- Page 1 StarVoice Installation Guide...
-
Page 2: Installation Guide
DATE: February 2003 Rights CopyRight 2003 Aethra SpA All Rights Reserved Printed in Italy Trademarks AETHRA is registered trademark of Aethra SpA. Ethernet is registered trademark of Xerox Corporation. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pag. 2... -
Page 3: Table Of Contents
INDEX Safety Rules ............................. 5 Warnings ............................6 Cleaning ............................6 CE Marking............................6 Introduction..........................7 Users............................. 7 Contents ..........................7 Abbreviations ........................7 Models ............................9 Interfaces..........................9 Installation ..........................10 Package ..........................10 Mounting..........................10 Connections........................11 3.3.1 Powering up ....................... - Page 4 How to change the IP address .................... 31 5.3.1 Changing the IP address from WEB server ............... 31 StarManager..........................32 How to connect StarVoice ....................32 LAN and DHCP server configuration................33 WAN configuration......................33 ATM parameter configuration for voice interfaces ............34 Password ..........................
-
Page 5: Safety Rules
SAFETY ADVISES AFETY ULES DEVIEC IN CLASS II WITH FUNCTIONAL EARTH Always connect to a grounded socket. To guarantee continuous protection for operator safety, only use the mains adapter supplied with the device. To guarantee continuous protection for operator safety, make sure that the mains plug is always connected to the power source. -
Page 6: Warnings
ARNINGS CAUTION: Many of the components used in this device are sensitive to electrostatic charge. In case of manipulation of the connection cables, disconnect the power supply and avoid direct contacts with the connector terminals. When handling electronic components, to eliminate any static electricity touch a grounded surface. -
Page 7: Introduction
Introduction StarVoice is a family of ADSL and SHDSL products developed to provide an integrated wide band voice and data device. StarVoice stems from Aethra long-standing experience with ISDN devices and terminations. It guarantees quick simple installation and high-compatibility level with any type of telephones, fax machines, PBXs, modems, etc. - Page 8 ⇒ ADSL Asymmetric Digital Subscriber Line ⇒ ATM Asynchronous Transfer Mode ⇒ ATOS Aethra Telecommunications Operating System ⇒ BLES Broadband Loop Emulation Service ⇒ BRI Basic Rate Interface ⇒ CAS Channel Associated Signaling ⇒ CCS Common Channel Signaling ⇒ CID AAL2 Channel Identifier ⇒...
-
Page 9: Models
Models StarVoice is available with different configurations to provide the ideal solution to the most diverse requirements. SV10xy models are based on ADSL technology. They deliver up to 4 analogue ports and 4 ISDN BRI ports. SV20xy models are based on SHDSL technology. They deliver up to 4 analogue ports and 4 ISDN BRI ports. -
Page 10: Installation
For wall installation (minimum height from the ground is 20 cm) drill two 6mm-diameter holes on the wall as shown in Fig. 3-1. Insert the dowels in the holes, tighten the screws and hook StarVoice on the slots. Figure 3-1: Drilling template... -
Page 11: Connections
Connections Connections are available on StarVoice back panel. They depend on the model and contract with the service provider. StarVoice has the following connections: ⇒ power supply (see 3.3.1); ⇒ console interface (see 3.3.2); ⇒ analogue telephone system (see 3.3.3);... -
Page 12: Console Interface
3.3.2 Console interface Connect your PC serial port to the Console interface with the cable supplied with StarVoice to access local configuration, diagnostics and firmware upgrade. You can also connect the backup unit serial cable to receive alarms and information on the PBU operation status. -
Page 13: Isdn Devices Or Bus S System
R DY PW R 3.3.4 ISDN devices or BUS S system ISDN devices (if placed near StarVoice) or BUS-S system (if the position of ISDN terminals requires this type of installation) are connected with RJ-45 connectors (marked as ISDN). Figure 3-3: ISDN ports... -
Page 14: Local Network (Lan)
You can connect your LAN to StarVoice with the RJ-45 interface marked as “LAN” using braid cables ending with RJ–45 plugs. StarVoice allows you to connect your PC with a straight cable. If you connect a hub without a cross dedicated port, use a suitable cable (cross). -
Page 15: Adsl Or Shdsl (Wan)
Figure 3-4: Line Interface Description StarVoice is a DSL technology-based device designed for small and medium-size offices for simultaneous voice and data transportation over a single telephone pair. The functionalities of analogue and ISDN ports are obtained thanks to the Broadband Loop Emulation Service (BLES) mode describes in the ATM forum “AF-VMOA-0145.000”... -
Page 16: Front Panel
LAN and provide suitable security system for connections; ⇒ Dynamic Host Configuration Protocol (DHCP) server functionality for automatic configuration of PC’s connected to StarVoice in the LAN; ⇒ DNS (Domain Name System) server and forwarder functionality for host and domain name resolution in IP addresses;... - Page 17 LED status function FLASHING (...) Correct connection with Alternate GREEN GREEN public exchange modem during establishment LINE of physical level or connection failed (no line). Device initialization Normal operation with No data flow GREEN data flow GREEN Short switching on Free line Busy line during ring phase...
-
Page 18: Back Panel
Line rate for ADSL and SHDSL technology is defined upon service subscription and determined by the public exchange modem configuration (DSLAM) when establishing the connection. During start-up StarVoice negotiates the maximum permitted rate with the public exchange modem. 4.4.2 ADSL interface The ADSL network interface complies with the ITU-T G.992.1 (g.dmt) standard. -
Page 19: Shdsl Interface
ELCP (Emulated Loop Control Protocol). 4.4.6 ATM Virtual Circuit Connections StarVoice uses one VCC for voice traffic transportation and up to 10 VCC’s for data traffic transportation. The voice traffic transportation VCC is configured with VPI/VCI value. The service class can be: ⇒... -
Page 20: Pots And Isdn-Bri Lines
Every profile contains one or more entries and every entry indicates a specific coding law in addition to voice packet length. StarVoice can be configured with one of the following profiles for every VCC assigned to voice transportation: Pag. 20... -
Page 21: Signaling Associated With Supplementary Services
CLIP upon Call Wait, CNIP and MWI services. StarVoice is completely transparent to the aforementioned signaling. Data interfaces StarVoice delivers one Ethernet 10BaseT (LAN0) standard interface and optionally one 10/100 BaseT (LAN1) additional interface. 4.6.1 Transportation protocols Every ATM VCC used for data transportation can be configured with one of the following protocols: ⇒... -
Page 22: Llc Snap Encapsulation
4.6.3 MAC Bridging StarVoice can be configured to operate as bridge at MAC level. Up to 4 logic bridges (bridge groups) between LAN or WAN (ATM VCC’s) interfaces can be configured. The Spanning Tree algorithm can be programmed for every bridge group. -
Page 23: Multicast Traffic
These services are used to make LAN configuration easier and faster. If the DHCP service is enabled, LAN hosts can be configured with the TCP/IP information supplied by StarVoice (IP address and host name, IP address of DSN and WINS servers, default gateway). -
Page 24: Management
⇒ upgrade the firmware. StarVoice manages an internal file system to save configuration and event traces. Information can be accessed via CLI. 4.7.2 Remote management StarVoice provides remote configuration using a dedicated ATM VC. The traffic generated on the VC is interpreted as IP traffic encapsulated according to RFC1483. -
Page 25: Configuration
If no PC with LAN board is available, you can use the Console port and StarManager (software included in the installation CD), as illustrated in 6; If a PC with LAN board is available, you can connect it to StarVoice LAN port and carry out the WEB browser configuration, as illustrated 5.1.3. -
Page 26: Preliminary Operations For Internal Web Server Use
5.1.2 Preliminary operations for internal WEB server use Connect a PC with LAN interface to one of StarVoice Ethernet ports. In the “Properties” option of the local network connection set TCP/IP parameters as illustrated below according for the different Microsoft operating systems:... -
Page 27: Internal Web Server Configuration With Quick Start
5.1.3 Internal WEB server configuration with Quick Start By using the DHCP services for the automatic configuration of network parameters in the LAN PC’s, you can open the browser and enter the local IP address assigned to StarVoice (10.0.0.1 by default). - Page 28 Enter encapsulation type and LLC SNAP mode and click Next; Different parameters must be entered based on encapsulation mode (PPP, RFC1483, etc.). Enter VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) values for WAN1 (interface enabled by default). This information can be found in the contract.
- Page 29 Enter VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) values for CPIWF1, (interface that enables voice service). This information can be found in the contract. Now you have entered all configuration parameters. Save the new configuration. Reboot the device after saving. The new configuration will be loaded.
-
Page 30: System Passwords
System passwords Two user levels are available: ⇒ Administrator; ⇒ User. To discriminate the level you must configure two different passwords for the two users. This operation can be accessed from StarManager (see 6.4) or from the internal WEB server System page, as illustrated below: Click System on the left of the WEB page;... -
Page 31: How To Change The Ip Address
How to change the IP address After you set the configuration parameters and before you connect StarVoice to an existing LAN, check that the default IP address (10.0.0.1) is compatible with the addresses used in the LAN. You can change the address with WEB server or StarManager (see 6.2). -
Page 32: Starmanager
StarVoice console port to communicate with the device. It is contained in the installation CD supplied with the device. Follow the instructions given in 3.3.2 to connect your PC to StarVoice console port. The initial page is shown below. -
Page 33: Lan And Dhcp Server Configuration
LAN and DHCP server configuration Enter IP address and Subnet mask; Check the box to use the DHCP server. A new window appears (see below). Enter the start and stop IP address. WAN configuration This section is used to enter the ISP service parameters;... -
Page 34: Atm Parameter Configuration For Voice Interfaces
If you select PPP encapsulation, you must enter the parameters shown here on the left; If you select RFC1483 encapsulation, you must enter the parameters shown here on the left. ATM parameter configuration for voice interfaces Enter VPI and VCI values supplied by the ISP (default values: VPI: 10 and VCI: 45) Pag. -
Page 35: Password
Password You can enter a password to protect the new configuration. Configuration parameters Configuration parameters are shown in this page at the end of the configuration procedure. Pag. 35... -
Page 36: File Download
File Download You can transfer a configuration file or firmware upgrade from the PC to the device. Select this button to open the window used to select the file you want to transfer. File Upload You can transfer a configuration file (saved with Save in the device) from the device to the Select this button to transfer the configuration file from the device to the PC. -
Page 37: Appendix "A" - Specifications
APPENDIX “A” – Specifications Technical features Analogue lines (POTS) Call ⇒ Insertion mode: unbalanced ⇒ Frequency : 25Hz + 2Hz ⇒ Level with Z = 2 KΩ (3,3 µF + 1000 Ω) : ≥ 40 V ⇒ Immediate call (first ring) for CLIP, CNIP and MWI services Dialing ⇒... -
Page 38: Atm
⇒ ITU-T I.361, I.363.5, I.363.2, I.432, I.610, I.732 ⇒ ATMF UNI 3.1, ATMF Traffic Loop Emulation Services and Narrowband Signaling ⇒ ATM Forum af-vmoa-0145.000, fb-vmoa-0175.000, fb-vmoa-0174.000 ⇒ ETSI EG 201 900-1, TS 300 324-1 and TS 300 347-1 Data Protocol ⇒... -
Page 39: Operation And Storage Conditions
Operation and storage conditions -5°C ÷ +45 °C OPERATING TEMPERATURE OPERATING RELATIVE HUMIDITY 10% ÷ 93 % (without condensation) STORAGE TEMPERATURE -40 ÷ +70 °C Reference standards (EEC MARKING RELIABILITY TESTS) CEI 50-3 STORAGE EN 60068-2-1 Test Ab (IEC 60068-2-1) EN 60068-2-2 Test Bb (IEC 60068-2-2) IEC 60068-2-14 Test Nb IEC 60068-2-18...
