Summary of Contents for FLO TV TV Accessories
- Page 1 Installation Manual...
- Page 2 Warning and Safety Information FCC Information This device complies with FCC Rules Part 15 Operation and is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, including interference that may cause undesired operation.
- Page 3 UHF channel 55 (720 MHz) and is multicast from terrestrial towers. Coverage will vary and reception is dependent upon the FLO TV module in your vehicle being within range of the towers. Coverage area can be viewed on the FLO TV web site (www.flotv.com).
- Page 4 Installation of the FLO TV product requires careful planning and preparation. Be extremely careful of the airbags in vehicles and not to have any FLO TV component or wire harness interfere with them. Keep wiring away from any air bag wiring (usually identified by yellow connectors and yellow wire jackets).
- Page 5 FLO TV Kit Contents The following items are included with your purchase of the FLO TV kit. FLO TV Module FLO TV Antenna Wired Remote Control with Antenna Wireless RF Remote Control - 5 -...
-
Page 6: Main Wire Harness
FILTER BOX Main Wire Harness RCA Male to Male Harness NOTE: The FLO TV kit also includes an antenna tail, antenna tape pad, owner’s manual, this installation manual, and a hardware kit that includes four wire ties. - 6 -... - Page 7 Connectors and Controls The illustration below details the FLO TV Module connectors for quick reference. FLO TV Antenna Connector Main Wire Harness Connector Wired Remote Control Connector FLO TV Module Connectors FLO TV Antenna Connector Antenna connection for the FLO TV antenna...
- Page 8 Vehicle Preparation 1. Read the manuals to become familiar with the electrical requirements and connections of the FLO TV kit. 2. Prepare the vehicle by removing any interior trim necessary to gain access to the vehicle’s wiring as well as areas where the interconnecting wire harnesses will be located.
- Page 9 Wiring Diagrams An overview of the FLO TV kit wiring diagram for connection to a Factory Vehicle Entertainment System (VES) is shown in Figure 1 below. FILTER BOX Figure 1 – FLO TV Wiring Diagram with Factory VES & A/V Input...
- Page 10 To connect the FLO TV kit to a Factory Vehicle Entertainment System (VES), via the connectors between the Factory VES and A/V input, follow the diagram shown in Figure 2. This installation is possible if mating connectors between the Factory VES and Factory A/V input are available.
- Page 11 An overview of the FLO TV kit wiring diagram for connection to an aftermarket Vehicle Entertainment System (VES) is shown in Figure 3 below. FILTER BOX Figure 3 – FLO TV Wiring Diagram with Aftermarket VES - 11 -...
- Page 12 The FLO TV Module has four mounting holes for securing the FLO TV Module to the vehicle by use of the included wire ties or by other means. If screws are used to mount the FLO TV Module, do not over tighten as the plastic case may be damaged.
- Page 13 Mounting options for the FLO TV Antenna will vary depending upon the vehicle. These instructions are meant to be a guide. The following steps detail the recommended permanent installation of the FLO TV Antenna utilizing the antenna magnet and double sided adhesive tape pad.
- Page 14 4” 4” 4” 4” Figure 4 – FLO TV Antenna Placement - 14 -...
- Page 15 FLO TV Antenna. 5. Starting at the strain relief on the FLO TV Antenna, attach the antenna tail to the FLO TV Antenna. Press the antenna cable into the wire track in the antenna tail. (See Figure 5, FLO TV...
- Page 16 6. Clean the surface area of the vehicle where the FLO TV Antenna and antenna tail will be installed. Ensure that the vehicle surface is clean and clear of any dirt or debris. 7. Remove the plastic liner from the adhesive backing on the bottom of the FLO TV Antenna.
- Page 17 Routing the Antenna Cable When the antenna has been mounted on the vehicle, the antenna harness can be routed to the FLO TV Module. 1. Route the antenna cable from the antenna mounting position to the interior of the vehicle, working the cable under the rear window molding.
- Page 18 Figure 7 – Routing the Antenna Cable - 18 -...
- Page 19 Locate the antenna 2 inches below the top of the windshield (see figure 8), remove the adhesive backing and press the antenna to the windshield. 3. Connect the 8 pin connector on the remote control to the 8 pin connector on the FLO TV Module.
- Page 20 2.0 “ Antenna Figure 8 – Remote antenna placement - 20 -...
- Page 21 Input Power Connection The main harness for the FLO TV Module contains a filter box for the 12V ACC line connection. The main harness also has an in-line fuse for the ACC connection. Connect the ACC input wire to an ignition switch input power line or a switched accessory power line.
- Page 22 The Audio/Video Output connectors on the Main Harness provide the audio and video output from the FLO TV Module, which must be connected to the vehicle’s factory VES. Refer to Figure 1, herein, for an overview of the wiring diagram.
- Page 23 Route the RCA Male to Male Harness from the VES Audio/Video Input jack location to the FLO TV Module installation location. Connect the RCA Male to Male Harness to the Audio and Video Outputs on the FLO TV Module Main Harness.
- Page 24 If mating connectors are available for the connectors between the Factory VES and the Factory A/V Input, as indicated in Figure 2, the FLO TV A/V Input and Output can be connected there. This allows the end user to maintain the use of the Factory A/V Input.
- Page 25 Route the RCA Male to Male Harness from the FLO TV Module installation location to the Audio Video Input location of the aftermarket VES. Connect the other end of the RCA Male to Male Harness to the Audio and Video Inputs of the aftermarket VES.
- Page 26 OFF will run down the vehicle’s battery.) 2. The VES screen will show the FLO TV splash screen and then the FLO TV preview channel. FLO TV 3. If you are not subscribed, subscribe to the service by calling 888-99-FLOTV or by going on line to www.flotv.com.
- Page 27 9. Press the (Settings) key on the remote to access the FLO TV user settings menu (e.g. Parental Control, etc.). FLO TV 10. The (Mode) key on the remote allows the user to switch between the service and an auxiliary A/V source if one is connected.
-
Page 28: Troubleshooting Guide
Antenna Wire is broken Verify that the antenna wire is not broken. Acquiring Signal is displayed FLO TV Signal is not being The FLO TV Antenna is obstructed or the vehicle received. is out of the coverage area. Poor or No Audio... - Page 29 FLO TV Output not selected Press the MODE button on the wired or wireless remote control to provide FLO TV to the vehicle’s rear seat entertainment system. Vehicle’s Rear Seat Change the source inputs on the vehicle’s rear...
- Page 30 Troubleshooting Guide (Cont) Problem Root Cause Solution Wired Remote Control does not Wired Remote Control not Verify that the Wired Remote Control connector is work Connected connected to the FLO Module. Wireless Remote Control does not Batteries installed incorrectly Verify that the two AAA batteries are installed work properly per the polarity markings.
- Page 31 - 31 -...
- Page 32 128-8593A Copyright © 2010 Audiovox Corporation 1.26.2010 - 32 -...
