Summary of Contents for Vido AU-KB3N

  • Page 1 KB3N Multi-functional Programmable Controller User's Manual...

  • Page 2: Table Of Contents

    WARNING CONTENTS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO 1. Precaution............1 RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. 2. Features............2 3.

  • Page 3: Precaution

    2.FEATURES - Refer all work related to the installaion of this product to qualified service The AU-KB3N is a multi-funcational, programable keyboard controller for Pan-Tilt-Zoom personnel or system installers. device, Digital Video Recorder and Matrix devices, and can be programmed with individual protocol setting for each connected device.

  • Page 4: Operation

    5. OPERATION 5. OPERATION Key Description After power on, keyboard will start the KB3N-Vxx<01> initialization and self-test. The LC-Display will System Keyboard show initial screen. Press Menu to start the operation. LCD Display with back light KB3N Power Operation Screen: MON--- ALM- Operation...

  • Page 5: Keyboard Setup

    6. KEYBOARD SETUP 6. KEYBOARD SETUP In order to get all advantages and functions, it is strongly recommended to SET DVR CHANNEL: When multiple DVRs are used, the keyboard can map the DVR- setup your keyboard before operation. channel input to a certain PTZ's ID. Once the DVR's channel is changed, the PTZ which responding to this channel will be selected automatically.

  • Page 6: Woking With Ptz

    6. KEYBOARD SETUP 7.Working with PTZ SET KEY ID: Set up the ID of the controller from 01 to 63. Start PTZ mode Input the No. by digit-key. After setting, press ENTER to save or CLR to exit the By default, the keyboard usually starts in PTZ mode (display shows as below). You can setting.

  • Page 7: Working With Dvr

    7.Working with PTZ 7. Working with DVR 6.Working with PTZ Enter DVR mode Tour - Sequence LED for A sequence can store up to 24 preset points with individual dwell time and speed. You To control DVR, press the DVR-Button and enter the DVR Mode KB3N can store a sequence by using this function.

  • Page 8: Connection

    8. Working with DVR 9. Multiplexer Function key for NVIDO DVR Control Multiplexer in MUX mode LED for Function Press the MUX button to enter the Multiplexer mode. MUX Mode KB3N Enter DVR Menu Power SHOT MENU Enter Enter Key Hold 4 Cut MUX_ID:01...
  • Page 9 10. Appendix 11. Note RS-485 Termination Devices using RS485 control are usually connected in daisy-chain. which reqiuers termination with 120 resistor on both ends. Following picture illustrates the connection methods. please note that a daisy-chain connection type shall not exceed 7 meters. RS 485+ RS485 Distributor...
