zonee
HFX
The HFX zonee is a universal UPNP based network player (client). It will be connected with USB DACs
and USB Amps and replaces Laptops and PCs. This way you have a small tiny powersaving player.
It has also analog mini jack output and S/PDIF output, which can be used. With HDMI you can also
monitor on your TV, what is actually playing in which zone.
You only need to connect the HFX zonee to your LAN network. With a webbrowser you can then give
each zone an individual name and you can also assign, which output (analog, S/PDIF, USB1-4) is used
for this zone. That's all! Once done, you can take any iPAD, Android Pad or Phone and start playing in
each zone, whatever you want.
What do you need for a UPNP system?
1. Network with Router, if you want to use internet radio, you also need internet access
2. UPNP-Server: with your music collection and internet radio like the RipNAS
3. UPNP-Clients: like the HFX zonee. You can have a zonee in each room or use only one
zonee and connect all rooms with USB Air DACs to 1 zonee centrally.
4. ControlPoint: use any Android or Apple device as a remote control, there are many
free UPNP apps in the market
this picture shows how to connect all components in a UPNP system in 1-room
Manual V1.0
© by HFX Austria
1/8
Advertisement
Summary of Contents for HFX Zonee
- Page 1 TV, what is actually playing in which zone. You only need to connect the HFX zonee to your LAN network. With a webbrowser you can then give each zone an individual name and you can also assign, which output (analog, S/PDIF, USB1-4) is used for this zone.
- Page 2 How to setup multiple zones? The HFX Zonee can handle more than one zone. Second zone could be another pair of speakers or just the headphones. But other zones can also be other rooms, if you are using USB Air DACs, which can transmit digital sound wireless.
- Page 3 Configuration If the Zonee is finished with Starting (about 40 seconds), then you can see all active zones in the network. You can find it with Apple Finder or Microsoft Explorer. Only zones show up, where a usb device is connected. Double-click on one of them.
- Page 4 If you do that, then 2 outputs will deliver the same music (which is good for parallel headphone use or for party mode, where all audio outputs deliver the same music). Please do not forget to save your changes with „Configure“ button. Manual V1.0 © by HFX Austria...
- Page 5 Attention: if a zone has no audio output connect, then it will not show up in the network neighborhood. Using more than one HFX zonee in the home network If you are using more than one HFX zonee within one home network, just please change the UUID Prefix. Display Brightness If the display is too bright, you can change it here and make it a little bit darker.
- Page 6 Party Mode If you want to hear the same music with all connected audio devices, please do the following steps: 1. rename one zone in „Party“ 2. Assign all audio outputs to this zone Manual V1.0 © by HFX Austria...
- Page 7 In the network neighborhood you will see only the „Party“ zone then. Connecting your TV If you connect your TV with HDMI to the HFX zonee, than you can see, what is actually playing in which zone, and also with which quality.
- Page 8 With a UPNP ControlPoints you have to select first the source like the RipNAS or Cinema. RipNAS has also Internet Radio included. Then you need to select the audio device (that means your zone of the HFX zonee). Now you can move the music with a finger tip to your zone or also create playlists.
