S2P KS2P-18C210 Owner's Manual

Outdoor evaporative air cooler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Evaporative Air Cooler
OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
Read
all instructions
carefully before
setting up and operating this unit.
This
manual is designed to provide you with
important information needed to setup,
operate, maintain, and troubleshoot your
cooler. Failure to follow these instructions
may damage and/or impair its operation
and void the warranty.
OUTDOOR EVAPORATIVE AIR COOLER
MODEL NO.: KS2P-18C210
1

Advertisement

Table of Contents
loading

Related Manuals for S2P KS2P-18C210

Summary of Contents for S2P KS2P-18C210

  • Page 1 Failure to follow these instructions may damage and/or impair its operation and void the warranty. OUTDOOR EVAPORATIVE AIR COOLER MODEL NO.: KS2P-18C210...
  • Page 2 Adopting the most advanced evaporative cooling technology in the world and the contemporary production management system, this installation manual is specific for KS2P-18C210 evaporative air cooler. To ensure the optimal efficiency, we recommend you to read the manual carefully before use.
  • Page 3 5. The exclusive fan blades produce large airflow and create little noise; 6. Filter pads are easy to clean and maintain; 7. Patented open-style water diffuser ensures high efficiency and stable water supply; 8. Multi-lever air flow regulator. KS2P-18C210 technical details Model no. KS2P-18C210 Voltage...
  • Page 4 Evaporative Air Cooler Product dissection and spare parts Main components: Motor:  high efficiency, low noise, strong power volume  Full prot ection against over current, over voltage and overload  Unsurpassed reliability Cont rol box:  Micro-computer control, easy upgrade, can design for customer special requirement ...
  • Page 5 Evaporative Air Cooler Fan blade:  Made up of 6 pieces of high-rigid and fibrous plastic  All pieces can be adjusted the prefer angle  Strong wind volume Drain valve:  Automatic water draining every 8hours  Prevents algae growth ...

  • Page 6: Important Notes

    Evaporative Air Cooler Check up and adjustment before operation: Is the cooler installed horizontally? Is drain pipe connected to the machine? Is the wat er supply leaking? Adjust water level in the sump? Is the power supply connected correctly (particularly for three phase machine)? Is the power line for the control panel correctly connected? Is the operation current within the rated range? Is there unwanted object in the vent?

  • Page 7: Packing And Transportation

    Evaporative Air Cooler Packing and transportation 1. Packed in carton on wood pallet. 2. Keep dry and upright. 3. Do not pile more than 2 units. 4. Keep the unit vertical during transportation. The tilt angle shall be less than 60 degrees. Operating Instructions Installing the casters: Locate the casters inside of the cooler and attach them to the cabinet bottom.

  • Page 8: Turn On/ Turn Off

    Evaporative Air Cooler Operating approach of RTC wall controller for KS2P-18C210 1. TURN ON/ TURN OFF 1) Press the button of , you can turn on and turn off evaporative air cooler manually . 2) Hold button down for 5 seconds, the wall controller will get back to the ex-factory setting, restart.
  • Page 9 Note: The EXHAUST function does not apply to all machines, it will be taken effect only for INVERTER evaporative air coolers. If your controller does not support the EXHAUST function, the button is not available. (KS2P-18C210 without EXHAUST function) button is used to select VENT(fresh air been delivered into rooms, but the air doesn’t been cooled).

  • Page 10: Auto-Cleaning

    Evaporative Air Cooler Note: The pump protection also happens on water shortage when cool function been turned Picture 4-1 turn on VENT and COOL Picture 4-2 pump stop running (low water) 5. CLEAN Drain function makes motor run by contraries to clean cooling pad, turn on the drain valve, drain the dirty water out.
  • Page 11 Evaporative Air Cooler will be 00 → 04 → 08 → 16 → 32 → 48 → 00 (in hours). If the Auto-cleaning cycle is 00H, the Auto-cleaning function been cancelled. When set Auto-cleaning cycle, the screen will show the cycle of Auto-cleaning(as shown in picture 6-1), Auto-cleaning cycle is 08-hour.
  • Page 12 Evaporative Air Cooler take an example of manual mode (MANUAL). 8.1 TIMING TURN ON The processes are as follows: button, the screen will show “--:--“, “ON” is flashing, means timing turn on function 1) Press the doesn’t be set, like the picture of 8-1. 2) Press button, --:-- changes to 00:00, and the hour is flashing, use button to changes...
  • Page 13 Evaporative Air Cooler 8.2 TIMING TURN OFF The processes are as follows: button, and the screen will show “18:40”, “ON” is flashing, means the machine will 1)Press the be turned on at 18:40; see the picture of 8-5. button, and the screen will show “--:--“, “OFF” is flashing, means timing turn off function 2) Press doesn’t be set;...
  • Page 14 Evaporative Air Cooler Picture 8-9 finish the settings of timing turn on/off 8.3 CANCEL TIMING The processes are as follows: button, the screen shows “18:40”, “ON” is flashing, time of turn on is 18:40, 1)Press the see the picture of 8-5. button, the screen shows “23:30”, “OFF”...

  • Page 15: Manual Mode

    Evaporative Air Cooler Picture 8-12 timing function been cancel 9. MODE Note: This feature does not apply to all machines, it will be taken effect only for evaporative air coolers with Relative Humidity and Temperature Detecting functions. If your controller does not support the Relative Humidity and Temperature Detecting functions, ℃...
  • Page 16 Evaporative Air Cooler preconcerted temperature. When the mode switch to AUTO℃, the icons of AUTO℃, FAN and COOL will be shown on screen, FAN and COOL functions will be turned on automatically, use buttons to change speed. As shown in picture 9-3, current temperature is 27℃, the preconcerted temperature is 25℃, FAN and COOL functions been turned on.
  • Page 17 Evaporative Air Cooler FAN and COOL functions will be turned on automatically, use button to change speed. (as shown in picture 9-6), the current relative humidity is 56%, preconcerted relative humidity is 60%, FAN and COOL functions been turned on. The default temperature on AUTO% mode is 60%, if want to change, press button, the preconcerted temperature will flash(as shown in picture 9-7), use...
  • Page 18 Note: This feature does not apply to all machines, it will be taken effect only for evaporative air coolers with EXHAUST function. We suggest you consult to sellers before you operate this settings. (KS2P-18C210 without this function) If your wall controller is designed to intelligent cleaning mode, when clean the air cooler, the motor will run by contraries, and cooling pad been soaked.

  • Page 19: Cleaning Mode

    Evaporative Air Cooler If intelligent cleaning mode is enabled, press the button, the cooler will operate as follows: (1) The motor will run by contraries and exhaust air. If the current air cooler is venting, the venting function will be stopped. 25 seconds later, exhaust function be opened automatically.
  • Page 20 Evaporative Air Cooler Picture 12-1 turn on the SHUTDOWN 12-2 turn off the SHUTDOWN CLEANING MODE CLEANING MODE Picture 13. SUGGESTIONS 13.1 COOL ICON FLASHING COOL icon flashing (as shown in picture 4-2), indicates the water tank with low water level. In order to product the pump, the pump will pause, and work again when water is enough.

  • Page 21: Maintenance

    Evaporative Air Cooler ”E3” flashing indicates, the voltage supply to air cooler is under -voltage, (lower than 140V or phase failure). Please break the power off, and check the power supply. "E8" flashing indicates, the wall controllers can’t receive the signal from air cooler, tr y to pull out the signal line, and re-plug, pay attention to the good connection on communication interface.

  • Page 22: General Problems

    Evaporative Air Cooler General problems Number PROBLEM PROBLEM CAUSE SUGGESTED REMEDY NOTE Air cooler fails to Power cut or incorrect Check input pressure and Suggest to check using run and no input power supply reconnect as requirement pressure meter response to all connect with electricity buttons, and the Fuse or switch break...
  • Page 23 Evaporative Air Cooler operate Loose electrical Tighten connections connections Pump run but Pump strainer clogged Clean stainer does not circulate or dirty water or pads lack Blocked water supply Clean the tubing water tubing Blocked water Clean the water distributor distributor a top of pad frames Continuous...

  • Page 24: Warranty

    4. The warranty does not cover the cost of a service call at the site of installation to diagnose cause of trouble, the c ost of labor to install the part, or mileage allowance to or from the site. S2P does not pay freight or postage on any exchange.
