Installation and Operation Manual
BLM100 BLM200
BLM700 BLT700
Warning
RISK OF ELECTRIC SHOCK OR ELECTROCUTION
The electrical supply to this product must be installed by a licensed or certified electrician in
accordance with applicable national and local codes and ordinances. Improper installation
may cause electrical hazard, which could result in death or serious injury to pool or spa
users, installers or others, and may also cause damage to property.
Read and follow the specific instructions inside this manual.
Swimming Pool Heat Pump
BLM400
BLM800
BLM500
BLT800
1
BLM600
BLT900

Advertisement

loading
Need help?

Need help?

Do you have a question about the BLM200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aquant BLM200

  • Page 1 Swimming Pool Heat Pump Installation and Operation Manual BLM100 BLM200 BLM400 BLM500 BLM600 BLM700 BLT700 BLM800 BLT800 BLT900 Warning RISK OF ELECTRIC SHOCK OR ELECTROCUTION The electrical supply to this product must be installed by a licensed or certified electrician in accordance with applicable national and local codes and ordinances.
  • Page 2: Table Of Contents

    Contents Ⅰ Working Principle and composing Ⅱ Main characteristics Ⅲ Technical data. 5 Ⅳ Electric circuit diagram Ⅴ Operation instruction Ⅵ Instructions and notices for installation Ⅶ Safety Cautions Ⅸ Troubleshooting and solutions...
  • Page 3: Ⅰ Working Principle And Composing

    Ⅰ、Working principle and composing 1、Composing A water heater is basically composed of a compressor, an evaporator, some capillary or expanding valves and a condenser. 2、Working principle Heat pumps use electricity to capture heat and move it from one place to another. They don't generate heat.
  • Page 4: Ⅱ Main Characteristics

    Ⅱ、Main characteristics 1、Efficient and economical The unit's Coefficient of Performance(cop)≥ 4.0. In comparison, an electric boiler (cop)≤0.95, a gas or oil boiler (cop) is about 0.5--0.8,a coal-boiler(cop) is only about 0.3--0.7. 2、Safety ensured When the unit is working, all electrophorus parts are absolutely isolated from circulating water, thus avoiding some possible dangers such as explosion, dry heating, gas poisoning, which may happen with a common water heater.
  • Page 5 6、Operation convenient The unit is controlled by microcomputer. According to the condition of water temperature and circular water volume, the unit will adjust itself. There is no need for anybody to keep on watching it. 7、Automatic defrost function With intelligent zed defrost function, you can set defrost condition according to different climates to make the unit defrost in a flexible way.
  • Page 6: Ⅲ Technical Data

    Ⅲ、Technical Data 1/2HP 2.5HP Model ASTRAL BLM100 BLM200 BLM400 BLM500 BLM600 BLM700 BLT700 BLM800 BLT800 BLT900 BTU/H 10200 14000 29000 34000 43000 58000 58000 72000 72000 85000 HEATING CAPACITY 3000 4200 8500 10000 13000 17000 17000 21000 21000 25000 HEATING POWER INPUT...
  • Page 7 ○ ! NOTE: Rated conditi o n: Circumstance dry bulb temperature :24℃ Inl e t water temperature:27℃...
  • Page 8: Ⅳ Electric Circuit Diagram

    Ⅳ、Electric circuit diagram BLM100 BLM200 BLM400 BLM500 BLM600...
  • Page 9 BLM700 BLM800 BLT700 BLT800 BLT900...
  • Page 11: Ⅴ Operation Instruction

    Ⅴ、Operation instruction Panel:  What¡s the meaning of the index lights on the panel? The function of the LED on the panel is showing below: Index Name Light Flash Light Temp In the state of Setting temp setting Refrigeratio Ready to refrigerate, in the state of Refrigerating compressor start delay protection Ready to heat, in the state of compressor...
  • Page 12 then exit the state of parameter setting. (The setting temp range is limited by the parameters F13 and F14, please refer to the advanced operation). Pressing the key ¡M¡ in the setting process means cancel and exit, but the setting value will not be saved.
  • Page 13 refer to the temperature controlling Max setting Notice: the ℃/℉ -58 - 302 temperature controller will follow the rule of F14<F11<F13 forcibly, if you find out that one parameter can not be adjusted, it is Min setting ℃/℉ -58 ¨ 302 because the temperature parameter is...
  • Page 14 Water pump stops time after 0 ¨ 10 compressor stops Water pump stop time 1 ¨ 99 Water pump run time 1 ¨ 10 0: without external alarm always open, unlocked External alarm always open, 0 -- 4 mode locked 3: always closed, unlocked Alarm...
  • Page 15 OFF means no password F80 Password 0001 -- 0000 means 9999 clearing password C: Centigrade Temperature unit F: Fahrenheit Display accumulative hour running time System Accumulative setting running time reset The controller will stop if the accumulative time is over probation F87 Probation time hour 1 -- 9999...
  • Page 16 refrigerating when the temperature is under ¡setting temperature¡, the controller begins to heat when the temperature of the temperature sensor is under ¡setting temperature - Auto mode temperature difference¡, and it stops heating when the temperature is over ¡setting temperature¡.(Attention: when set F17<F12, F17=F12 admitted) Compressor delay time The compressor delay time is set by F21, for example, 3 minutes.
  • Page 17 The process above can only run in heating state, in other words, the controller will not turn on defrosting in non-heating state. Air defrost mode: when start defrost, the compressor stop running ,the fan continue running; when stop defrost the compressor and fan continue running; 4 way valve defrost mode: when start defrost,the compressor and fan continue running,the four-way valve energized;when stop defrosting the compressor and fan continue running, the four-way valve powered off.
  • Page 18 controller will ensure that whether need to heat according to water temperature, otherwise the current time is in or not in the setting period of time, if it is not in the setting period of time, then the controller will not heat whether the water temperature is high or low.
  • Page 19: Ⅵ Instructions And Notices For Installation

    Notice: 1. Please read the guide carefully before using, and set the parameter accurately. 2. Please place the temperature sensor at the place of air return of the air-cooler. 3. Please use the temperature sensors which are supplied by our company. Ⅵ、Instructions and notices for installation 1、Materials Needed For Installation:...
  • Page 20 NOTE: Flex conduit is recommended for connecting the electrical supply wires to the heat pump so that the front panel may be removed easily for servicing. 2、The requirements for heat pumps include the following  Appropriate site location and clearances; ...
  • Page 21 5、Indoor Installations See Figure 1 (Standard plumbing Layout, Indoor) Figure 1 CHEMCAL LOOP OR OPTIONAL CHLORINE GENERATION SYSTEM CHECK (JANDY AQUAPURE VALVE POOL HEATER SHOWN) FILTER CHEMICAL FEEDER POOL PUMP SENSORS FROM POOL SPA TO POOL OR SPA 5.1、Condensation and Drainage Condensation from the evaporator coil will occur while the unit is running, depending upon ambient air temperature and humidity.
  • Page 22 Heat Pump to Heat Pool Pool Heat Pump to Heat SPA Pool 3- way valve Filter Filtration pump 6.2、Independent Filtration System Heat pump to Heat Pool Pool Heat pump to Heat Spa Pool 3- way valve Filter Filtration pump 7、Multiple Heat Pump Connections All plumbing on multiple heat installations must be done in parallel (see figures 2 and figures 3).An equal flow of water to each heat pump is important for optimum operation.
  • Page 23 Figure 2 12inches(30.5cm)min,clearance around evap NOTE! Gate Valves are optional on heater inlets but will help system balancing Extend 12"(30.5cm) past end heater inlet for hydraulic balancing Flow Meter 2"(5.1cm)PVC OPTIONAL 2"(5.1cm)Gate Valve Bypass POOL PUMP TO POOL Figure 3 12inches(30.5cm)min,clearance around evap NOTE! Gate...
  • Page 24: Ⅶ Safety Cautions

    8、Instructions and notice for installation  ○ ! The place which the unit is installed must be sturdy and able to withstand its weight. If not, it is possible that the unit fall off and be destroyed.  ○ ! The electrical system must comply with the local regulations and rating data in the technical sheet, and the power supply must be separate.
  • Page 25: Ⅸ Troubleshooting And Solutions

    Do not spray flammable chemicals around unit to avoid fire. Ⅷ、Troubleshooting and solutions SYMPTOM CORRECTIVE ACTION Heat pump will Breaker or fuse may be tripped. Reset breaker or check fuse. If not start, no heat pump still does not run,call for service. Three-phase models control board only the phases may be reversed or there may be a loss of phase, display...
  • Page 26 Heat pump runs Verify cold air is blowing out the top of the heat pump. If the heat but does not heat pump has just been installed or if the pool water has been allowed to cool significantly, it is necessary to run the heat pump continually, it is necessary to run the heat pump continually for 24-48 hours.
