DP4 4 CHANNEL DMX DIMMER PACK
USER MANUAL
154.110UK Version 1.0
INTRODUCTION
The DP4 4 channel DMX dimmer pack has 4 channels each with 2 IEC power outputs per channel.
It has 16 built-in chase programs or can be controlled by 4 channels DMX.
LED readout display
•
16 built in chase programs
•
4 Channel output
•
Pulse feature to keep lamp filaments warm for instant on/off effect
•
Not suitable for LED products (recommend 154.111UK)
•
Master / slave
•
IN THE BOX
1 x DP4
1 x IEC POWER LEAD
1 x MANUAL
WARNING BEFORE USE
This item is for professional use only. Please take note of the following instructions before using
this device.
This product is not suitable for low power LED products
•
This unit must be earthed.
•
Do not turn on the power until all connections are securely made.
•
Always disconnect from the mains before replacing any fuse
•
There are no user serviceable parts inside
•
FUSES
The Pack can carry maximum overall load of 10 amps. Each channel can also carry a maximum
overall load of 10 amps but the unit is factory fitted with 2.5amps. These can be changed but the
maximum overall load for each channel should not exceed 10 amps and you must be
professionally qualified in order to change the fuses to suit.
Page 1
Advertisement
Table of Contents
Summary of Contents for QTX Light DP4
- Page 1 USER MANUAL 154.110UK Version 1.0 INTRODUCTION The DP4 4 channel DMX dimmer pack has 4 channels each with 2 IEC power outputs per channel. It has 16 built-in chase programs or can be controlled by 4 channels DMX. LED readout display •...
- Page 2 PRODUCT LAYOUT 1) IEC Power outputs: 2 x IEC power outputs per channel, 8 sockets in total 2) FUSES per channel 3) Power ON/OFF – Use to turn the mains power ON/OFF 4) Power inlet – The items is hard wired to the unit with a 13 amp maximum rating. 5) DMX IN –...
- Page 3 OPERATIONS GUIDE: The unit has two working modes. It can be used as a four-channel chaser or as a 1, 2, or 4 channel DMX dimmer pack. Please follow up the instructions below to operate the unit for your desired performance. CHASE MODE Choose this working mode only when you want the device to act as a 4-channel chaser.
- Page 4 DMX controller. 0 will give no output and 100 will give you full output. SPECIFICATION: Power supply: 230Vac, 50Hz DMX Inputs: Channel Outputs: Size: 193 x 72 x 260mm Weight: 2.5kg Please disposal of the unserviceable device according to the current statutory requirements. Copyright protected by QTX Light Manchester WWW.QTXLIGHT.COM Page 4...
