– TR-CPQ

UICK

TART

UIDE

QUICK START GUIDE FOR THE

TRANZEO WIRELESS TR-CPQ

1.3

EVISION

IRMWARE

UILD

12, 2005

ECEMBER

This document is intended for Public Distribution

19473 Fraser Way,

Pitt Meadowse, B.C. Canada V3Y 2V4

Phone (604) 460-6002 Fax (604) 460-6005

www.tranzeo.com

12/12/2005

Table of Contents

Need help?

Do you have a question about the TR-CPQ and is the answer not in the manual?

Questions and answers

Summary of Contents for Tranzeo TR-CPQ

Page 1 – TR-CPQ UICK TART UIDE QUICK START GUIDE FOR THE TRANZEO WIRELESS TR-CPQ EVISION IRMWARE UILD 12, 2005 ECEMBER This document is intended for Public Distribution 19473 Fraser Way, Pitt Meadowse, B.C. Canada V3Y 2V4 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com...
Page 2: Safety Notices
Operation of this equipment in residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his or her own expense. The user should not modify or change this equipment without written approval from Tranzeo Wireless. Modification could void authority to use this equipment.
Page 3 Fully compliant with the IEEE802.11b standard, the TRANZEO TR-CPQ also provides powerful features such as the Internet-based configuration utility as well as WEP and WPA security. Maximize network efficiency while minimizing your network investment and maintenance costs.
Page 4 Amber Light up in sequence to indicate signal strength Power Supply ONLY use the power adapter supplied with the TR-CPQ. Otherwise, the product may be damaged. This document is intended for Public Distribution 19473 Fraser Way, Pitt Meadowse, B.C. Canada V3Y 2V4 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com...
Page 5 Before installing, you must determine if the unit will be in the horizontal or vertical orientation. The TR-CPQ model can be mounted in either orientation. The Ethernet boot should always be placed so that the cable runs toward the ground for maximum environmental protection.
Page 6 – TR-CPQ UICK TART UIDE Connecting the Ethernet Cable Step 1 Place the Ethernet Boot Cover over the end of your Cat 5 Cable. Attach the sticky side of the gasket to the underside of the Ethernet Boot. Step 2 Attach Ethernet Cable Lock on side of the Ethernet Boot.
Page 7 – TR-CPQ UICK TART UIDE Step 4 Repeat steps 2 & 3 to attach the second Ethernet Cable lock if you purchased the optional dual port boot. Step 5 Place Gasket over screws. Step 6 Remove gasket backing and place boot cover on radio.
Page 8 – TR-CPQ UICK TART UIDE Step 8 Place the Ethernet boot over the 4 Screw Posts. The screws should just barely clear the tightening bracket. Apply 4 Keep nuts to the screw posts and tighten until the gasket makes full contact with the Ethernet boot.
Page 9 – TR-CPQ UICK TART UIDE Connect the Power Cable Connect the power adapter to the power socket on the Power over Ethernet Adaptor, and plug the other end of the power into an electrical outlet. Plug the RJ-45 Cable from the unit into the POE.
Page 10: Html Interface
– TR-CPQ UICK TART UIDE HTML Interface NOTE: The default IP address is 192.168.1.100 The default User Name is admin The default Password is default Passwords When you first enter the Web Interface, you will be required to enter a new recovery password.
Page 11: Wireless Settings
– TR-CPQ UICK TART UIDE Wireless Settings SSID The SSID is a unique ID given to an Access Point. Wireless clients associating to the Access Point must have the same SSID. The SSID can have up to 32 characters. TX Rate The rate at which the radio will communicate with the clients.
Page 12: Administrative Settings
– TR-CPQ UICK TART UIDE Administrative Settings Image File Name Enter the location of the Bios update file, or use Browse to locate the file in your PC, and then press ‘Upgrade Software” Defaults Returns all settings to factory defaults.
Page 13: Security Basic
– TR-CPQ UICK TART UIDE Security Basic Enabled Turn On WEP Authentication Select Open or Shared Key Authentication Key Length Level of Encryption. NOTE: 64 bit is referred to as 40 bit on some systems Default Key Choose the default WEP key Activate Keys Enter your WEP keys.
Page 14 – TR-CPQ UICK TART UIDE AP List Shows list of available APs in the area This document is intended for Public Distribution 19473 Fraser Way, Pitt Meadowse, B.C. Canada V3Y 2V4 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com 12/12/2005...
Page 15: Network Configuration
– TR-CPQ UICK TART UIDE Network Configuration This page allows you to control the network configura- tion of the device. You can also choose Static or DHCP Client IP configu- ration for both the device and any associated IP clients.
Page 16: Dhcp Configuration
– TR-CPQ UICK TART UIDE DHCP Configuration Subnet Mask Subnet mask for the DHCP pool. Address Range Starting Address The starting address of the DHCP pool. Number of Addresses The number of addresses you want to have in the DHCP pool.
Page 17 – TR-CPQ UICK TART UIDE Static Routing Setup Screen Static Routes Adds a new route to the IP routing table. System Routes This section shows the current routing table entries. Interface Specifies whether the entry will be enabled or disabled, and what interface it should use transmit the packet.
Page 18 – TR-CPQ UICK TART UIDE Tranzeo QOS Setup Screen Menu Options Uplink Speed ( Mbps) Sets the maximum total pipe size for this client. Dynamic Fragmentation Re- duce delay for high- priority traffic and adaptive fragmentation where the fragmenta- tion is determined by the uplink speed.
Page 19 Information about the access point is displayed here. Some items will only be displayed if the Access Point is a Tranzeo TR-CPQ series AP NOTE ABOUT TX RATE: This field shows the value that the signal is capable of. If you have locked the data rate to a lower rate, this number may exceed that value.
Page 20 What standard does Tranzeo Wireless equipment meet? This radio exceeds International Standard IEC 61000-4-5 when properly grounded. For a copy of the full testing report, see Report Number TRL090904 - Tranzeo Surge Protection board located on the Tranzeo website. Is lightning damaged covered by the Warranty? No.
Page 21 – TR-CPQ UICK TART UIDE Where to Ground the device This radio must be grounded at the Pole AND at the POE. This is because the radio is between the Exterior Antenna and the POE ground. See the examples below...
Page 22 – TR-CPQ UICK TART UIDE Ungrounded POE Mounting Pole In this case, the surge will be picked up by the Cat 5 cable, and since the POE is not grounded, the route for the surge is through the radio to the antenna, and out through the building.
Page 23 – TR-CPQ UICK TART UIDE Best Practices 1) Always try to run the Cat5 and LMR inside of the mounting pole wherever possible. This helps to insulate the cable from any air surges. Building Cat 5 Cable 2) Keep all runs as straight as possible. Never put a loop into the cables.
Page 24 FTP transfer in the upstream direction will reduce the Mean Opinion Score (MOS) for a G.729 VoIP codec from a very good 4.4 to a completely unacceptable level of 1 immediately. Using the same scenario with Tranzeo Wireless Technologies’...
Page 25 – TR-CPQ UICK TART UIDE Examples: Non-latency- sensitive traffic Low – Priority or excess Traffic This document is intended for Public Distribution 19473 Fraser Way, Pitt Meadowse, B.C. Canada V3Y 2V4 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com 12/12/2005...
Page 26 – TR-CPQ UICK TART UIDE This document is intended for Public Distribution 19473 Fraser Way, Pitt Meadowse, B.C. Canada V3Y 2V4 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com 12/12/2005...
Page 27 Reply from 66.94.230.45: bytes=32 time=21ms TTL=50 Reply from 66.94.230.45: bytes=32 time=21ms TTL=50 RTT on a Tranzeo Wireless Technologies QOS enabled router Repeating the same “ping” test with background traffic on a Tranzeo Wireless Technologies router This document is intended for Public Distribution 19473 Fraser Way, Pitt Meadowse, B.C.
Page 28 Reply from 66.94.230.37: bytes=32 time=26ms TTL=50 Reply from 66.94.230.37: bytes=32 time=34ms TTL=50 Note: These results were obtained on a system with a quoted 256Kbps upstream capacity. The Tranzeo Wireless Technologies router was configured to use the Dynamic Fragmentation setting with Automatic Classification. FAQ: q.
Page 29: Appendix C - Ip Protocol Numbers
– TR-CPQ UICK TART UIDE APPENDIX C – IP Protocol numbers. This is a list of currently assigned IP protocol numbers as of time this document was written as defined in RFC 1700. Decimal Keyword Protocol Decimal Keyword Protocol =======...
Page 30 – TR-CPQ UICK TART UIDE Decimal Keyword Protocol Decimal Keyword Protocol ======= ======= ======== ======= ======= ======== NSFNET-IGP NSFNET-IGP VRRP Virtual Router Redundancy Dissimilar Gateway Protocol PGM Reliable Transport any 0-hop protocol EIGRP EIGRP L2TP Layer Two Tunneling Protocol OSPFIGP...
Page 31: Appendix D - Common Tcp Ports
– TR-CPQ UICK TART UIDE APPENDIX D – Common TCP Ports http://www.iana.org/assignments/port-numbers for a full list of Well Known Port Numbers. Keyword Port Description ======= ==== =========== ECHO Echo SYSTAT Active Users QOTD Quote of the day Message Send Protocol...
