Summary of Contents for Ventus GPS G730
- Page 1 VENTUS GPS G730 DATA LOGGER Manual...
-
Page 2: Features And Functions
Caution Read before you start to use: Global position system (GPS) is obtained by American Ministry of National Defense, and they got the full responsibility about the preciseness and the maintenance. Any changes may cause the capacity and preciseness of GPS differed. If you use this device inside of buildings, tunnels, or any huge objects beside you, the GPS signals might be cut-off or disturbed. -
Page 3: Check The Package Content
Check the Package Content Before you start using, please check out if your package includes the following items. • GPS USB receiver X 1 • CD with software and driver X 1 • Fastening strap Safety • Do not let children play with the GPS receiver as it contains small items. •... - Page 4 Connect to PC Connect the USB unit to the USB port in the computer, see Fig 1.1 Fig 1.1 Install drivers and software 1. Insert the CD in your pc. Click on ”Start” in Windows. Click on ”Computer”. Then double click on CD. 2.
- Page 5 Identify the colour lights on the GPS receiver Green LED indicates: battery is charging. Red LED indicates: battery is low and must be charged. Orange LED indicates: Point og interest. This function is to be activated by holding the ”Point of interest”...
- Page 6 Charge Status On/off button Point of interest Status. Point of interest button GPS Status...
- Page 7 Quick guide for your first trip • You now have ”Photo Tagger” software well installed on your pc. • Be aware of correct time settings in “Display Time Zone” on the top of the screen in “Photo Tagger”. And remember to click on “Daylight saving time”...
- Page 8 Concerning of Poor GPS Signal It is possible unable to receive GPS signal or signal low in these places: Beside buildings. GPS-signal is low Inside a tunnel. GPS-signal is blocked. or disturbed. Inside a forest or to many covers. Covers above. GPS-signal is blocked. GPS-signal is low or disturbed.
- Page 9 Used equipment must be disposed of in compliance with current environmental protection regulations. You should return it to your reseller or dispose of it in an approved recycling centre. DECLARATION: We hereby declare that this product complies with essential requirements and other related requirements, of the 1999/5/EC R&TTE directive and particularly with article 3 sections 1a, 1b and 3.
