Summary of Contents for Audio Resource Group TX72 Bodypack transmitter
- Page 2 ANUAL and UIDE ONGRATULATIONS! Your TALK AND LISTEN® System has been engineered and designed to provide you many years of reliable service. This manual contains vital information regarding system overview, safety information, use, operating tips and instructions, battery information, troubleshooting and warranty information. We recommend it be stored in the carry case or in another safe place for easy and frequent reference.
-
Page 3: Table Of Contents
ONTENTS SAFETY INFORMATION SYSTEM OVERVIEW BATTERY INFORMATION Battery installation Rechargeable & Non-Rechargeable Batteries OPERATING INSTRUCTIONS ARG-TX72BP Transmitter ARG-RX72BP Receiver Channel Selection and Settings LCD Display Hints for using the System IN CASE OF DIFFICULTY COMPLIANCE WARRANTY SYSTEM SPECIFICATIONS... -
Page 4: Safety Information
AFETY NFORMATION EARING AFETY CAUTION! This product is designed to amplify sounds to a high volume level which could potentially cause hearing damage if used improperly. To protect your hearing and the hearing of others: 1. Set the volume level at the minimum setting before placing the listening accessory on your ears. -
Page 5: System Overview
YSTEM VERVIEW Your Talk and Listen® System is a portable, high-performance communication system designed to be transmitter, microphone, receiver, listening device and batteries. The transmitter broadcasts a high-quality one-way audio signal to an unlimited number of receivers providing crystal clear FM quality audio to each listener. Much like a miniature radio station, the speaker uses a transmitter to broadcast an FM radio signal and the listeners use a receiver to hear the FM radio signal. -
Page 6: Battery Information
ATTERY NFORMATION ECYCLING NSTRUCTIONS Please help ARG, Inc. protect the environment by taking time to dispose of your used equipment properly. Do product to local recycling collection centers OR, return the products to the factory for proper recycling. ON-RECHARGEABLE ATTERIES In normal use, two AA 1.5V alkaline batteries will last about 30-40 hours in the ARG-TX72BP transmitter and approximately 40-50 hours in the ARG-RX72BP receiver. -
Page 7: Operating Instructions
PERATING NSTRUCTIONS ARG-TX72BP T SING THE RANSMITTER Before installing batteries, determine if they are carbon zinc, heavy duty, alkaline or rechargeable. Open the battery compartment door and locate the “ALK/NiMH” switch. If using carbon zinc, heavy duty or alkaline batteries slide the switch to the “ALK”... - Page 8 TRANSMITTER PRODUCT FEATURES 3.5mm Audio Input Jack Power ON/OFF Switch ON/Low/Charging Indicator LED Liquid Crystal Display (LCD) Channel/Volume/Squelch Button Set Button Battery Compartment ALK/NiMH Selector Switch Lock/Unlock Button USB Power/Charging Port Belt Clip Battery Door Latch Mute Button...
- Page 9 ARG-RX72BP R SING THE ECEIVER Before installing batteries, determine if they are carbon zinc, heavy duty, alkaline or rechargeable. Open the battery compartment door and locate the “ALK/NiMH” switch, if using carbon zinc, heavy duty or alkaline batteries slide the switch to the “ALK”...
- Page 10 RECEIVER PRODUCT FEATURES 3.5mm Audio Output Jack Power ON/OFF Switch ON/Low/Charging Indicator LED Liquid Crystal Display (LCD) Channel/Volume/Squelch Button Set Button Battery Compartment ALK/NiMH Selector Switch Lock/Unlock Button USB Power/Charging Port Belt Clip Battery Door Latch...
- Page 11 LCD D RANSMITTER/ ECEIVER ISPLAY Figure 5: LCD Display Lock/Unlock Signal Strength Memory Battery Level Group Volume Channel Squelch Frequency Strong Signal Weak Signal Channel lock Battery full Battery low...
- Page 12 TALK AND LISTEN INTS TO SING YOUR ® IRELESS YSTEM Maximum operating distance between the transmitter and receiver is 100m (LOS). The operating range will tion may restore the signal. Getting transmitters too close to one another may cause signal interference, even when they are each on a three feet of separation between them to avoid this.
-
Page 13: In Case Of Difficulty
ASE OF IFFICULTY If your Talk and Listen® System is not working, check the following: Read through the manual and user guide carefully to verify proper setup and installation of your system. Make sure the batteries are fresh or completely charged and that the “plus” and “minus” terminals are installed correctly. -
Page 14: Compliance
OMPLIANCE This transmitter (ARG-TX72BP) is authorized by rule under the Low Power Radio Service (47 C.F.R. part 95) and must not cause harmful interference to TV reception or United States Navy SPASUR installations. You do not need an FCC license to operate this transmitter. This transmitter may only be used to provide: auditory assis- tance to persons with disabilities, persons who require language translation, or persons in educational settings;... -
Page 15: Warranty
Toll-Free for Customer Assistance: 1-888-468-4552 If it is necessary to return your system for service, please contact your Customer Service Representative for a Return Authorization Number prior to shipping. Mail: Audio Resource Group, Inc. ATTN: Repair Dept. 440 Ramsland Ave Hannaford, ND 58448...
