Summary of Contents for Salvo Primary Dive Lights
- Page 1 Primary Lighting Guide...
- Page 2 U S E A N D C A R E G U I D E For Salvo Primary Dive Lights © Salvo, LLC 705 NW Santa Fe Boulevard High Springs, FL 32643 Phone 386.454.0019 • Fax 386.454.1661...
-
Page 3: Table Of Contents
T able of Contents Lighting Innerspace -- One Explorer at a Time......2 Light Models ................2 Warranty Information..............2 Features ..................3 Charging and Storage ............... 5 Pre-Dive ..................6 Post-Dive................... 7 Changing the Bulb..............8 Rebel 12 and Handheld 9............10... -
Page 4: Lighting Innerspace -- One Explorer At A Time
• The Rebel 12W and Handheld 9W – LED Primary Lights Warranty Information All of the Salvo lights come with a one year warranty from the original date of purchase. The warranty covers all items including battery and charger. Please contact your local dealer or us directly should you experience any issues with your light that you may think is not right. -
Page 5: Features
Features All lights are delivered complete from our facility--including a fully charged battery pack, charger, and of course the light itself. HAVOC II and REBEL II PRIMARY LIGHTS • Dry Lid Utilizing Banana Connector. Based on constant customer request and our commitment to manufacture the highest quality primary light, the Havoc II and Rebel II lights utilize banana connectors from battery canister to lid. - Page 6 is a critical (and pricey) part to your primary light; it deserves the added attention and protection. • Delrin™ component construction. With the exception of the aluminum light heads on the Rebel II 21W LED’s, all of our components are housed within Delrin™ bodies. Delrin™ is a lightweight, low-friction, and wear-resistant thermoplastic with good physical and processing properties and capable of operating in temperatures in excess of 200 degrees Fahrenheit (approximately...
-
Page 7: Charging And Storage
Charging and Storage All lighting systems come fully charged from our facility; you will need to use the There are no customer serviceable light before being able to charge it again. components sealed within this pack… SO, STAY OUT OF IT! All warranty claims will be nullified if the internal seal of the pack has been compromised. -
Page 8: Pre-Dive
• LED will glow red while charging and will turn green when the charge cycle is completed. • It is recommended from the battery manufacturer to leave the Li-Pol packs partially discharged (30-50% rated capacity) when storing. Pre-Dive To ensure years of dependable service from your light, follow the steps below during your pre-dive setup. -
Page 9: Post-Dive
• When closing the locking latches, make sure to apply pressure evenly and simultaneously to the latches. • Turn on the light and make sure it comes on. It is best to leave the light on for at least 30 seconds before turning off. Although the Brightstar™... -
Page 10: Changing The Bulb
Changing the Bulb There are no user serviceable components in the Rebel II series of LED primary lights. If you are experiencing any issues, please return them to Salvo for service, inspection, and repair. The Havoc II series of HID primary light features a user replaceable bulb. - Page 11 • Carefully remove the lamp cover by gently pulling it off with a twisting motion. It is best to use a glove or wrap the lamp cover with a small towel to protect your hand from accidental breakage of the glass. Note –...
-
Page 12: Rebel 12 And Handheld 9
• Connect the new bulb to the lead wires from the ballast. • Reinstall the bulb into the socket. Twist the bulb with a ¼ turn as you do so to help the wires back into the socket assembly. • Holding the lamp cover with a glove or towel, reinstall the lamp cover with a slight twisting motion. - Page 13 • Inspect threads and o-rings to ensure they are free from dirt and debris. • Connect universal charger to wall outlet. • Connect universal charger to tail piece.
- Page 14 • LED will glow red while charging and will turn green when the charge cycle is completed. • It is recommended from the battery manufacturer to leave the Li-Ion packs partially discharged (30-50% rated capacity) when storing. Diving The switch for the Rebel 12W LED and Handheld 9W LED primary lights is located in the light head and is double o-ring sealed.
