KYL GSM/GPRS/GPS Tracker User Manual

Hide thumbs Also See for GSM/GPRS/GPS Tracker:

Advertisement

Quick Links

Download this manual See also: User Manual
Shenzhen KYL Communication Equipment Co., Ltd
GSM/GPRS/GPS Tracker

User Manual

Preface
Thank you for purchasing this product. This manual shows how to operate the device smoothly and
correctly. Make sure to read this manual carefully before using this product. Please note that
specification and information are subject to change without prior notice in this manual. Any change
will be integrated in the latest release. The manufacturer assumes no responsibility for any errors or
omissions in this document.
www.rf-data.com
Fax: 86-755-83408785
sales02@rf-data.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the GSM/GPRS/GPS Tracker and is the answer not in the manual?

Questions and answers

Related Manuals for KYL GSM/GPRS/GPS Tracker

Summary of Contents for KYL GSM/GPRS/GPS Tracker

  • Page 1: User Manual

    Shenzhen KYL Communication Equipment Co., Ltd GSM/GPRS/GPS Tracker User Manual Preface Thank you for purchasing this product. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to change without prior notice in this manual.

  • Page 2: Table Of Contents

    Shenzhen KYL Communication Equipment Co., Ltd Content 1. Summary………………………………...……………………...…………………2 2. Application………………………………………………………...………………2 3. Hardware description………………………………………...………………..2 4. Specifications………………………………………………………………………4 5. How to use..…………………………………………………………...…………4 6. Cautions…………………………………………………………………………..13 7. Faults & Solutions……………………………………………………...………..14 1 Summary This device works based on existing GSM/GPRS network and GPS satellites. It can be used to locate and monitor any remote targets by SMS or internet.

  • Page 3: Hardware Description

    Shenzhen KYL Communication Equipment Co., Ltd 3 Hardware Descriptions Indicator for power Front face 3.2 Rear face Press this button and push the cover to the right side. Then you can open it. Indicator for signal 3.3 Side face Turn on/off button...

  • Page 4: Specifications

    Shenzhen KYL Communication Equipment Co., Ltd 4 Specifications Content Specifications. Dim. 78.4mm x 45.4 mm x 16.5mm Weight Network GSM/GPRS Band 900/1800/1900Mhz or 850/900/1800/1900Mhz GPS chip SiRF III chip GSM/GPRS SIMCOM 300 OR SIMCOM 340 module GPS sensitivity -159dBm GPS accuracy Reacquisition 0.1s...
  • Page 5 Shenzhen KYL Communication Equipment Co., Ltd 3 Insert SIM card into the holder, put down the foil right and fasten it. 5.2 Battery and Charger Please use the original battery and charger provided by the manufacturer. This device adopts built-in Li-ion battery, and full battery will support around 60 hours.
  • Page 6 Shenzhen KYL Communication Equipment Co., Ltd every two seconds, the GPS is standby. When the blue indicator is off, the tracker is working but doesn’t get position yet. If the tracker gets the position, the blue indicator will be on all the time.
  • Page 7 Shenzhen KYL Communication Equipment Co., Ltd off by itself and begin to search the position. One minute later, no matter whether it has fixed position, the device will send back a message. If the device hasn’t fixed position, it will keep searching for 4 minutes.
  • Page 8 Shenzhen KYL Communication Equipment Co., Ltd "Auto track set ok.” ‘AT30SUM0’ means device replies the location intervals every 30 seconds. (Please note, 0 means detail times) 5. 5. 3 Monitor the voice of the device. Send SMS: monitor123456 to the device No. The device reply ‘monitor ok’, then you can monitor the voice.
  • Page 9 Shenzhen KYL Communication Equipment Co., Ltd authorized number. If the setting is successfully, the device will reply “no administrator state” in SMS. example:’noadmin123456 13612345678’ d. If you are in a foreign country to set up your device, you should add the country code which your SIM card belongs to before the cell phone number.
  • Page 10 Shenzhen KYL Communication Equipment Co., Ltd Report a Geo-info at 30s (minute: m; hour: h) intervals to the authorized numbers for 5 times: a. Set up: Send SMS ‘at30sum15’ to the device, it will report the Geo-info at 30s intervals for 15 times. (s: second, m: minute, h: hour). The setting must be in...
  • Page 11 Shenzhen KYL Communication Equipment Co., Ltd a. Set up: When the device stays immobile in a place for 3-10 minutes, the user Send ‘stockade+password+space+latitude,longitude; latitude,longitude’ to the device to set the restricted district. In case of breach, it will send SMS “stockade!+geo-info” to the authorized numbers.
  • Page 12 Shenzhen KYL Communication Equipment Co., Ltd authorized numbers. It will alarm one time in each setting. b. Cancel: Send SMS ‘nospeed+password’ to deactivate the over-speed alert 5.15 IMEI checking: Send SMS imei+password to the device to check the IMEI number.
  • Page 13 Shenzhen KYL Communication Equipment Co., Ltd c. Send SMS noadminsms+password to cancel the SMS center. Response SMS format: authorized number+Geo-info 5.20 Set up GPRS The user needs to set IP address and Port by SMS to start the function of GPRS.

  • Page 14: Cautions

    Shenzhen KYL Communication Equipment Co., Ltd SMS. (The default is sending the GPS data to the telephone by SMS) 5.23 Set APN For sending GPS data to IP address, you should set up mobile network Access Point Name (APN).If you don’t know the APN, you can consult local network service supplier.

  • Page 15: Faults & Solutions

    Shenzhen KYL Communication Equipment Co., Ltd 7 Faults & The solutions Faults Solution Check the battery and see if it is fully charged or correctly Startup Fail installed. Hangup Fail In existence of an authorized number, an unauthorized Number dials up the device. Please initialize the device and re-set up the authorized numbers.
