Summary of Contents for PROCEED CDD Compact Disc Drive

  • Page 1 CDD Compact Disc Drive...
  • Page 2 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.

  • Page 3: Important Safety Instructions

    Important Safety Instructions Please read all instructions and precautions carefully and completely before operating your Proceed compo- nent. 1. ALWAYS disconnect your entire system from the AC mains before connecting or disconnecting any cables, or when cleaning any component. 2. This product is equipped with a three-conductor AC mains power cord which includes an earth ground connection.

  • Page 4: Table Of Contents

    Table of Contents Unpacking and Placement ............... 6 Unpacking the CDD ..................6 Remove the Transport Screws ................6 Placement of the CDD ..................6 Operating Voltage & Frequency ....................7 Voltage label ....................7 A Quick Start… .................... 8 Warm up/break-in period .................
  • Page 5 Programming the CDD ................29 Introduction to Playlists ..................29 Assembling a Playlist ..................29 Programming by Omission ................29 Reviewing a Playlist ..................30 Adding a Track to a Playlist ......................30 Deleting a Track from a Playlist ....................30 Deleting an Entire Playlist ................

  • Page 6: Unpacking And Placement

    Unpacking and Placement Unpacking the CDD Unpack your CDD Compact Disc Drive and remove all accessories from the car- ton. Important! Keep all packing materials for future transport of your CDD. Shipping your new component in anything other than its purpose-designed packing material may result in damage that is not covered by the warranty.

  • Page 7: Operating Voltage & Frequency

    Attempting to operate the CDD at an incorrect voltage can damage the unit. The CDD Compact Disc Drive is also set at the factory for operation on either 50 or 60 Hz AC line frequencies, as appropriate for the country in which it is to be sold.

  • Page 8: A Quick Start

    A Quick Start… We recognize that many people are understandably eager to begin listening to their new components, and that reading the manual is often done (if at all) at a later time—perhaps while listening to music with the new product itself. We strongly recommend that you read this manual thoroughly, as the CDD Compact Disc Drive incorporates many unusual features that enhance its operation.

  • Page 9: Warm Up/Break-In Period

    Congratulations! Y ou should now be able to enjoy your favorite music while reading the rest of this manual. (Please, do read the rest of this manual.) Although your Proceed CDD Compact Disc Drive delivers outstanding perfor- Warm up/break-in period...

  • Page 10: Special Design Features

    Special Design Features Congratulations on your purchase of the CDD Compact Disc Drive. The Madrigal design team is confident you will enjoy the outstanding performance of the CDD for many years. In case you are interested in technical details, what follows is a brief outline of some of the key technologies in your new transport.

  • Page 11: Industrial Design

    Proceed products. Industrial Design The CDD shares the handsome industrial design of other Proceed components such as the DAP digital audio processor. Dark buttons against a light face simplify the operation of the CDD, even in a dimly-lit room.

  • Page 12: Front Panel, Cdd

    c d d track/index display power program– program+ prev/rew play/pause next/f.fwd stop/drawer repeat time remaining on disc random program disc track PR O C E E D Front Panel, CDD POWER & POWER LED Assuming that the CDD’s power cord is connected to AC power, pressing this latching power button connects the CDD to the AC mains and turns on the unit.

  • Page 13: The Extended Pause Mode

    PREV/REW BUTTON Pressing this button momentarily will return you to the beginning of the current track. Pressing it repeatedly will move you backward through the available tracks, one at a time. Pressing and holding this button will instead perform a reduced-volume reverse scan of the music, reminiscent of the audible rewind function found on many cassette decks.

  • Page 14: Hidden" Front Panel Standby Button

    TIME INDICATOR The time section of the display can be set to display any of the following four indications of time in minutes and seconds: time elapsed in track time elapsed on disc time remaining on disc time remaining on track These four options are accessed by pressing the button to the right display...
  • Page 15 If the CDD senses an obstruction during opening of the drawer mecha- nism, it will attempt to re-close. If successful, it will read the disc’s table of contents and display the disc’s number of tracks and total time (followed by the playlist’s track and time information, if one exists).
  • Page 16 TIME ON DISC AND TIME REMAINING LED INDICATORS These LEDs are used to indicate which of the four available display modes the CDD is in. The four indications of time that can be displayed are: • (neither LED lit) time elapsed in track •...

  • Page 17: Rear Panel, Cdd

    It has been Madrigal’s experience that the AES/EBU interconnection stan- dard offers the best quality of all digital transmission interfaces when fully optimized, and we recommend its use wherever possible between Proceed components. However, optimizing any digital interface completely represents a significant engineering challenge.
  • Page 18 S/PDIF (BNC) ELECTRICAL DIGITAL OUTPUT This output provides the digital audio signal ) via cables equipped with BNC-type connectors to the digital processor. This output conforms to the Sony/Philips Digital Interface Standard (S/PDIF), which calls for a 75Ω transmission of the DAS. Use a digital inter- connecting cable specifically designed for the 75Ω...

  • Page 19: Ir Input Tip Polarity

    100 mA If you would like more information on the possibility of using an infrared repeater with your CDD, please contact your Proceed dealer. AC POWER INPUT This input accepts AC power from the AC mains (via the supplied AC cable).

  • Page 20: Remote Control, Cdd

    Remote Control, CDD IR TRANSMITTER WINDOW The CDD’s Remote Control sends infrared (IR) commands through its pro- jection lens, and the CDD receives IR commands through its Remote sensor window. (See “Front Panel, CDD”). If either of these lenses is obstructed, /dwr no IR commands can be received by the CDD.
  • Page 21 NUMERIC KEYPAD The numbers 0, 1, 2, 3, 4, 5, 6, 7, 8, and 9 may be used to directly access in- dividual track numbers of discs played by the CDD. For example, to go di- rectly to track 13, press followed by , and then press .
  • Page 22 PROCEED DAP CONTROLS These four buttons control the key functions of the Proceed DAP , should you choose to purchase this outstanding digital audio processor as a com- panion to your CDD.

  • Page 23: Conditions That Affect Ir Performance

    BATTERY COMPARTMENT The two AA batteries used by the Remote Control must be placed inside the compartment on the back of the remote’s housing (near the bottom). Carefully remove the battery compartment cover and insert the batteries, being careful to orient them as indicated inside the battery compartment. Then replace the cover, clicking it into place.
  • Page 24 If the requirements of your installation preclude a clean line of sight between the CDD and your listening position, you may want to consider using an infrared re- peater to route the remote control’s commands directly to the CDD, using the ex- ternal ir input on the rear panel.

  • Page 25: Setup And Installation

    75Ω S/PDIF interconnection (via either RCA or BNC connectors). Both cables are available in various lengths from your Proceed dealer. Using an appropriate cable, connect an output of your CDD to a suitable input of your digital processor.

  • Page 26: Basic Operation

    Basic Operation Before operating your CDD, take a minute to become familiar with its controls and their locations. (See “Front Panel” and “Remote Control.”) To load a CD: Loading a CD 1. Enable the CDD’s controls by pressing if in standby . standby 2.

  • Page 27: Direct Time Access

    As soon as you release the button, play resumes. If you search past the beginning or end of a track, the laser pickup will move on to the previous (or next) track. If you try to search forward past the end of a CD or program, the laser pickup will stop at the end of the last track.

  • Page 28: A-B Repeat

    Track repeat takes priority over other functions such as . To re- next previous turn to normal operation, press repeat again. To repeat (continuously) a specific phrase or passage on a CD (when learning A-B Repeat how to play a favorite solo, for example), press rpt a/b on the remote at the be- ginning of the passage you would like to repeat.

  • Page 29: Programming The Cdd

    Programming the CDD Introduction to Playlists Rather than playing an entire CD, you may choose to play only certain selections. To do this, you create a “playlist” for that particular CD. It may be used immedi- ately upon being created, and will remain in memory until replaced by a differ- ent playlist.

  • Page 30: Reviewing A Playlist

    remaining in the playlist. This next track will be shown with the green program LED lit to indicate that it is still in the playlist. 4. Using next previous , move to any other tracks you would pre- fer to skip, pressing to eliminate each track from the program –...

  • Page 31: Using Learning Remote Controls

    Using Learning Remote Controls The CDD includes both an infrared receiver and an infrared transmitter. With this capability, it can “teach” a learning remote control any commands that might be needed for remote operation. Specifically, the CDD can send all of the necessary IR commands from its display window, enabling you to teach a learning remote any or all of its pre-pro- grammed commands, as well as some optional special commands that are avail-...

  • Page 32: Teaching Other Cdd Commands

    REPEAT THE PROCESS OF “TEACHING” NEW COMMANDS TO THE VARIOUS BUTTONS ON YOUR REMOTE CONTROL UNTIL ALL APPROPRIATE OR DESIRED FRONT PANEL COMMANDS HAVE BEEN LEARNED BY YOUR REMOTE WHEN FINISHED, EXIT THE TEACH IR MODE BY ALLOWING THE CDD TO “TIMEOUT”...

  • Page 33: Special Commands Table

    no button is pushed for more than ten seconds, the CDD will “time out” and return to normal operation. special commands table Command Display positive control for operate positive control for standby display on display off A–B repeat Numeric Keypad: 1 Numeric Keypad: 2 Numeric Keypad: 3 Numeric Keypad: 4...

  • Page 34: Troubleshooting

    Troubleshooting In general, refer any service problems to your Proceed dealer. Before contacting your dealer, however, check to see if the problem is listed here. If it is, try the suggested solutions. If none of these solves the problem, contact your Proceed dealer.

  • Page 35: Care And Maintenance

    Care and Maintenance To remove dust from the cabinet of the CDD, use a feather duster. To remove dirt and fingerprints, we recommend isopropyl alcohol and a soft cloth. Caution! Always apply the isopropyl alcohol to the soft cloth and then wipe the CDD with the dampened cloth.

  • Page 36: U.s. And Canadian Warranty

    Madrigal Audio Laboratories, Inc., P . O. Box 781, Middletown, CT 06457. The extended warranty for this Proceed product is five (5) years from the date of Five Year Extended Warranty purchase.

  • Page 37: Obtaining Service

    We take great pride in our dealers. Experience, dedication, and integrity make these professionals ideally suited to assist with our customers’ service needs. If your Proceed component must be serviced, please contact your dealer. Your dealer will then decide whether the problem can be remedied locally , or whether to contact Madrigal for further service information or parts, or to obtain a Return Authorization.

  • Page 38: Specifications

    1 IEC mains connector Madrigal provides an owner-transferable, five year extended warranty on all Proceed products within the U. S. and Canada ONLY. Warranty and service policies outside the U. S. and Canada are set by the local, authorized distributor and are applicable in the country of purchase ONLY. Madrigal products are designed to operate at set voltages appropriate for the country of sale and may be damaged if operated at the wrong voltage.

  • Page 39: Dimensions

    Dimensions 17.25" 43.8cm c d d track/index display power program– program+ prev/rew play/pause next/f.fwd 3.5" stop/drawer repeat time remaining 8.9cm on disc random program disc track PR O C E E D 14.25" 36.2cm 1.00" 2.00" 2.54cm 5.1 cm 12.27" 13.25"...
  • Page 40 Madrigal Audio Laboratories, Inc. 2081 South Main Street, P.O. Box 781 Middletown, Connecticut 06457 USA Telephone: (860) 346-0896 Fax: (860) 346-1540 http://www.madrigal.com/ PR O C E E D is a registered trademark of Madrigal Audio Laboratories, Inc. a Harman International company 630161-3 ©...
