Fxunits RAC12 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RAC12
owner's manual
revision 1.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAC12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fxunits RAC12

  • Page 1 RAC12 owner’s manual revision 1.1.1...

  • Page 2: Important Safety Instructions

    Trademarks are the property of Fractal Audio Systems which is in no way associated or affiliated with Fxunits.com. The use of these products, trademarks, images or names does not imply any cooperation or endorsement.
  • Page 3 Certificate of Conformity Cedia Industrie, France, hereby declares on its own responsibility that the following product: RAC12 covered by this certificate and marked with CE label, conforms to following standards: EN60065 Safety requirement for mains operated electronic and related apparatus for household and (IEC 60065) similar use.

  • Page 4: Table Of Contents

    8.2 Connecting another foot-controller or other MIDI equipment ....17 8.3 If phantom power is needed ..............18 8.4 Connecting two RAC12’s ............... 19 8.5 Connecting three (or more) RAC12’s ............. 19 9 Specifications ................20 MIDI Implementation Chart ................20 Warranty ...................

  • Page 5: Introduction

    Now you must be thinking 12 knobs and 12 switches make only a total of 24 possible controllable parameters. But the RAC12 is a lot more powerful than that : It allows you to control up to 384 Axe-Fx parameters. How ? Let’s now talk about the RAC12 Pages concept.

  • Page 6: Pages

    AMP block parameters. Here is the RAC12 screen when on this page: A Page is a RAC12 concept describing a set of 12 knobs and 12 switches functionalities. What does that mean ? Let’s see what the default configuration of page 2 looks like : The 12 knobs now control different Axe-Fx parameters : The first knob (labeled DRIVE on the front panel) now controls the Preamp Bias parameter, the knob labeled BASS now controls the Low Resonance parameter…etc.

  • Page 7: Rac12 Screen Layout

    3 RAC12 screen layout This is the first screen you will see when your RAC12 is connected to your Axe-Fx*. This screen displays the current preset’s name (in green), the current scene (S1 in this example), the 12 parameters assigned to each knob, the current page number (01 here) and the current page’s name (“AMP”).

  • Page 8: Switches

    MIDI activity LEDS Merge, In and Values modified from the RAC12 or from the Axe-Fx’s front-panel are displayed in red, until the preset is saved or reverted (see the advanced functionalities chapter) or the current page is changed. 4 Switches The RAC12 allows you to choose from a large number of functions for every switch.

  • Page 9: Rac12Edit

    You will typically get this screen : Here you can see some RAC12 functions assigned to the 5 last knobs, see advanced functions chapter for more details. 5 RAC12Edit RAC12Edit is free software you will need to configure your RAC12 if the default configuration does not suit you.

  • Page 10: Installing Driver (Windows Only)

    Firmware update Every RAC12Edit version will have the latest RAC12 firmware embedded. It means you don’t have to download a firmware file, just get the latest RAC12Edit software from our website, and then click on You can see the latest additions/improvements in the main RAC12Edit menu, under “Release Notes”.

  • Page 11: Configuration

    Configuration For each knob, select the Axe-Fx block it will control. Then the block’s parameter you want it to control : revision 1.1.1...

  • Page 12: Global Knobs And Global Switches

    5.4 Global knobs and global switches This is a very important concept in the RAC12. Just see it as a way to have identical knob/switch functions on every page, without having to configure each page. This can be very convenient by example for your main level knob.

  • Page 13: Rac12 Advanced Functions

    So in the default RAC12 config, the Level/1/2/3 and 4 switches will have the same functions across the pages. 6 RAC12 advanced functions Here is a list of all the RAC12 functions you can assign to switch actions “click”, “double-click” or “long press”: Page Navig : When engaged, turn the same knob you’ve just activated to select the page to display, then...
  • Page 14 The Compare function will save the full preset data into the RAC12, thus the operation may take up to 9 seconds on the Axe-Fx XL and about 5 seconds on the Axe-Fx II, due to the slow speed of MIDI transfers.

  • Page 15: Page Mapping

    We strongly recommend using a good 5 pin DIN (DIN-5) MIDI cable, which has the 5 pins wired. With such cable, only one cable is needed to connect the RAC12 to your Axe-Fx : Just connect the Axe-Fx’s MIDI IN to the RAC12’s MIDI OUT.

  • Page 16: Connecting A Single Rac12

    Connecting a single RAC12 (Axe-Fx) Use a single DIN-5 MIDI cable with 5 pins wired (RAC12) (Axe-Fx) Use a 2 DIN-5 MIDI cables with 3 pins wired (RA12) revision 1.1.1...

  • Page 17: Connecting Another Foot-Controller Or Other Midi Equipment

    You must use the MERGE connector of the RAC12. This connector is not bidirectional, meaning only MIDI traffic incoming to the RAC12 will be transferred to the Axe-Fx, but MIDI communications from the Axe-Fx will not be routed back to the MERGE connector.

  • Page 18: If Phantom Power Is Needed

    If your foot-controller only has one midi in/out, you should buy/make a MIDI Y-cable like this one : If phantom power is needed (courtesy of forum member npx) revision 1.1.1...

  • Page 19: Connecting Two Rac12'S

    Connecting two RAC12’s (Axe-Fx) Use a single DIN-5 MIDI cable with 5 pins wired (Foot controller, if needed) Connecting three (or more) RAC12’s For those wanting to use more than two RAC12 with their Axe-Fx, just contact us at support@fxunits.com revision 1.1.1...

  • Page 20: Specifications

    9 Specifications The RAC12 supports Fractal Audio Systems Axe-Fx II or XL with firmware>13.07. However, for higher parameter accuracy, the latest Axe-Fx firmware is preferred. MIDI INTERFACE IN Connector: 5-pin DIN OUT Connector: 5-pin DIN, bidirectional MERGE Connector: 5-pin DIN...

  • Page 21: Warranty

    Warranty Cedia industrie warrants that your new RAC12 product shall be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. During the warranty period, Cedia industrie shall, at its sole option, either repair or replace any product that proves to be defective upon inspection by Cedia industrie.
