ATD Tools ATD-5540 Instructions Manual

Automotive multimeter
Hide thumbs Also See for ATD-5540:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Enlarged version
ATD-5540
AUTOMOTIVE MULTIMETER
INSTRUCTIONS
-1
INSTRUCTION
Contents
Voltage(V) .........................................................
)
)
)
Electrical Speci cations
0
MANUAL
1
4
4
6
7
8
9
10
11
12
13
14
15
15
16
16
17
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATD-5540 and is the answer not in the manual?

Questions and answers

Dan Michaelson
March 27, 2025

I need to replace the battery in my ATD-5540 and the manual says to remove the 3 screws in the back there are no screws or holes in the back of the tester.

0
1 comments:
Mr. Anderson
March 27, 2025

To replace the battery in the ATD Tools ATD-5540:

1. Loosen the three screws in the case back.
2. Remove the case by lifting up and forward.
3. Replace the battery with a 9-volt alkaline battery.

If screws are not visible, they may be covered or recessed. Inspect the back closely for hidden screw covers and remove them to access the screws.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for ATD Tools ATD-5540

Summary of Contents for ATD Tools ATD-5540

  • Page 1: Table Of Contents

    INSTRUCTION MANUAL Contents Safety Meter Basics Meter Functions Voltage(V) ………………………………………………… ATD-5540 Resistance( AUTOMOTIVE MULTIMETER Diode Check( Audible Continuity( ) INSTRUCTIONS DC Current(A) RPM( Frequency(Freq) Dwell( ) Duty Cycle(%) Maintenance Fuse and Battery Replacement Trouble Shooting General Speci cations Electrical Speci cations...
