A-DATA XPG 3.5" SSD Enclosure
2.5" To 3.5" Hard Drive Converter
Description:
This 3.5" enclosure is for the use of two 2.5" SATA SSD or hard disks
mounted on one mini 3.5" form factor drive cage.
Features:
SATA-I/II
* Interface:
* LED indication for Working and Failure.
* The dimensions match exactly as a standard 3.5" bay.
* Energy saving on using 2.5" SSD or HDD.
* For the use on desktop, server case, rack mount chassis that is
with 3.5" form factor space.
* Complies with SATA-I, SATA-II interface. Maximum transfer
rate up to 1.5Gbps for SATA-I and 3.0Gbps for SATA-II.
* SSD Auto Eject when you open the front cover.
* Aluminum material, best heat sink.
* Dimension: 148.2 x 101.7 x 25.8mm (L*W*H)
* Weight: 0.23 kg
V090420
User Manual
User Manual
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XPG 3.5” and is the answer not in the manual?

Questions and answers

Related Manuals for Adata XPG 3.5”

Summary of Contents for Adata XPG 3.5”

  • Page 1 User Manual User Manual A-DATA XPG 3.5” SSD Enclosure 2.5” To 3.5” Hard Drive Converter Description: This 3.5” enclosure is for the use of two 2.5" SATA SSD or hard disks mounted on one mini 3.5" form factor drive cage. Features: SATA-I/II * Interface:...

  • Page 2: Accessory List

    User Manual Accessory List: 3.5” Enclosure * 1 User Manual * 1 7 pin SATA Cable * 2 Screws Bag * 1 (With 4 screws) Front Panel: Picture A A1 : SSD/HDD 0 Access LED (Green: working) A2 : Power LED (Green: Power is on) A3: SSD/HDD 1 Access LED (Green: working) A4 : Upper cover &...

  • Page 3: Rear Panel

    User Manual A7 : Push the rise high position to open the upper & lower cover A8 : Lower SSD/HDD Safety Lock (Push rightward to open & push leftward to lock) Rear Panel: B1 : SATA 15pin power connector B2 : SATA 7pin data connector for SSD/HDD 0 B3 : SATA 7pin data connector for SSD/HDD 1 Safety Lock Upper SSD/HDD Safety Lock &...
  • Page 4 User Manual SSD/HDD Installing: Open the upper & lower cover and put the SSD/HDD into the cage. You can install one SSD/HDD or two SSDs/HDDs. Picture D - 4 - V090420...

  • Page 5: Hardware Installation Procedures

    User Manual Hardware Installation Procedures Please follow below procedures to complete the hardware installation: Open the package, take out the product, make sure the product is brand new and all the necessary parts are included (Please check with Accessory List). If damage or shortage occurred, please contact your distributor or where you bought.
  • Page 6 User Manual Picture E 6) There are 2 ways to mount the 3.5”enclosure on the device: -- Picture F-1) Mount it on the floppy drive bay -- Picture F-2) Mount it inside the case 7) Connect the 3.5” enclosure with PC via 15pin SATA power cable (from Power Supply) and 7pin SATA cable ( using included cables).(See Picture F-3) - 6 -...
  • Page 7 User Manual Picture F-1 Picture F-2 Picture F-3 - 7 - V090420...

  • Page 8: Troubleshooting

    User Manual Trouble Shooting A) Why can’t I open the panel cover? Please check the Safety Lock is at UNLOCK position. B) Can I install or uninstall the Hard Drive anytime? We suggest you to turn off PC before your installation. C) Why can’t I see the Hard Drive in “My Computer”...
  • Page 9 User Manual Notice: 1. Hot-plug function depends on your PC system. Generally, internal SATA device does not support hot-plug function. Some e-SATA devices support but also depend on the motherboard driver. If you are not clear that your PC system supports or not, please do not change your SSD or HDD as the PC is working.
