTING AND OPERATING Starting Replacement Parts The characteristics of E-85 fuel make it unsuitable for use Many components in your Flexible Fuel Vehicle (FFV) are when ambient temperatures fall below 0°F (-18°C). In the designed to be compatible with ethanol. Always be sure range of 0°F (-18°C) to 32°F (0°C), you may experience an that your vehicle is serviced with correct ethanol com- increase in the time it takes for your engine to start, and...
Page 381: Adding Fuel
STARTING AND OPERATING 379 ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is behind the fuel filler door, on the left rear quarter panel of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.
Page 382 380 STARTING AND OPERATING After removing the gas cap, place the gas cap tether cable NOTE: If the gas cap is lost or damaged, be sure the over a hook on the inside of the fuel door. This keeps the replacement cap is for use with this vehicle.
Page 383: Loose Filler Cap Message
STARTING AND OPERATING 381 NOTE: WARNING! • Tighten the gas cap until you hear a “clicking” sound. • Never have any smoking materials lit in or near the This is an indication that the gas cap is tightened vehicle when the gas cap is removed or the tank is properly.
Page 384: Vehicle Loading
382 STARTING AND OPERATING • Type of Vehicle appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice • Month Day and Hour of Manufacture (MDH) in a row, the system will turn on the MIL. Resolving the The bar code allows a computer scanner to read the VIN.
Page 385: Overloading
STARTING AND OPERATING 383 Figure out the weight on the front and rear of the vehicle WARNING! separately. It is important that you distribute the load evenly over the front and rear axles. Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front Overloading can cause potential safety hazards and or rear GAWR.
Page 386: Trailer Towing
384 STARTING AND OPERATING TRAILER TOWING exceed the GVWR. Refer to “Vehicle Loading/Vehicle Certification Label” in “Starting and Operating” for In this section you will find safety tips and information further information. on limits to the type of towing you can reasonably do with your vehicle.
Page 387 STARTING AND OPERATING 385 evenly. Make sure that you do not exceed either front or Frontal Area rear GAWR. Refer to “Vehicle Loading/Vehicle Certifica- The frontal area is the maximum height multiplied by the tion Label” in “Starting and Operating” for further maximum width of the front of a trailer.
Page 388 386 STARTING AND OPERATING Trailer Hitch Classification Trailer Hitch Classification Definitions The following chart provides the industry standard for Class Max. Trailer Hitch In- the maximum trailer weight a given trailer hitch class can dustry Standards tow and should be used to assist you in selecting the Class I - Light Duty 2,000 lbs (907 kg) correct trailer hitch for your intended towing condition.
Page 389 STARTING AND OPERATING 387 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Max. Gross Trailer Wt. Max. Trailer Tongue Wt. Engine/Transmission Max. Frontal Area (GTW) (See Note 1) 2.4L/Auto 11 sq.ft.
Page 390 388 STARTING AND OPERATING Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 391 STARTING AND OPERATING 389 NOTE: Remember that everything put into or on the CAUTION! (Continued) trailer adds to the load on your vehicle. Also, additional • Then, during the first 500 miles (805 km) that a factory-installed options or dealer-installed options must trailer is towed, do not drive over 50 mph (80 km/h) be considered as part of the total load on your vehicle.
Page 392 390 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Vehicles with trailers should not be parked on a • Make certain that the load is secured in the trailer grade. When parking, apply the parking brake on and it will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts the tow vehicle.
Page 393 STARTING AND OPERATING 391 Towing Requirements – Tires replacement procedures. Replacing tires with a higher load carrying capacity will not increase the vehicle’s • Do not attempt to tow a trailer while using a compact GVWR and GAWR limits. spare tire. Towing Requirements –...
Page 394 392 STARTING AND OPERATING CAUTION! WARNING! (Continued) • Towing any trailer will increase your stopping If the trailer weighs more than 1,000 lbs (454 kg) distance. When towing you should allow for addi- loaded, it should have its own brakes and they tional space between your vehicle and the vehicle should be of adequate capacity.
Page 395 STARTING AND OPERATING 393 Automatic Transmission NOTE: Check the transmission fluid level (four-speed transmission only) before towing. The six-speed trans- The DRIVE range can be selected when towing. How- mission does not require a fluid level check before ever, if frequent shifting occurs while in DRIVE, select the towing.
Page 396 394 STARTING AND OPERATING Electronic Speed Control – If Equipped City Driving • Do not use in hilly terrain or with heavy loads. When stopped for short periods of time, shift the trans- mission into NEUTRAL and increase engine idle speed. •...
Page 397: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 395 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground All Models Flat Tow NONE NOT ALLOWED Dolly Tow Front Rear NOT ALLOWED On Trailer Recreational Towing – All Models 3.
Page 398 396 STARTING AND OPERATING CAUTION! • DO NOT flat tow this vehicle. Damage to the drivetrain will result. • Towing this vehicle in violation of the above re- quirements can cause severe transmission damage. Damage from improper towing is not covered un- der the New Vehicle Limited Warranty.
Page 399: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS ▫ Road Tire Installation ....408 HAZARD WARNING FLASHERS ...398 IF YOUR ENGINE OVERHEATS .
Page 400: Hazard Warning Flashers
398 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel, below the radio. potential for overheating by taking the appropriate ac- tion.
Page 401: Engine Oil Overheating - 2.4L Engine Only (If Equipped)
WHAT TO DO IN EMERGENCIES 399 supplement to the radiator and aids in removing heat WARNING! (Continued) from the engine cooling system. you see or hear steam coming from under the hood, do not open the hood until the radiator has had time CAUTION! to cool.
Page 402: Jacking And Tire Changing
400 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! (Continued) • The jack is designed to be used as a tool for WARNING! changing tires only. The jack should not be used to • Do not attempt to change a tire on the side of the lift the vehicle for service purposes.
Page 403: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 401 Spare Tire Removal Preparations For Jacking Lift up the load floor cover and remove the hold down. 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic, pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 404: Jacking Instructions
402 WHAT TO DO IN EMERGENCIES 6. Block both the front and rear of the wheel diagonally WARNING! (Continued) opposite the jacking position. For • Always park on a firm, level surface as far from the example, if changing the right front edge of the roadway as possible before raising the tire, block the left rear wheel.
Page 405 WHAT TO DO IN EMERGENCIES 403 WARNING! (Continued) CAUTION! • Only use the jack in the positions indicated and for Do not attempt to raise the vehicle by jacking on lifting this vehicle during a tire change. locations other than those indicated in the Jacking •...
Page 406 404 WHAT TO DO IN EMERGENCIES 3. There is a front and rear jacking location on each side of the vehicle. The plastic trim has been cut away to expose the jacking locations on the body. Removing Jack H3andle From Jack 2.
Page 407 WHAT TO DO IN EMERGENCIES 405 Rear Jacking Location Jack Engaged (Front Jacking Location) 4. Turn the jack screw to the left until the jack can be placed under the jacking location. Once the jack is positioned, turn the jack screw to the right until the jack head is properly engaged to the jacking location on the wheel to be changed.
Page 408 406 WHAT TO DO IN EMERGENCIES 5. Raise the vehicle by turning the jack screw to the right, using the swivel wrench. Raise the vehicle only until the tire just clears the surface and enough clearance is obtained to install the spare tire. Minimum tire lift provides maximum stability.
Page 409 WHAT TO DO IN EMERGENCIES 407 WARNING! • To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered. Failure to follow this warning may result in personal injury. •...
Page 410: Road Tire Installation
408 WHAT TO DO IN EMERGENCIES 9. Lower the jack until it is free. Remove the wheel Road Tire Installation blocks. Reassemble the lug wrench to the jack assem- Vehicles Equipped With Wheel Covers bly and stow it in the spare tire area. Secure the assembly using the means provided.
Page 411 WHAT TO DO IN EMERGENCIES 409 3. Align the valve notch in the wheel cover with the valve stem on the wheel. Install the cover by hand, snapping the cover over the two lug nuts. Do not use a hammer or excessive force to install the cover. 4.
Page 412 410 WHAT TO DO IN EMERGENCIES 6. Finish tightening the lug nuts. Push down on the WARNING! wrench while at the end of the handle for increased leverage. Tighten the lug nuts in a star pattern until To avoid the risk of forcing the vehicle off the jack, each nut has been tightened twice.
Page 413: Jump-Starting
WHAT TO DO IN EMERGENCIES 411 5. After 25 miles (40 km) check the lug nut torque with a CAUTION! torque wrench to ensure that all lug nuts are properly seated against the wheel. Do not use a portable battery booster pack or any other booster source with a system voltage greater JUMP-STARTING than 12 Volts or damage to the battery, starter motor,...
Page 414: Preparations For Jump-Start
412 WHAT TO DO IN EMERGENCIES Preparations For Jump-Start The battery in your vehicle is located between the left front headlight assembly and the left front wheel splash shield. To allow jump-starting there are remote battery posts located on the left side of the engine compartment. Remote Battery Posts 1 —...
Page 415 WHAT TO DO IN EMERGENCIES 413 3. Remove the protective cover over the remote positive WARNING! (+) battery post. To remove the cover, press the locking • Take care to avoid the radiator cooling fan when- tab and pull upward on the cover. ever the hood is raised.
Page 416: Jump-Starting Procedure
414 WHAT TO DO IN EMERGENCIES 4. If using another vehicle to jump-start the battery, park CAUTION! the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. Failure to follow these procedures could result in damage to the charging system of the booster vehicle WARNING! or the discharged vehicle.
Page 417 WHAT TO DO IN EMERGENCIES 415 8. Disconnect the opposite end of the positive (+) jumper WARNING! cable from the positive (+) post of the booster battery. Do not connect the cable to the negative post (-) of the 9. Disconnect the positive (+) end of the jumper cable discharged battery.
Page 418: Freeing A Stuck Vehicle
416 WHAT TO DO IN EMERGENCIES CAUTION! (Continued) CAUTION! the vehicle’s battery will discharge sufficiently to Racing the engine or spinning the wheels may lead to degrade battery life and/or prevent the engine from transmission overheating and failure. Allow the en- starting.
Page 419: Shift Lever Override
WHAT TO DO IN EMERGENCIES 417 CAUTION! WARNING! (Continued) explode and injure someone. Do not spin your vehi- • When “rocking” a stuck vehicle by shifting be- cle’s wheels faster than 30 mph (48 km/h) or for tween DRIVE and REVERSE, do not spin the longer than 30 seconds continuously without stop- wheels faster than 15 mph (24 km/h), or drivetrain ping when you are stuck and do not let anyone near...
Page 420: Towing A Disabled Vehicle
418 WHAT TO DO IN EMERGENCIES 4. Turn the ignition to the ACC or ON/RUN position, 7. Move the shift lever to the NEUTRAL position. but do not start the engine. 8. The vehicle may then be started in NEUTRAL. 5.
Page 421 WHAT TO DO IN EMERGENCIES 419 Proper towing or lifting equipment is required to prevent CAUTION! damage to your vehicle. Use only tow bars and other • Do not use sling type equipment when towing. equipment designed for this purpose, following equip- ment manufacturer’s instructions.
Page 422: Without The Ignition Key
420 WHAT TO DO IN EMERGENCIES If flatbed equipment is not available, and the transmission Without The Ignition Key is operable, the vehicle may be flat towed (with all four Special care must be taken when the vehicle is towed wheels on the ground) under the following conditions: with the ignition in the LOCK/OFF position.
Page 423 MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Oil Filter ..... .432 ENGINE COMPARTMENT — 2.4L ..423 ▫...
Page 424 422 MAINTAINING YOUR VEHICLE ▫ Brake System ......448 BULB REPLACEMENT ....471 ▫...
Page 425: Engine Compartment - 2.4L
MAINTAINING YOUR VEHICLE 423 ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 5 — Integrated Power Module (Fuses) 9 — Coolant Pressure Cap 2 — Power Steering Fluid Reservoir 6 — Power Distribution Center (Fuses) 10 — Engine Oil Dipstick 3 —...
Page 426: Engine Compartment - 3.6L
424 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.6L 1 — Engine Coolant Reservoir 5 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 6 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 7 — Engine Oil Fill 4 — Integrated Power Module (Fuses) 8 —...
Page 427: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 425 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.
Page 428: Emissions Inspection And Maintenance Programs
426 MAINTAINING YOUR VEHICLE persists, the message will appear the next time the serviced, recently had a dead battery or a battery replace- vehicle is started. This might indicate a damaged cap. If ment. If the OBD II system should be determined not the problem is detected twice in a row, the system will ready for the I/M test, your vehicle may fail the test.
Page 429: Replacement Parts
MAINTAINING YOUR VEHICLE 427 3. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced •...
Page 430: Maintenance Procedures
428 MAINTAINING YOUR VEHICLE available which include detailed service information for MAINTENANCE PROCEDURES your vehicle. Refer to these Service Manuals before The pages that follow contain the required maintenance attempting any procedure yourself. services determined by the engineers who designed your vehicle.
Page 431: Engine Oil
MAINTAINING YOUR VEHICLE 429 fully warmed engine is shut off. Do not check oil level CAUTION! (Continued) before starting the engine after it has sat overnight. • Your vehicle has been built with improved fluids Checking engine oil level when the engine is cold will that protect the performance and durability of your give you an incorrect reading.
Page 432 API Certified and meet pressure and an increase in oil temperature. This the requirements of Chrysler Material Standard MS-6395. could damage your engine. Also, be sure the oil fill American Petroleum Institute (API) Engine Oil cap is replaced and tightened after adding oil.
Page 433 MAINTAINING YOUR VEHICLE 431 Lubricants that do not have both, the engine oil certifi- CAUTION! cation mark and the correct SAE viscosity grade number should not be used. Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Such damage is Engine Oil Viscosity –...
Page 434: Engine Oil Filter
432 MAINTAINING YOUR VEHICLE Synthetic Engine Oils station or governmental agency for advice on how and where used oil and oil filters can be safely discarded in You may use synthetic engine oils provided the recom- your area. mended oil quality requirements are met, and the recom- mended maintenance intervals for oil and filter changes Engine Oil Filter are followed.
Page 435: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 433 Maintenance-Free Battery WARNING! Your vehicle is equipped with a maintenance-free battery. The air induction system (air cleaner, hoses, etc.) can You will never have to add water, nor is periodic main- provide a measure of protection in the case of engine tenance required.
Page 436 434 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Battery fluid is a corrosive acid solution and can • It is essential when replacing the cables on the burn or even blind you. Do not allow battery fluid battery that the positive cable is attached to the to contact your eyes, skin, or clothing.
Page 437: Air Conditioner Maintenance
MAINTAINING YOUR VEHICLE 435 Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer approved by the manufacturer for your air condi- at the start of each warm season. This service should tioning system.
Page 438: A/C Air Filter - If Equipped
436 MAINTAINING YOUR VEHICLE Protection Agency and is an ozone-saving product. How- 1. Open the glove box and remove all contents. ever, the manufacturer recommends that air conditioning 2. Push in on the sides of the glove box and lower the service be performed by authorized dealer or other door.
Page 439: Body Lubrication
MAINTAINING YOUR VEHICLE 437 7. Install the A/C Air Filter with the arrow on the filter pointing toward the floor. When installing the filter cover, make sure the retaining tabs fully engage the cover. CAUTION! The A/C air filter is identified with an arrow to indicate airflow direction through the filter.
Page 440: Windshield Wiper Blades
438 MAINTAINING YOUR VEHICLE MOPAR® Spray White Lube to assure quiet, easy opera- Operation of the wipers on dry glass for long periods tion and to protect against rust and wear. Prior to the may cause deterioration of the wiper blades. Always use application of any lubricant, the parts concerned should washer fluid when using the wipers to remove salt or dirt be wiped clean to remove dust and grit;...
Page 441: Exhaust System
MAINTAINING YOUR VEHICLE 439 reservoir with windshield washer solvent (not radiator Exhaust System antifreeze) and operate the system for a few seconds to The best protection against carbon monoxide entry into flush out the residual water. the vehicle body is a properly maintained engine exhaust When refilling the washer fluid reservoir, apply some system.
Page 442 440 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Exhaust gases can injure or kill. They contain • The catalytic converter requires the use of un- carbon monoxide (CO), which is colorless and leaded fuel only. Leaded gasoline will destroy the odorless. Breathing it can make you unconscious effectiveness of the catalyst as an emissions control and can eventually poison you.
Page 443 MAINTAINING YOUR VEHICLE 441 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 444: Cooling System
442 MAINTAINING YOUR VEHICLE Cooling System Coolant Checks Check engine coolant (antifreeze) protection every 12 WARNING! months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or • When working near the radiator cooling fan, rusty in appearance, the system should be drained, disconnect the fan motor lead or turn the ignition flushed, and refilled with fresh engine coolant (anti-...
Page 445 MAINTAINING YOUR VEHICLE 443 Cooling System – Drain, Flush, And Refill CAUTION! If the engine coolant (antifreeze) is dirty or contains • Mixing of engine coolant (antifreeze) other than visible sediment, have an authorized dealer clean and specified Organic Additive Technology (OAT) en- flush with OAT coolant (antifreeze) (conforming to MS- gine coolant (antifreeze), may result in engine 12106).
Page 446 (antifreeze) products. Do not use additional Additive Technology (OAT) engine coolant (antifreeze) rust inhibitors or antirust products, as they may not that meets the requirements of Chrysler Material Stan- be compatible with the radiator engine coolant and dard MS-12106. When adding engine coolant (antifreeze): may plug the radiator.
Page 447 MAINTAINING YOUR VEHICLE 445 (antifreeze) solution. The use of lower quality water The cap should be inspected and cleaned if there is any will reduce the amount of corrosion protection in the accumulation of foreign material on the sealing surfaces. engine cooling system.
Page 448: Maintaining Your Vehicle
446 MAINTAINING YOUR VEHICLE Disposal Of Used Engine Coolant Six-Cylinder Engines – the level of the engine coolant (antifreeze) in the pressurized coolant bottle should be Used ethylene glycol-based engine coolant (antifreeze) is between the “COLD” and “FULL” range on the bottle a regulated substance requiring proper disposal.
Page 449 MAINTAINING YOUR VEHICLE 447 • If frequent engine coolant (antifreeze) additions are Points To Remember required, the cooling system should be pressure tested NOTE: When the vehicle is stopped after a few miles/ for leaks. kilometers of operation, you may observe vapor coming •...
Page 450: Brake System
448 MAINTAINING YOUR VEHICLE result in unsatisfactory engine coolant (antifreeze) Master Cylinder – Brake Fluid Level Check performance, poor gas mileage, and increased emis- Check the fluid level in the master cylinder immediately sions. if the brake system warning light indicates system fail- ure.
Page 451 MAINTAINING YOUR VEHICLE 449 Use only manufacturer’s recommended brake fluid. Re- WARNING! (Continued) fer to “Fluids, Lubricants, and Genuine Parts” in “Main- • To avoid contamination from foreign matter or taining Your Vehicle” for further information. moisture, use only new brake fluid or fluid that has been in a tightly closed container.
Page 452: Automatic Transmission
450 MAINTAINING YOUR VEHICLE NOTE: No chemical flushes should be used in any WARNING! (Continued) transmission; only the approved lubricant should be • Do not allow petroleum based fluid to contaminate used. the brake fluid. Brake seal components could be damaged, causing partial or complete brake failure.
Page 453 MAINTAINING YOUR VEHICLE 451 Automatic Transmission Fluid (ATF) is an engineered 2. Run the engine at normal idle speed for at least 60 product and its performance may be impaired by supple- seconds, and leave the engine running for the rest of mental additives.
Page 454 452 MAINTAINING YOUR VEHICLE cannot be held comfortably between the fingertips. transmission before rechecking the fluid level. Cold fluid is at a temperature of approximately 80° F 8. Check for leaks. Release the parking brake. (27° C). To prevent dirt and water from entering the transmission 7.
Page 455 MAINTAINING YOUR VEHICLE 453 an improper fluid level can cause severe transmission CAUTION! (Continued) damage. • Dirt and water in the transmission can cause seri- ous damage. To prevent dirt and water from enter- CAUTION! ing the transmission after checking or replenishing •...
Page 456: Appearance Care And Protection From Corrosion
454 MAINTAINING YOUR VEHICLE Appearance Care And Protection From Corrosion What Causes Corrosion? Corrosion is the result of deterioration or removal of Protection Of Body And Paint From Corrosion paint and protective coatings from your vehicle. Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 457 MAINTAINING YOUR VEHICLE 455 • If insects, tar, or other similar deposits have accumu- Special Care lated on your vehicle, use MOPAR® Super Kleen Bug • If you drive on salted or dusty roads or if you drive and Tar Remover to remove. near the ocean, hose off the undercarriage at least once •...
Page 458 456 MAINTAINING YOUR VEHICLE • If you carry special cargo such as chemicals, fertilizers, CAUTION! de-icer salt, etc., be sure that such materials are well packaged and sealed. Do not use scouring pads, steel wool, a bristle brush, or metal polishes. Do not use oven cleaner. These •...
Page 459 MAINTAINING YOUR VEHICLE 457 • For grease stains, apply MOPAR® Multi-Purpose To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth. To Cleaner to a clean, damp cloth and remove stain. Use remove road dirt, wash with a mild soap solution fol- a fresh, damp towel to remove soap residue.
Page 460 458 MAINTAINING YOUR VEHICLE if absolutely necessary. Do not use harsh cleaners or WARNING! Armor All®. Use MOPAR® Total Clean or equivalent to clean vinyl upholstery Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in Cleaning Leather Upholstery closed areas they may cause respiratory harm.
Page 461: Cleaning Center Console Cupholders
MAINTAINING YOUR VEHICLE 459 Cleaning Plastic Instrument Cluster Lenses Replace the belts if they appear frayed or worn or if the buckles do not work properly. The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care Cleaning Center Console Cupholders must be taken to avoid scratching the plastic.
Page 462: Convertible Top Care
460 MAINTAINING YOUR VEHICLE Installation CAUTION! (Continued) Align the liner in the cupholder and press down firmly. • Use care when washing the vehicle, water pressure directed at the weather strip seals may cause water Convertible Top Care to leak into the vehicles interior. CAUTION! Immediate removal of any contaminant is recommended.
Page 463 MAINTAINING YOUR VEHICLE 461 CAUTION! CAUTION! Avoid high-pressure car washes, as they can damage Never use an abrasive type cleaner or bleaches. the top material. Also, increased water pressure may Cleaners should not contain silicones, organic sol- force water past the weather strips. vents, petroleum distillates, or plasticizers.
Page 464: Weather Strip Care - Soft And Hard Top
462 MAINTAINING YOUR VEHICLE Additional Cleaning Procedure CAUTION! For additional cleaning assistance in removing stubborn Avoid getting Scotchguard® on the surrounding stains, apply MOPAR® Convertible Cloth Top Cleaner or weather strips, moldings, paint, or glass. Damage to equivalent to the complete stain, extending 2 inches (50 these items might occur.
Page 465: Fuses
MAINTAINING YOUR VEHICLE 463 FUSES WARNING! WARNING! If the replaced fuse blows again, contact an autho- rized dealer. • When replacing a blown fuse, always use an appro- priate replacement fuse with the same amp rating as WARNING! the original fuse. Never replace a fuse with another fuse of higher amp rating.
Page 466: Integrated Power Module
464 MAINTAINING YOUR VEHICLE Integrated Power Module The Integrated Power Module is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini fuses. A label that identifies each component may be printed on the inside of the cover.
Page 467 MAINTAINING YOUR VEHICLE 465 Car- Car- Mini Mini Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 20 Amp Brake Vacuum — 30 Amp Ignition Off Draw Yellow Pump Green (IOD) Sense 1 — 10 Amp Center High —...
Page 468 466 MAINTAINING YOUR VEHICLE Car- Car- Mini Mini Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 20 Amp — — 10 Amp Wireless Control Yellow Module (WCM)/ Clock/Steering — 20 Amp Ignition/Cigar Control Module Yellow Lighter (SCM) —...
Page 469 MAINTAINING YOUR VEHICLE 467 Car- Car- Mini Mini Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 10 Amp Ignition Run – Cli- — 10 Amp Ignition Run – Oc- mate Controls/Hot cupant Classifica- Cupholder – If tion Module Equipped (OCM)/Occupant Restraint Controller...
Page 470 468 MAINTAINING YOUR VEHICLE Car- Car- Mini Mini Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 20 Amp Ignition Run – 30 Amp — Anti-Lock Brakes Yellow Heated Seats – If Pink (ABS) Module – If Equipped Equipped/ Electronic Stability —...
Page 471 MAINTAINING YOUR VEHICLE 469 Car- CAUTION! Mini Cavity tridge Description Fuse • When installing the Integrated Power Module Fuse cover, it is important to ensure the cover is properly 30 Amp — Passenger Door positioned and fully latched. Failure to do so may Pink Module (PDM)/ allow water to get into the Integrated Power Mod-...
Page 472: Vehicle Storage
470 MAINTAINING YOUR VEHICLE VEHICLE STORAGE REPLACEMENT BULBS If you will not be using your vehicle for more than 21 Interior Bulbs days, you may want to take steps to preserve your Bulb Number battery. • Disengage the mini-fuse in the Power Distribution Front Courtesy/Reading 578/W5W Lamp...
Page 473: Bulb Replacement
MAINTAINING YOUR VEHICLE 471 Exterior Bulbs BULB REPLACEMENT Bulb Number NOTE: Lens fogging can occur under certain atmo- Bi-Halogen Headlamp HIR2 spheric conditions. This will usually clear as atmospheric conditions change to allow the condensation to change Front Turn Signal Lamp 3157NAK back into a vapor.
Page 474 472 MAINTAINING YOUR VEHICLE 2. To begin removal of the driver side headlamp, reach in To begin removal of the passenger side headlamp, reach through the inner fender headlamp access door and in through the inner fender headlamp access door and grasp the bulb cover.
Page 475 MAINTAINING YOUR VEHICLE 473 3. Rotate bulb cover and one-quarter turn and pull 4. Rotate bulb and connector one-quarter turn and pull outward from assembly. outward from assembly. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life.
Page 476: Front Turn Signal
474 MAINTAINING YOUR VEHICLE 5. Pull the bulb out of the socket and replace the bulb. 8. Place bulb cover back and rotate one-quarter turn clockwise to secure. Front Turn Signal 1. Raise and prop open the hood. 2. Rotate the bulb’s electrical connector one-quarter turn counterclockwise and remove it from the headlamp housing.
Page 477: Front Fog Lamp
MAINTAINING YOUR VEHICLE 475 Front Fog Lamp CAUTION! NOTE: Access to the lamps through the lower fascia Do not touch the new bulb with your fingers. Oil cutout is limited. We recommend you access the lamps by contamination will severely shorten bulb life. If the turning the steering wheel to allow access and remove bulb comes in contact with an oily surface, clean the the inner fender shield.
Page 478 476 MAINTAINING YOUR VEHICLE 2. Remove the two plastic wing nuts from the tail lamp 3. Grasp the tail lamp by both the outboard and inboard housing. sides, and pull firmly to disengage the tail lamp from the vehicle. NOTE: It is normal to hear a loud sound when the lower tail lamp area unsnaps from the vehicle mounting bracket during tail lamp removal.
Page 479: License Plate Lamp
MAINTAINING YOUR VEHICLE 477 4. Twist and remove socket from lamp. License Plate Lamp 5. Remove bulb from socket and replace. 1. Using a small screwdriver, press inward the locking tab on the side of the lamp assembly and pull down on 6.
Page 480: Fluids, Lubricants And Genuine Parts
478 MAINTAINING YOUR VEHICLE U.S. Metric Cooling System* 2.4L Engine (MOPAR® Antifreeze/Engine Coolant 10 7.7 Quarts 7.3 Liters Year/150,000 Mile Formula or equivalent) 3.6L Engine (MOPAR® Antifreeze/Engine Coolant 10 11.6 Quarts 11 Liters Year/150,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level. FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component...
Page 481 Fluid, Lubricant, or Genuine Part Engine Oil – 2.4L Engine We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Ma- terial Standard MS-6395 such as MOPAR, Pennzoil®, and Shell Helix®. Refer to your engine oil filler cap for correct SAE grade.
Page 482: Chassis
480 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Spark Plugs – 3.6L Engine We recommend you use MOPAR® Spark Plugs (Gap 0.043 in [1.1 mm]). Fuel Selection 87 Octane * PZEV = Partial Zero Emission Vehicle Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Use only ATF+4®...
Page 483: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS ▫ Maintenance Chart.....484 MAINTENANCE SCHEDULE ... . .482...
Page 484 482 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE your authorized dealer, the message can be reset by refer- ring to the steps described under “Electronic Vehicle Infor- Your vehicle is equipped with an automatic oil change mation Center (EVIC)/Oil Change Required” in “Under- indicator system.
Page 485 MAINTENANCE SCHEDULES 483 Required Maintenance Intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Refer to the maintenance schedules on the following • Inspect automatic transmission fluid if equipped page for the required maintenance intervals. with dipstick. At Every Oil Change Interval As Indicated By Oil •...
Page 486 484 MAINTENANCE SCHEDULES Maintenance Chart Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals and replace if necessary. Inspect the brake linings, replace as necessary. Adjust parking brake as neces- sary...
Page 487 MAINTENANCE SCHEDULES 485 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace engine air filter. Replace cabin/air conditioning filter. Replace spark plugs (2.4L Engine). ** Replace spark plugs (2.4L PZEV Engine Only). ** Replace spark plugs (3.6L Engine).
Page 488 486 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Change automatic transmission fluid and filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing.
Page 489 MAINTENANCE SCHEDULES 487 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 491: If You Need Consumer Assistance
IF YOU NEED ASSISTANCE ....491 REPORTING SAFETY DEFECTS ... .495 ▫ Chrysler Group LLC Customer Center..492 ▫ In The 50 United States And Washington, D.C..
Page 492 490 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... . .497 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ....497 ▫...
Page 493: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 491 SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 494: Chrysler Group Llc Customer Center
• Vehicle delivery date and mileage dealer service manager first. Most matters can be re- solved with this process. Chrysler Group LLC Customer Center • If for some reason you are still not satisfied, talk to the P.O. Box 21–8004 general manager or owner of the authorized dealer.
Page 495: In Mexico Contact
IF YOU NEED CONSUMER ASSISTANCE 493 In Mexico Contact: Canadian residents with hearing difficulties that require assistance can use the special needs relay service offered Av. Prolongacion Paseo de la Reforma, 1240 by Bell Canada. For TTY teletypewriter users, dial 711 Sante Fe C.P.
Page 496: Warranty Information
See the Warranty Information Booklet, located on the the ownership experience. You will be pleased with their DVD, for the terms and provisions of Chrysler Group sincere efforts to resolve any warranty issues or related LLC warranties applicable to this vehicle and market.
Page 497: Mopar® Parts
IF YOU NEED CONSUMER ASSISTANCE 495 MOPAR® PARTS campaign. However, NHTSA cannot become involved in individual problems between you, your authorized MOPAR® fluids, lubricants, parts, and accessories are dealer, and the manufacturer. available from an authorized dealer. They are recom- mended for your vehicle in order to help keep the vehicle To contact NHTSA, you may either call the Auto Safety operating at its best.
Page 498: Publication Order Forms
Chrysler Group LLC vehicles. ing, servicing, and repairing Chrysler Group LLC ve- Included are starting, operating, emergency and mainte- hicles.
Page 499 IF YOU NEED CONSUMER ASSISTANCE 497 Call toll free at: Treadwear • 1–800–890–4038 (U.S.) The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled • 1–800–387–1143 (Canada) conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded Visit us on the Worldwide Web at:...
Page 500 498 IF YOU NEED CONSUMER ASSISTANCE concrete. A tire marked C may have poor traction perfor- passenger car tires must meet under the Federal Motor mance. Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test WARNING! wheel, than the minimum required by law.
Page 501 INDEX...
Page 502 500 INDEX About Your Brakes ......327 Air Conditioning Refrigerant ....435 ABS (Anti-Lock Brake System) .
Page 503 INDEX 501 Automatic Transmission ....303 Anti-Lock (ABS) ......329 Adding Fluid .
Page 504 502 INDEX Certification Label......382 Compass Variance ......241 Chains, Tire .
Page 505 INDEX 503 Pressure Cap ......445 Dipsticks Radiator Cap ......445 Automatic Transmission .
Page 506 504 INDEX Electronic Speed Control (Cruise Control) ..189 Jump Starting ......411 Electronic Stability Control (ESC) .
Page 507 INDEX 505 Exterior Lights ......96 Replacement Parts ..... . .378 Starting .
Page 508 506 INDEX Filler Cap (Gas Cap) .....218 Gauges Filler Door (Gas Cap) ....218 Coolant Temperature .
Page 509 INDEX 507 Bulb Replacement ..... . .471 Hood Release ......175 Cleaning .
Page 510 508 INDEX Introduction ......4 Hood ....... .175 Latch Plate.
Page 511 INDEX 509 Fog ....... . .181 Service .......471 Headlights .
Page 512 510 INDEX Maintenance Free Battery....433 Monitor, Tire Pressure System ....362 Maintenance Procedures .
Page 513 INDEX 511 Filter ....... .432 Passenger Seat Back Tilt (Easy Entry System)..171 Filter Disposal .
Page 514 512 INDEX Pretensioners Remote Control Seat Belts ......51 Security Alarm ......18 Programmable Electronic Features .
Page 515 INDEX 513 Safety Checks Outside Vehicle ....95 Untwisting Procedure .....49 Safety Defects, Reporting .
Page 516 514 INDEX Settings, Personal ......244 Tilt Column ......188 Setting the Clock.
Page 517 INDEX 515 Time Delay, Headlight ..... .179 Radial .......352 Tip Start.
Page 518 516 INDEX Weight .......387 Tread Wear Indicators ..... .358 Towing Assistance.
Page 519 INDEX 517 Variance, Compass ......241 Wheel and Wheel Trim .....456 Vehicle Certification Label .
Page 521 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s The antenna cable should be as short as practical and routed away electronic system to provide immunity to radio frequency signals. from the vehicle wiring when possible. Use only fully shielded Mobile two-way radios and telephone equipment must be installed coaxial cable.
Page 522 Chrysler Group LLC 14C27-126-AA First Edition Printed in U.S.A.

This manual is also suitable for:

2014 200 convertible

Chrysler 200 Convertible 2014 Owner's Manual

Table of Contents

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Quick Links

Chapters

Related Manuals for Chrysler 200 Convertible 2014

Summary of Contents for Chrysler 200 Convertible 2014
