PRYME Radio Product PRYMEBLUPUSH-TO-TALK User Manual

QUICK START

1. Charge the PRYMEBLU Wireless PTT
2. Pair the PRYMEBLU Adapter with a wireless headset
3. Pair the PRYMEBLU PTT with the PRYMEBLU Adapter
4. Test and Use.
STEP ONE: Charging the PRYMEBLU PTT
The PRYMEBLU PTT has an internal Lithium Ion rechargeable battery pack which must be charged prior
to operation, and must be recharged regularly. A fully charged battery will provide approximately 12
hours (or more) of operation before needing to be recharged.
To charge the PRYMEBLU PTT:
* Ensure the PRYMEBLU PTT is turned o , using the switch located on the back of the device.
* Plug the supplied wall charger into an AC (110V) wall outlet.
* Plug the charger into charge jack on the bottom of the PRYMEBLU Adapter. You will need to remove
the protective rubber cover that is inserted into the charge jack. (To prevent dust and moisture from
damaging your PTT, always ensure this cover is in place when you are not charging the PRYMEBLU PTT.)
* The PRYMEBLU PTT takes approximately 4.5 hours to charge. Actual charge time will vary depending
on several factors including the battery's charge state, condition, and age.
Charging Cautions:
- Use only the wall charger supplied by the manufacturer. Do not use any other charger.
- Do not use a wall charger that appears to be damaged. (Example: frayed wires, melted plastic, etc.)
Contact PRYME to get a new manufacturer-approved replacement charger.
- Do not tamper with or modify the PRYMEBLU PTT or charger.
-Always turn the power switch to the O position when charging the PRYMEBLU PTT.
3
Controls and Connection
LED Indicator
The LED ashes messages that let
the user know the current status of
the PRYMEBLU PTT.
Push-To-Talk Button
When paired with a PRYMEBLU Adapter
and wireless headset, this button functions
as a Push-to-Talk, causing the two-way radio
to transmit when the switch is pressed.
Velcro Fastener
The Velcro strap on the back of the
PRYMEBLU PTT rotates 360° and allows
the PRYMEBLU PTT to be securely attached
in many convenient locations, such as to
the user's clothing, around the user's ngers,
on an automobile steering wheel, on duty
gear, and many more!
Power Switch
Turns the
PRYMEBLU PTT
on and o .
Charge Jack
This jack is used to connect the
PRYMEBLU PTT to the supplied
wall charger.
Lanyard Attachment Point
Allows attachment of a wrist strap
or lanyard to the PRYMEBLU PTT.
USING THE FRICTION PAD
The PRYMEBLU PTT is supplied with a rubber Friction Pad. This pad provides additional protection and
stability when using the Velcro Fastener on the back of the PRYMEBLU PTT to attach the device to an
automobile steering wheel, gearshift, or any other location.
To install the rubber Friction Pad do the following:
1. Open the Velcro Fastener on the back of the
PRYMEBLU PTT so that the two straps are separated.
2. Align the Friction Pad so that it is centered over the
Velcro Fastener on the back of the PRYMEBLU PTT.
3. Slide one strap of the Velcro Fastener into one
of the slots in the Friction Pad and pull the strap through.
4. Slide the other Velcro Fastener strap through the other slot in the Friction Pad.
5. Place the PRYMEBLU PTT in the position you wish to mount it and close the Velcro Fastener.
Pairing With an Audio Accessory
STEP TWO: Pairing the PRYMEBLU Adapter and Wireless Headset
In order to operate, the PRYMEBLU PTT must be paired to PRYMEBLU Adapter (BT-500 series).
However, The PRYMEBLU Adapter must rst be paired to a wireless Bluetooth headset. To pair these
devices, follow this procedure:
Pairing the PRYMEBLU Adapter and Bluetooth Headset
* The PRYMEBLU Adapter must be connected to a compatible radio with a freshly charged battery.
Ensure the two-way radio, Bluetooth headset, and PRYMEBLU PTT are all powered o .
* Place the PRYMEBLU Adapter in Accessory Pairing mode. To do this, turn the two-way radio on while
holding down the Talk button on the PRYMEBLU Adapter. Continue to hold the Talk button down for
approximately three seconds. Release the Talk button when the status LED ashes two times per
second. The PRYMEBLU Adapter is now in audio accessory pairing mode.
* Activate the pairing mode on your Bluetooth headset by following the instructions provided by the
headset's manufacturer. Once the wireless audio accessory and PRYMEBLU Adapter are paired with
each other, the status
LED on the PRYMEBLU Adapter will show a constant blue light for three seconds.
* Once the headset and PRYMEBLU Adapter have been successfully paired, turn o the two-way radio
and Bluetooth headset and wait at least three seconds.
Pairing the PRYMEBLU Adapter and PRYMEBLU PTT
* Turn on the two-way radio while holding down the Talk button on the PRYMEBLU Adapter. Continue
to hold the Talk button down for approximately three seconds. Release the Talk button when the
status LED ashes two times per second. Then, press the Talk button again. The LED should now ash
three times per second, indicating that the PRYMEBLU Adapter is now in PTT Pairing mode.
* Place the PRYMEBLU PTT in pairing mode by holding down the Push-To-Talk button while moving
the power switch to the On position. Continue to hold down the Push-To-Talk button until the LED
indicator on the PRYMEBLU PTT ashes blue continuously. You can then release the Push-to-Talk
button. The PRYMEBLU PTT is now in pairing mode.
* Once the PRYMEBLU Adapter and PRYMEBLU PTT are paired with each other, the status LED on the
PRYMEBLU Adapter will show a constant blue light for three seconds and the LED on the PTT will show
one blue ash every second.
* If the PRYMEBLU Adapter or PRYMEBLU PTT does not detect a compatible wireless accessory within
60 seconds of being put into pairing mode, the devices will exit the pairing mode and resume normal
operation.
* After pairing is successful, turn o the PRYMEBLU PTT and the two-way radio that the PRYMEBLU
Adapter is attached. Wait at least three seconds.
