Summary of Contents for D3 Media LCD Media Player
-
Page 1: User Manual
Media USER MANUAL D3 MEDIA LCD INSTRUCTIONS... -
Page 2: Table Of Contents
Table of Contents ●Safety Instructions ●Introduction ●Using the Remote Control P 4-5 ●Basic Operating Steps P 6-7 ●Inserting Memory Cards ●Set Timer & Timer Function P 8-9 ●Playback using File List Function P10-11 ●Standard Playback P11-12 ●Changing the Data Source ●USB File Transfer P13-14 ●Power interruption... -
Page 3: Safety Instruction
5. Avoid operating the D3 Media player in extremely hot or damp environments. 6. Do not open the unit or attempt to repair this product. The D3 Media should only be repaired by authorized dealers. D4 Display Inc does not accept any responsibility for damage due to illegal or incorrect use of this product or if tampered with by unauthorised personnel. -
Page 4: Introduction P
The D3 Media player integrates innovative LCD technology with an internal flash drive that allows you to play movies, animations, music and slide shows without the need for a computer or DVD player. The D3 Media display is a unique freestanding display that is low voltage and low energy consumption Features 1. -
Page 5: Using The Remote Control
Press “TIMING/A-B” button for the first time in playing mode to choose starting point A. Press “TIMING/A-B” for the second time to choose the ending point B. Then the D3 Media will repeat playing the chosen clip A-B. Press “TIMING/A-B” again to cancel this function. - Page 6 Press “Cancel” to end the selected choice in Timer setting mode. Cancel Pressing the “Time” button in playing mode will display the current Time time. Press again to cancel Brings up the Menu Menu CVBS, VGA selection button AV/VGA Volume up and down adjustment Volume +/- Press “A/M”...
-
Page 7: Basic Operating Steps
●Basic Operating steps 1. Play Insert CF card with video files, connect the power adaptor to the power outlet, device will automatically play until power off. No manual intervention required. 2. Configuring the Player The setup menu allows you to configure the operation of the player .You can change OSD languages, TV Display, TV Type, create a Play List, function and configure other aspects of the display behavior. -
Page 8: Inserting Memory Cards
The first set of daily timer ON: 08-20. Other sets: OFF. ●Inserting Memory Cards Unlock the access port on the left hand side of the D3 Media player, using the key provided with the unit. Insert CF and SD cards with the label facing towards the front of the unit. Do not force the memory card into the memory slot. - Page 9 ●Main timer setup Press “TIMING/A-B”; the main clock will appear as shown in (picture 3) (PICTURE 3) To set the clock the day of the week, hour, minute and seconds can be entered using the ▲▼ navigation buttons or the number key pad. ●Timer function –...
- Page 10 Choose different days of the week by pressing navigation buttons. Choosing a day is confirmed by pressing button. Then “INPUT” instruction will be displayed in the upper left corner of the screen. Press navigation buttons to make changes between ON and OFF. “ON”...
-
Page 11: Playback Using File List Function
●Playback using file list function This function allows you to pre program up to a maximum of 12 files stored on the CF card for continuous playback on each day of the week. How to set a file list: Go to “Configuring the player” on page 2, choose the “Play list” function and turn it on With the player stopped, press the “mute”... -
Page 12: Standard Playback
1. Power on When the D3 Media is plugged in, if no CF or SD card has been inserted the screen will display a “No Disc” message as shown in (picture10). Turn the unit off again and insert a CF or SD card before restarting. - Page 13 With a CF card inserted the content menu screen will appear as shown in (picture11) and the files listed will play repeatedly when the “ button is pressed. Use the ▲▼ buttons to highlight the files and choose which file will commence the playback cycle. Press the button to stop playback PICTURE 11...
-
Page 14: Changing The Data Source
PICTURE 13 If only one card is inserted in the D3 Media it will automatically be chosen to start playback. 3. USB File Transfer We can use the USB port to update the CF/SD card contents; we can also use the remote control to delete, shift and rename the CF/SD card contents. -
Page 15: Power Interruption
CF/SD card and copy the files using a computer with CF/SD card reader. ●Power interruption When the D3 Media is running a program if there is power outage, play will resume from the stop point once power is restored.
