Summary of Contents for AD-net Technology AN-FE1-ETH
- Page 1 AN-FE1-ETH Interface Converter User Manual AD-NET TECHNOLOGY CO., LTD...
-
Page 2: Table Of Contents
2. Main features ................2 3. Technical specifications ............. 3 4. Installation and panel description ..........4 4.1 Unpacking (stand alone AN-FE1-ETH Bridge) ....... 4 4.2 Front and rear panel of the stand alone device ...... 4 4.2.1 System test and configuration......... 6 4.3 Front and rear panel of the rack mount........ -
Page 3: Product Description
AN-FE1-ETH Interface Converter (also AN-FE1-ETH Ethernet Bridge) is an Ethernet bridge of high performance, which accomplishes the converting between the 100M Ethernet port and the E1 port. As an extended device of the Ethernet, the AN-FE1-ETH Bridge realizes interconnection of two Ethernet by using the E1 channel provided by existing networks with low cost. -
Page 4: Main Features
AN-FE1-ETH Interface Converter User Manual If the AN-FE1-ETH Bridge is used in the framing mode, the transmission clock can be either provided internally, i.e. using the main clocking timing mode (INT), or extracted from the E1 channel, i.e. using slave clock timing mode. - Page 5 AN-FE1-ETH Interface Converter User Manual In the E1 framing mode, the number of time slots is optional from 1 to 31. Supporting 2.048Mbps transparent transmission in the E1 un-framing mode. The 100BASE-TX Ethernet interface supports 100M half/ full duplex modes.
-
Page 6: Technical Specifications
AN-FE1-ETH Interface Converter User Manual the Bridge of rack mount architecture, assuring high reliability. Support local Hypber Terminal management via RS232 serial port and remoter management by Telnet、 Web、SNMP and CGI management software. Can be communicated with the bridge of other company. - Page 7 AN-FE1-ETH Interface Converter User Manual Cable: 75ohm coaxial-cable, UTP5 twisted pair。 Transmission range: Circuit interface: BNC: 600m; RJ45: 300m; Data interface: 100m Indicator: indicating power, connection states of data and circuit interfaces, operation state, test state and trouble alarm. Dimensions:...
-
Page 8: Installation And Panel Description
■ Box up list In case of any damage in transportation, contact our offices or agencies. 4.2 Front and rear panel of the stand alone device The front panel of the AN-FE1-ETH Bridge is shown in figure 2. Page 7 of 22... - Page 9 AN-FE1-ETH Interface Converter User Manual Figure 2 front panel of AN-FE1-ETH Bridge Explanations for the two rows of indicators at the left are as follows: POWER: Power. Always lights after starting up. LINK: Link. Always lights if the data link is complete.
- Page 10 E1 circuit. Note: Circuit pseudo-random sequence test is valid only when the local equipment is in the framing mode and main clock is configured. The AC input rear panel of AN-FE1-ETH Bridge is shown in figure 3. 220V 220V...
- Page 11 75ohm impedance E1 interface E1-120 : RJ45 socket for 120ohm impedance E1 interface ETH: RJ45 socket for 100Mbps Ethernet interface The DC input rear panel of AN-FE1-ETH Bridge is shown in figure 4. 48V DC E1-75 ? ? ? ?
-
Page 12: System Test And Configuration
AN-FE1-ETH Interface Converter User Manual match impedance of the E1 interface is 120ohm balanced twisted-pair. (The E1 circuit uses RJ45 sockets.) Note: the default factory setting is (1). 4.3 System test and configuration S5.1: main/slave clock setting. ON for main clock (INT-CLK) and OFF for slave clock (LINE-CLK). -
Page 13: Front And Rear Panel Of The Rack Mount
Underneath the panel there is an indicator matrix. See figure 2 about the description of the front panel of AN-FE1-ETH Bridge for its functionality. The rear panel of RACK is shown in figure 6. Figure 6 Rear panel of rack... - Page 14 AN-FE1-ETH Interface Converter User Manual The small panel of AN-FE1-ETH bridge module, as shown in figure 7. Figure 7 Panel of AN-FE1-ETH Bridge module See figure 3 about the description of AC input rear panel of AN-FE1-ETH bridge for the functions of every component of the small panel.
-
Page 15: Applications Of An-Fe1-Eth Bridge
+” is the polarity of the –48V DC input) ON OFF: Power converter +5V: 5V main power indicator +12V: 12V fan power indicator 5. Applications of AN-FE1-ETH Bridge 5.1 Definition of balanced twisted-pair wire sequence for RJ45 interface 5.1.1 100BASE-TX interface wire sequence... -
Page 16: Setting Of Dip Switch And Jumper
AN-FE1-ETH Interface Converter User Manual 1 and 2 are transmitting lines, 4 and 5 are receiving lines, as shown in figure 10. Figure 10 RJ45 balanced twisted-pair wire sequence for E1 interface 5.2 Setting of DIP switch and jumper For a rack mount unit, the module can be easily drawn out from the guide channel just by unscrewing the screws on the module panel. - Page 17 AN-FE1-ETH Interface Converter User Manual plate-clip time slot correspond to S1, S2, S3 and S4. Status Function Status Function Default Unframed 2048KBps CCS (PCM31) (PCM30) switch (S1.1) used controlling ●1st framing/un-framing. “ON” refers to un-framing mode (2.048Mbps). ●31 switches, from 2nd—32nd (S1.2~S1.8, S2, S3, S4), are respectively used for controlling the selection of 1st –31st time slots.
-
Page 18: Configuration Of Ethernet Connecting Devices
100M half/full duplex and adaptive 10/100M. 5.4 Simple self-test methods for devices & E1 circuits Test 1: test of back-to-back connection Connect two AN-FE1-ETH bridge devices back to back, ping the other’s IP address on the two computers to test the FE1/ ETH... -
Page 19: Typical Applications
If the exchange end and the user end is very far away, the E1 circuits of the two AN-FE1-ETH bridge must be correctly connected first. Otherwise, indicator LOS will always light. Set the device at the exchange end to framing and main clock mode, set S5.5 (RLOOP) to ON, pseudo... -
Page 20: Common Questions And Their Maintenance
Connected with twisted pair or 75ohm coaxial cable, the E1 ports of AN-FE1-ETH Bridge support a transmission range of 300m or 600m. Two Ethernet networks at different locations can be bridged by two AN-FE1-ETH Bridge with existing twisted pair or coaxial cable. - Page 21 AN-FE1-ETH Interface Converter User Manual has a failure. Send it rear to factory for repair. 1. The type of the cable does Indicator LINK Integrity meet DTE/DCE does not light test of link modes of the Ethernet ports of when the equipment.
- Page 22 AN-FE1-ETH Interface Converter User Manual 120ohmRJ45 interface used. See 5.2.1 for reference. 3. The internal circuit of the equipment is damaged. Send it to factory for repair. The setting of framing or Indicators are Make un-framing selected normal, different different.
