Q U I C K S TA R T G U I D E

Advertisement

loading
Need help?

Need help?

Do you have a question about the Penveu and is the answer not in the manual?

Questions and answers

Related Manuals for Penveu Penveu

Summary of Contents for Penveu Penveu

  • Page 1 Q U I C K S TA R T G U I D E...
  • Page 2 Record your serial numbers here and retain for your records. Serial numbers can be found under the veu and on the back of the pen. Please register your product at www.penveu.com/register to enable warranty support. Find the complete User Guide at www.penveu.com/resources.
  • Page 3 the pen USB cable the veu VGA cable T H E B OX the dock power adapter (2)
  • Page 4 Full Battery C H A R G E T H E P E N Low Battery Battery indicators located near the tip of the pen and the top of the veu let you know when you need to charge your pen. Charge the pen by placing it inside the veu or in the dock.
  • Page 5 VGA cable * VGA cable * provided with projector or display I N S TA L L penveu USB cable E A S I LY computer projector or laptop or display Installation is as easy as one, two, three.
  • Page 6 C O N N EC T T H E P E N Take the pen out of the veu. Touch the pen tip to the display until the pen beeps to indicate a successful connection between the pen and the veu. You’re ready to go!
  • Page 7 M O D E Right Click Undo/Back All the functionality of a mouse from anywhere Capture in the room, in Touch, Remote and penveu Pad Mode modes, including the ability to hover. Use the Camera Lens buttons as indicated. Push the mode button to switch to pen mode.
  • Page 8 No calibration required. Write directly on your Mode display (Touch mode), from anywhere in the Camera Lens room (Remote mode) and on the penveu Pad paper (Pad mode). Push the mode button to Communication to Veu switch to mouse mode.
  • Page 9 Color Thickness Grip U S I N G Color P E N Indicator M O D E While in pen mode, the color indicator near the pen tip illuminates to show the selected color. Change colors using the menu or the touch scroll.
  • Page 10 WHITEBOARD Select color and Select background color line thickness (white, green, black) and pattern HIGHLIGHTER Highlight text and/or SAVE image; select color Capture anything shown on P E N and thickness screen as a bitmap image LOAD ERASER M O D E Erase writing or drawing on View previously captured the whiteboard;...
  • Page 11 Buttons/ Inputs Power Reset Locate Pen To Computer To Display T H E Indicators V E U Connected to Display Battery After the veu is installed, it Communication communicates wirelessly with the pen. to Pen The veu also acts as a charging station and carrying case for the pen.

  • Page 12: Your Notes

    C A P T U R E YO U R N OT E S Click the capture button to store your screen captures on the veu’s built-in 8GB or 32GB USB drive. Easily share them when your veu is connected to your computer. You may store If using Linux, see User Guide for specifics.
  • Page 13 S Y S T E M update.penveu.com U P DAT E To update the penveu system, place the pen inside the veu and connect the veu to a computer using the USB cable. Further instructions can be found at update.penveu.com.

  • Page 14: T I P S Fo R

    When writing directly on the display, use with screen sizes from 20 to 100 inches measured diagonally. If using a larger display and using penveu only away from the display, use the menu to select SETTINGS – SCREEN SIZE – AUDITORIUM.
  • Page 15 Warranty Information For further information on product warranty, please review the penveu warranty at support.penveu.com. Other Information ©2012 Interphase Corporation. The name penveu and the penveu logo are registered trademarks of Interphase Corporation. All rights reserved. penveu.com facebook.com/penveu @penveu PN: MS0000115-C...
