- Page 1 AMSynths AM8075SE Athena Filter User Manual 24dB/Octave Low Pass Filter & 6db/Octave High Pass Filter © AMSynths 2012 Rob Keeble, Owner & Designer Contact: sales@amsynths.co.uk Web Site: www.amsynths.co.uk...
-
Page 2: Table Of Contents
AM8075SE Athena Filter Contents Welcome Front Panel Connections & Controls Module Description Configuration Warranty & Support Specifications AMSynths Page 2... -
Page 3: Welcome
AMSynths modules are produced in low volumes, with each module having a unique holographic serial number and a certificate of ownership. You own a rare and beautiful analog synthesizer module that will provide many years of amazing sounds and musical inspiration. -
Page 4: Front Panel
AM8075SE Athena Filter Front Panel AUDIO INPUTS: InA, InB CONTROL INPUTS: CV1, CV2, CV3 AUDIO OUTPUTS: CONTROL POTS: Signal A (white) Signal B (white) Signal C (white) LP Frequency (blue) LP Resonance (red) HP Frequency (blue) CV1 (grey) CV2 (grey) The serial number is on a small silver holographic sticker on the inside of the front panel. - Page 5 AM8075SE Athena Filter Module Description The AM8075SE is a clone of the ARP 4075 4-pole 24dB low pass filter in the ARP Odyssey Mark 3, Omni, Quadra and Solus, and very similar to the ARP 4072 filter in later models of the ARP 2600. The module also has a single pole High Pass filter connected in series after the low pass filter.
-
Page 6: Connections & Controls
AM8075SE Athena Filter Connections & Controls The two uppermost jack sockets INA and INB are for connecting audio signals into the input side of the filter, these signals are mixed together. The level of each audio signal can be varied from nil to maximum using the front panel slide potentiometers SignalA and SignalB. -
Page 7: Configuration
The module should be connected to the 12V Doepfer style power bus within your case using the included AMSynths multi-way power cable. Ensure the power is OFF before connecting the module and BE VERY CAREFUL to ensure that the power connector to the bus is connected with the red stripe of the cable lined up with -12V (negative 12V). -
Page 8: Warranty & Support
Warranty & Support Repairs resulting from a defect of the module or its construction process are covered by a one year warranty, with the customer paying transit costs to AMSynths in the Damage to the module resulting from incorrect power supply... -
Page 9: Specifications
AM8075SE Athena Filter Specifications ower Supply: +12V, GND and -12V standard Doepfer 10 pin connector RED stripe on power cable is -12V (NEGATIVE 12V) Current consumption: Dimensions: 128.5mm (Height) x 70.8 mm (Width) Euro Rack Size: 16HP/TE Panel: 2mm machined aluminum with colour photographic print.
