Mission Expressionator User Manual

NOTE: Changing SPAN is mainly for use with the raw
taper. For saw and square tapers, the span is not
changed, only the number of times the square/saw
cycles between toe and heel (so instead of eight, it
could be four). When setting extremely tight spans,
it may be necessary to move the treadle a full span
width before pressing the SET button.
INT NAL CV
SWITCH
Expressionator has an internal switch for each
channel to send +5 CV for use with devices that call
for it such as Moogerfoogers, etc.
WARNING: Sending control voltage to a pedal
that does not require it can seriously damage your
pedal! Do NOT flip this switch unless the device
specifically calls for it.
MEMORY
When powering off Expressionator, your current
active channel, ON status, current taper and span for
each channel, is retained.
CLê RING
MEMORY
To return Expressionator to factory default, hold
the SET and STOMP down simultaneously for five
seconds. When you see the three channel LEDs cycle,
memory has been cleared.
WARRANTY &
LIABILITY
We offer a one-year warranty on Expressionator.
Contact info@mission-engineering.com for more info.
Due to the nature of this product, we do not take
responsibility for damage to other products.
Thank you for
purchasing the
Expressionator!
©
Mission Engineering Inc. 2012. All rights reserved. Trademarks,
registered trademarks, product names, logos and other materials are
the property of their respective owners.
User
Guide
Mission
Enginî ring Inc.
www.mission-engineering.com
info@mission-engineering.com
