Adjustment Of Top Burr; Customer Service Department - Graef CM 80-Serie Instruction Manual

EN
Remove the grind adjustment collar including the top burr.
•
Lift out the top burr from the grind adjustment collar and clean it using the burr cleaning brush.
•
Also clean the upper burr with the cleaning brush.
•
After cleaning return the grind adjustment collar to its position on the appliance.
•
The upper graphic arrow is aligned with the second graphic arrow (Align).
•
Replace the top burr back into position in the grind adjustment collar and turn clockwise to the desired
•
grind setting.
Notice: To check if the burr was inserted correctly, you can try to pull out the burr on the metal ring.
Now, the burr should not be removable.

Adjustment of top burr

By adjusting the burr you can adjust the grind setting coarser or finer.
Remove the top burr as described in "Cleaning the burrs".
•
Remove the two small screws with a screw driver.
•
Turn the burr one step to the left (coarser) or to the right (finer).
•
Turn back the screws.
•
Replace the burr.
•
Repeat the adjustment if it is not fine or coarse enough.
•

Customer service department

If your Graef appliance becomes damaged or you lose the instruction manual, please contact your deal-
er or the Graef customer service department.
9
