Summary of Contents for Nxg NX-HDMIWL-R
-
Page 2: Safety Precautions
1. Important Information Take time to read this user manual before you Danger: Be careful with electricity. use your NX-HDMIWL-T and NX-HDMIWL-R. It contains important information and notes λ Power to the units must be switched off regarding operating your wireless HD receiver before any work is undertaken, such as and transmitter. -
Page 3: Declaration Of Conformity
EN 55024 Information technology equipment---- λ Ventilation: Do not block the ventilation Equipment---Immunity slots on the receiver/transmitter or place characteristics---Limits and methods of any heavy object on top of it. measurement Blocking the air flow could damage the EN 301 489-1 Electromagnetic compatibility and Radio receiver. - Page 4 HDTV set or projector where you want- just connect your HDTV set and NX-HDMIWL-R by HDMI cable. Any display like LCD, PDP or computer monitor with HDMI input connector are applicable to our NX-HDMIWL-R.
- Page 5 OUT jack at rear panel of the transmitter. Attach the IR blaster to the device connected to the NX-HDMIWL-T. You can point the device’s existing remote at the NX-HDMIWL-R receiver to control connected device. HDMI IN Connect Transmitter to High-definition video...
-
Page 6: Hdmi Out
Power Button with LED indicator DC IN Press to turn the receiver on and off. The For connecting the NX-HDMIWL-R power indicator in the Power button lights up in blue adapter. when the power is on, and turns red in standby mode. - Page 7 C. Remote Controller Instruction Button Function Description TRANSMITTER/ Press to turn the RECEIVER power NX-HDMIWL transmitter/receiver on/off. CHANNEL Press to change another wireless channel manually if you experience video noise. HDMI 1/2 Press this button to switch the video source from the connected HDMI device source.
-
Page 8: Installation
color and AUDIO R connection cable is the one with red color.) 3. Installation Step1: Multiple Devices Connection with NX-HDMIWL-T: Note: Transmitter has 4 source inputs which (1) Connect the NX-HDMIWL means you can have 4 choices for video sources (2) TRANSMITTER’s “HDMI IN”... - Page 9 Step2: HDTV set Connection with NX-HDMIWL-R: (1) Connect the HDMI cable between the HDMI OUT jack of the NX-HDMIWL-R and your HDTV set. Press the SOURCE/INPUT button on your TV’s remote to select “HDMI” video mode. (2) Attach one side of the provided Velcro (fastening tapes) to the receiver back cover.
- Page 10 Step3: If necessary, connect the Infrared (IR) Blaster & Sensor. Users can point hand-held remote control of your High Definition device at NX-HDMIWL-R or HDTV set directly for source device’s operation at Line-of-sight (20 meters transmission distance). Plug the IR Blaster cable into the IR If your connected device will be out of the OUT jack of the NX-HDMIWL-T.
- Page 11 Step 4: Power on your NX-HDMIWL-T and NX-HDMIWL-R (1) Place the two AAA batteries into the remote control. (2) If users already plugged the power cord, the power or NX-HDMIWL will be turned on automatically. If it’s under Standby mode (The POWER LED shows red), press the TRANSMITTER and RECEIVER POWER button to turn on the NX-HDMIWL-T and NX-HDMIWL-R.
- Page 12 (4) Ensure your LCD TV set or projector is set to HDMI input mode and already powered on. (5) Press the Source 1, HDMI 2, HDMI 3, YPbPr 4, YPbPr button, until you see the available video from your device. (6) If you have some electronic devices like cordless phone, wireless access point/ router used with 5GHz channel frequency near the NX-HDMIWL , you may experience no/noise picture or diminished sound quality.
- Page 13 Note: A. How to change to a different wireless channel for NX-HDMIWL: 1. Enter wireless RF channel 2. Changes to the next 3. Exit the wireless RF adjustment mode RF wireless channel channel adjustment mode There is no button on the Press the CHANNEL Press the CHANNEL Method...
- Page 14 (7) If all the operation is normal, the POWER, SOURCE LED will glow solid blue and Signal Quality will light in blue with 3 signal quality. Please refer the next LED details part: Note: A. Make sure your multiple High-Definition devices connected with NX-HDMIWL-T have already powered on.
-
Page 15: Troubleshooting
4. Troubleshooting Problem Solution • Check that the power plug of The NX-HDMIWL front panel NX-HDMIWL-T/NX-HDMIWL-R is properly inserted power indicator (red LED) into a functioning power outlet. doesn't light up. • Verify that the proper cable has been selected and installed between the desired transmitter input connector and your High-Definition device. - Page 16 • Check your video resolution with HDMI input from your device is 1080p @ 24/30 Hz, 1080i, 720p, 576p, 480p. Please refer to the Supported Resolution chapter that it define video consumer timing of your HD device NX-HDMIWL supports. Poor picture quality or •...
-
Page 17: Supported Resolution
5. Supported Resolution If the SOURCE LED continues to blink blue (slower than no signal mode) and there is no/abnormal video displayed, this is an indication that video format from your A/V source device is not supported. Ensure that the consumer timing of your HD device is compliant with below detail sheet. -
Page 18: Audio Formats Support
6. Audio Formats Support ν Analog Audio from Base Band audio L/ R inputs: Convert to 2-channel by fixed 24 bits/sample with sampling rate 48KHz by I S bus over Wireless High-Definition Interface transmission ν Digital Audio from HDMI inputs: Support up to 3.072Mbit/s ♦... -
Page 19: Product Specification
4.9~ 5.9GHz (non-DFS Frequency Bands) for US, EU, JP, TW Power Supply 100~ 240V AC in, 5V 3A DC out Power Adaptor Operating Temperature 0~40°C Regulations FCC, CE NX-HDMIWL-T NX-HDMIWL-R Interfaces Sets Component Input Connectors Analog Audio L/ R Sets A/V Interfaces... - Page 20 NXG TECHNOLOGIES www.nxgtechnology.com Tel: 1-800-733-0008...
