Page 1 ADVANCED MANUAL TH SPEAKERS Rev. b www.audison.eu www.audison.eu...
Page 2: Table Of Contents
ADVANCED MANUAL / TH Speakers Index THESIS – The project TH 1.5 violino Flush mounting without trim ring Flush mounting with trim ring Surface mounting without trim ring Surface mounting without trim ring, with rear bracket Connecting, filtering, suggested positioning/angle TH 3.0 voce Sizing template Flush mounting...
Page 3 With the Thesis speakers, the Audison R&D team have reached a signi cant evolution; producing a speaker system that can match and complement the Audison ampli ers sound, worthy of the Thesis nomenclature.
Page 4: Flush Mounting Without Trim Ring
ADVANCED MANUAL / TH Speakers Flush mounting without trim ring Do not remove these screws 66 mm / 2” 23 mm / 15/16” 66 mm / 2”...
Page 5: Flush Mounting With Trim Ring
ADVANCED MANUAL / TH Speakers Flush mounting with trim ring 7/16 87,3 mm / 3” 66 mm / 2”...
Page 6: Surface Mounting Without Trim Ring
ADVANCED MANUAL / TH Speakers Surface mounting without trim ring 66 mm / 2” 17 mm / 11/16” 60 mm / 2”...
Page 7 ADVANCED MANUAL / TH Speakers Surface mounting without trim ring, with rear bracket 66 mm / 2” 10 mm / 7/16” 60 mm / 2”...
Page 8 ADVANCED MANUAL / TH Speakers Connecting Filtering, suggested positioning/angle MINIMUM FILTERING Hi-pass 1.8 kHz @ 12 dB Oct.
Page 9 ADVANCED MANUAL / TH Speakers Sizing template 5/16 84 mm / 3” 73 mm / 2”...
Page 10 ADVANCED MANUAL / TH Speakers Factory cut-out and flush mounting Gasket...
Page 11 ADVANCED MANUAL / TH Speakers Connecting Filtering MINIMUM FILTERING Hi-pass 250 Hz @ 12 dB Oct.
Page 12 ADVANCED MANUAL / TH Speakers Suggested positioning/angle and Thesis grille mounting 2.5 mm 2.9 x 13 mm...
Page 13 ADVANCED MANUAL / TH Speakers Sizing template 4 mm / 3/16” 145,5 mm / 5” 163 mm / 6” 7/16 155 mm / 6”...
Page 14 ADVANCED MANUAL / TH Speakers Factory cut-out and flush mounting 3.9 x 22 mm 3 mm Gasket...
Page 15 ADVANCED MANUAL / TH Speakers Connecting Do not remove these screws...
Page 16 ADVANCED MANUAL / TH Speakers Suggested positioning/angle and Thesis grille mounting 3 mm 3.9 x 22 mm...
Page 17 ADVANCED MANUAL / TH Speakers Sizing template 235 mm / 9” 5/16 261 mm / 10” Template ratio 1:2...
Page 18: Flush Mounting
ADVANCED MANUAL / TH Speakers Flush mounting Gasket...
Page 19 ADVANCED MANUAL / TH Speakers Connecting Do not remove these screws...
Page 20: Thesis Grille Mounting
ADVANCED MANUAL / TH Speakers Thesis grille mounting 4 mm 4,8 x 25 mm 4 mm 4,8 x 25 mm...
Page 21 ADVANCED MANUAL / TH Speakers Recommended enclosure speciﬁcations Sealed Box Dimension Net Int. Volume: 13,11 l 2 5 0 0.463 ft 2 1 0 Fc: 68 Hz Performance Net Int. Volume: 18,21 l 2 5 0 0.643 ft 2 7 0 Fc: 58 Hz Reﬂex Box Dimension...
Page 22: Wiring Configurations
ADVANCED MANUAL / TH Speakers Wiring configurations 1 Speaker Free Air DC Series TH 6.5 sax TH 10 basso Resistance Ω Ω 1 Speaker 4,50 3,50 Series 9,00 7,00 13,50 10,50 Parallel 2,25 1,75 1,50 1,17 4,50 3,50 Mixed 4,50 3,50 Parallel Mixed...
Page 23: Grille Cosmetic Options
ADVANCED MANUAL / TH Speakers Grille cosmetic options...
Page 24: Technical Specifications
ADVANCED MANUAL / TH Speakers Technical specifications TH 1.5 violino TH 3.0 voce TH 6.5 sax TH 10 basso Component Tweeter Cone Midrange Woofer Subwoofer 34 (1” 80 (3”) 165 (6” 250 (10”) Size Power Handling peak 180 W 100 W 300 W 1000 W 180W@1.8Hz-12dB Oct.
