Solar 3C 3C382B Installation, User And Service Manual

Domestic hot water cylinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Version 6.1
14/07/2014
Installations, User and Service Manual
Section A
Domestic Hot Water Cylinder
3C382B | 3C510B | 3C382HP | 3C510HP
Section B
Solar 3C Heating System
Important -This manual should be left with the cylinder after installation
Solar 3C
01242 253817
tech@solar3c.com
Solar 3C
Unit 1
20 Winchcombe Street
Cheltenham
GL52 2LY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3C382B and is the answer not in the manual?

Questions and answers

Summary of Contents for Solar 3C 3C382B

  • Page 1 Version 6.1 14/07/2014 Installations, User and Service Manual Section A Domestic Hot Water Cylinder 3C382B | 3C510B | 3C382HP | 3C510HP Section B Solar 3C Heating System Important -This manual should be left with the cylinder after installation Solar 3C 01242 253817 tech@solar3c.com...
  • Page 2 Installations, User and Service Manual Section A Domestic Hot Water Cylinder 3C382B | 3C510B | 3C382HP | 3C510HP Important - This manual should be left with the cylinder after installation...

  • Page 3: Table Of Contents

    This coil, sat in a reservoir of energy hopefully supplied via the solar thermal collectors, will enable the energy to be taken from the cylinder indirectly to the heating load via the Solar 3C purpose control box and jig.

  • Page 4: Technical Specifications

    2. Technical specifications Solar 3C 3- Coil Indirect Cylinders 3C382B 3C510B 3C382HP 3C510HP Storage capacity (litres) Overall diameter (mm) Overall diameter incl. immersion heater mm Overall height with exp. vessel on cold feed supply (mm) 2100 2057 2100 2057 Weight when full (kg)

  • Page 5: General Requirements

    4. General requirements 4.1. The Solar 3C domestic hot water cylinder MUST be installed by a competent person in accordance with WRAS and section G3 of the current Building Regulations. 4.2. Important - It is important that the installer reads and understands these instructions, unpacks and familiarises themselves with the equipment before commencing the installation.
  • Page 6 Fig.1a. Solar 3C Cylinder Three Coil pipe work connections - 382B and 510B cylinders HOT OUT 'SOLAR3C' OUTPUT COIL SOLAR3C ONLY PROBE SECONDARY RETURN 11 10 CYLINDER STAT BOILER INPUT COIL SOLAR INPUT SOLAR COIL HIGH-LIMIT STAT SOLAR SYSTEM COLD IN...
  • Page 7 Fig.1b. Solar 3C Cylinder Three Coil pipe work connections - 382HP and 510HP cylinders HOT OUT 'SOLAR3C' OUTPUT COIL SOLAR3C ONLY PROBE SECONDARY RETURN HEAT PUMP INPUT COIL CYLINDER STAT *3C382HP ONLY SOLAR INPUT COIL SOLAR HIGH-LIMIT STAT SOLAR SYSTEM...

  • Page 8: Primary Circuit Installation

    5.2. Systems - For the best results we recommend that the Solar 3C Cylinder be connected to a “S” plan type system. Solar 3C Cylinder can be used on “S” plan or “Y” plan systems only.
  • Page 9 ROOM STAT. NOTE: ORANGE AND GREY WIRES NOT REQUIRED ELECTRICALLY ISOLATE Pump overrun LINK 8 TO 10 ST9400A/C BOILER PUMP PUMP BOILER Solar 3C Jig Space Solar 3C Heating Cylinder Cylinder Boiler Stat. Radiators 2 Port Zone Valve 3 Port Mid-Postion Valve For illustration purposes only.
  • Page 10 ROOM STAT. NOTE: ORANGE AND GREY WIRES NOT REQUIRED ELECTRICALLY ISOLATE Pump overrun LINK 8 TO 10 ST9400A/C BOILER PUMP PUMP BOILER Solar 3C Jig Space Solar 3C Heating Cylinder Cylinder Stat. Boiler 2 Port Zone Valve Radiators 2 Port Zone Valve For illustration purposes only.
  • Page 11 Fig. 4a. “S” Plan wiring layout and system schematic for Solar 3C Heating System NOTE: 2 PORT V4043H ZONE VALVE ZONE VALVE 1. We recommend a 10 way junction box or Sundial Wiring Centre is used. CYLINDER MOTOR MOTOR STAT.
  • Page 12 BROWN MOTOR HWHTG HWHTG PUMP 3 PORT PUMP DIVERTER VALVE BOILER BOILER See Section B for full wiring instructions for the Solar 3C Control Panel Towel Rail Solar 3C Jig Space Solar 3C Heating Cylinder Boiler Diverter Check valve valve Radiators For illustration purposes only.
  • Page 13 Fig. 5. Wiring layout and system schematic for solar collectors using the high temp zone valve 2 PORT 230V HI-TEMP 50Hz VALVE 3A RATED BLUE SOLAR G/YELLOW CYLINDER MOTOR STAT. SOLAR SOLAR PUMP STATION CONTROLLER For illustration purposes only.

  • Page 14: Secondary Circuit Installation

    Expansion vessel – A suitable expansion vessel with a pre-charge pressure of 3 bar is supplied for fitting to all cylinders. All Solar 3C Cylinders must be fitted with a potable water expansion vessel (supplied) and the expansion vessel MUST be connected into the cold water supply after the pressure reducing valve.

  • Page 15: Discharge Arrangement

    7. Discharge Arrangement The user must install a Tundish in a position so that it is clearly visible and positioned away from electrical devices. In addition, the discharge pipe from the Tundish should terminate in a safe place where there is no risk to persons in the vicinity of the discharge, be of metal and: (a) Must be at least one pipe size larger than the normal outlet size of the safety device unless its total equipment hydraulic resistance exceeds that of a straight pipe 9m long, i.e.
  • Page 16 Worked example The example below is for a ½”diameter temperature relief valve with a discharge pipe (D2) having 4 No elbows and a length of 7m from the tundish to the point of discharge. Maximum resistance allowed for a straight length of Ø22mm copper discharge pipe (D2) from a ½” diameter temperature relief valve is - 9.0 m.

  • Page 17: Electrical Installation

    3Amp supply and a double pole switch with a minimum 3mm gap. From an economic and convenience point of view, it is intended that these controls operate in conjunction with other control packages for example: Solar 3C Solar Heating System or “S” and “Y” plan systems which incorporate a programmable time clock etc.

  • Page 18: Filling And Commissioning

    Fig 8. Immersion Heater Wiring WARNING: THIS APPLIANCE MUST BE EARTHED 9. Filling and commissioning 9.1. Check that the expansion vessel charge pressure is 3 bar. 9.2. Check that all connections are made tight including the immersion heater. 9.3. Open the main stopcock and fill the secondary system first. Open successive taps (hot and cold) starting with the tap furthest from the cylinder.

  • Page 19: Servicing And Maintenance

    WARNING: BOTH THE PRIMARY AND SECONDARY SYSTEMS WILL CONTAIN VERY HOT WATER THAT WILL SCALD, THEREFORE CARE SHOULD BE TAKEN WHEN OPENING ANY JOINTS, SEALS OR VALVES. 10.3. Only use spare parts authorised by Solar 3C. The use of unscheduled spare parts will invalidate the warranty. 10.4.

  • Page 20: Spare Parts List

    Spare Parts List 80 Litre Expansion vessel ZI-11A0008000 35 Litre Expansion vessel ZI-11A0003500 3/4” T & P relief valve 309570 1 3/4” Immersion Heater CESTC 340 Dual thermostat TLSC/542794 10BAR Pressure Gauge WI-557410 2 Port Direct Valve HQ-272848 Tundish AP-400010 Pressure relief valve 536060 311560...

  • Page 21: Fault Finding

    12. Fault Finding Notice: Disconnect electrical supply before removing any electrical equipment cover. Fault Possible cause Remedy No hot water 1. Mains supply off 1. Open stockcock 2. Strainer blocked 2. Turn water supply off, remove strainer and clean. (see 10.6) 3.
  • Page 22 Users Instructions. 13.1 Your Solar 3C Cylinder unvented hot water cylinder has been deigned to give many years of trouble free service and is made from hygienic high grade stainless steel. It includes 2 x 3 kW electric immersion heaters as standard for back-up purposes.

  • Page 23: Installer Details

    15. Installation, commissioning and service record Customer Details Name Address Tel No: Installer Details Company Name Date: Address Tel No: Installer Name Registration No: Commisioning Engineer (if different) Company Name Date: Address Tel No: Installer Name Registration No: Service Record Details Before completing the appropriate Service Interval Record below, please ensure you have carried out the service as described in the manufacturer’s instructions and in compliance with all relevant codes of prac- tice.
  • Page 24 Notes...
  • Page 25 Version 6.1 14/07/2014 Installations, User and Service Manual Section B Solar 3C 3C Jig | 3C Control Panel Important -This manual should be left with the system after installation...
  • Page 26 Solar 3C Installation, User and Service Manual Index Section Page Introduction System Operation Overview System Components Solar 3C Control Panel Heating Commissioning Hot Water Commissioning Fault Finding User Instructions Warranty...

  • Page 27: Introduction

    1. Introduction Solar 3C is a unique heating system that provides mains pressure hot water and space heating from a solar source. Water is heated in a triple coiled water heater by solar collectors. Heat is supplemented where necessary by a conventional boiler. The upper coil supplies heat from the cylinder to the heating system.

  • Page 28: System Operation Overview

    Solar 3C Cylinder, the back-up boiler/heat pump will automatically be switched off. The zone valve on the Solar 3C Jig will open, allowing the top/output coil of the Solar 3C Cylinder to provide the necessary temperature/energy to the heating circuit. This will cool the Solar 3C Cylinder promoting greater yield input from the solar collectors.
  • Page 29 The DHW zone value will open allowing water to flow through the cylinder heating the water. In addition, the Solar 3C mixing valve is switched to allow water through into the domestic hot water heating system. When the cylinder water has reached the correct temperature, the DHW zone valve is switched off so that only the heating circuit is supplied (as described in “Heating the dwelling”).

  • Page 30: System Components

    Note that the flow and return are connected to the Solar 3C Cylinder top coil in the reverse to that which may be expected because it concentrates the heat lower down and encourages a more even distribution of heat in the cylinder.
  • Page 31 3.2. Components provided on the Solar 3C Jig For illustration purposes only. 3.3. Spare parts list The following specialised components make up the Solar 3C Jig. Additional parts are available from Solar 3C. 22mm single check valve 1 off Grundfos pump UPS15-50 5mtr head...

  • Page 32: Solar 3C Control Panel

    4.1. Installing the Solar 3C Control Panel The Solar 3C Control Panel is designed to be fixed to the wall with four screws through the back plate. Once fixed, the front hinges downwards allowing easy access to the connection block at the top of the unit.
  • Page 33 4.3. Component location Fig.6 Solar 3C zone valve Solar 3C pump Solar 3C mixing valve 071e sensor 422 sensor For illustration purposes only. 522 sensor 070e sensor...
  • Page 34 (on 3C JIG) Cylinder Thermostat Control Fig 8. Control Panel Wiring For illustration purposes only. Solar3C Pump The Solar 3C Control Panel wiring is extremely simple • L, N, E to the panel as shown • Connect sensors (see section 4.2) •...

  • Page 35: Heating Commissioning

    Ensure all pipe work to the Solar 3C Jig are configured correctly (section 3). 5.3. Ensure the Solar 3C mixing valve is in the factory position by lining up the white collar with the white dot on the valve flange.

  • Page 36: Hot Water Commissioning

    6. Hot Water Commissioning 6.1. Check correct operation of the HW clock on Solar 3C Control Panel and the Cylinder stat. When the clock is on and the cylinder stat is “calling” the DHW zone valve should be energised. This is consistent with standard “S-Plan”...

  • Page 37: User Instructions

    Solar 3C guarantees all electrical and mechanical controls supplied with the Solar 3C Control Panel and Solar 3C Jig for a period of 1 year from the date of purchase provided that they have been installed for their intended use by a qualified person and have not been modified in any way.
  • Page 38 Notes...
