CAUTION: This stabilized antenna system is designed to be used with transmit/receive equipment manufactured
by others. Refer to the documentation supplied by the manufacturer which will describe potential hazards,
including exposure to RF radiation, associated with the improper use of the transmit/receive equipment. Note that
the transmit/receive equipment will operate independently of the stabilized antenna system. Prior to work on
the stabilized antenna system, the power to the transmit/receive system must be locked out and
tagged.
When the transmit/receive system is in operation, no one should be allowed anywhere within the radiated
beam being emitted from the reflector.
The ultimate responsibility for safety rests with the facility operator and the individuals who work
on the system.
Sea Tel, Inc.
4030 Nelson Avenue
Concord, CA 94520
Tel: (925) 798-7979
Fax: (925) 798-7986
Email: seatel@cobham.com
Web: :
www.cobham.com\seatel
December 16, 2009
INSTALLATION AND OPERATION
MANUAL FOR SEA TEL BROADBAND-AT-SEA
Sea Tel Inc doing business as Cobham SATCOM
TRANSMIT / RECEIVE SYSTEM
MODEL: 2406-7
Document. No. 126843 Revision D
Sea Tel Europe
Unit 1, Orion Industrial Centre
Wide Lane, Swaythling
Southampton, UK S0 18 2HJ
Tel: 44 (0)23 80 671155
Fax: 44 (0)23 80 671166
Email: seatel@cobham.com
Web:
www.cobham.com\seatel
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Summary of Contents for Sea Tel 2406-7
- Page 1 Southampton, UK S0 18 2HJ Fax: (925) 798-7986 Tel: 44 (0)23 80 671155 Email: seatel@cobham.com Fax: 44 (0)23 80 671166 Web: : www.cobham.com\seatel Email: seatel@cobham.com Web: www.cobham.com\seatel Sea Tel Inc doing business as Cobham SATCOM December 16, 2009 Document. No. 126843 Revision D...
- Page 2 All Rights Reserved. The information contained in this document is proprietary to Sea Tel, Inc.. This document may not be reproduced or distributed in any form without the consent of Sea Tel, Inc. The information in this document is subject to change without notice.
- Page 4 Revision History ECO# Date Description December 7, 2007 Production Release. May 2, 2008 Updated text & drawings January 23, 2009 Change BUC to 8W NJRC. Updated text, & drawings. Updated font & logo. December 16, 2009 Updated Text, Graphics, and Drawings to reflect current build and GSR2 features...
-
Page 5: Table Of Contents
Table of Contents 2406-7 Broadband At Sea INTRODUCTION ......................................1-1 1.1..................................1-1 ENERAL YSTEM ESCRIPTION 1.2........................................... 1-1 URPOSE 1.3......................................1-1 YSTEM OMPONENTS 1.4..................................1-1 ENERAL SCOPE OF THIS MANUAL 1.5..................................1-1 UICK VERVIEW OF CONTENTS OPERATION ........................................ - Page 6 2406-7 Broadband At Sea Table of Contents 4.4.2. Antenna Pedestal Mechanical Checks ..........................4-2 4.5......................................4-3 ABLE NSTALLATION 4.5.1. Shipboard Cable Installation ..............................4-3 4.5.2. Cable Terminations In The Radome ............................ 4-3 4.6....................................4-4 ELOW ECKS QUIPMENT 4.6.1.
- Page 7 – S 06 ........................7-16 EDESTAL ONTROL ONFIGURATION ERIES 7.5.1. To configure the PCU; ................................7-16 7.5.2. Model Configuration Numbers ............................7-16 2406-7 TECHNICAL SPECIFICATIONS ............................8-1 8.1. 2406 .................................. 8-1 NTENNA EFLECTOR 8.2. RF E ........................................8-1 QUIPMENT 8.3.
- Page 8 2406-7 Broadband At Sea Table of Contents This Page Intentionally Left Blank viii...
-
Page 9: Introduction
1.4. General scope of this manual This manual describes the Sea Tel Series 06 Antenna (also called the Above Decks Equipment), its’ operation and installation. Refer to the manual provided with your Antenna Control Unit for its’ installation and operating instructions. - Page 10 2406-7 Broadband At Sea Introduction THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 11: Operation
Operation 2406-7 Broadband At Sea Operation Operation of your system is accomplished from the DAC-2202 Antenna Control Unit (ACU). Refer to the operation section of the DAC-2202 Antenna Control Unit manual. 2.1. System Power-up Turn the power switch on front panel of the Antenna Control Unit (ACU) and the breaker switch inside the Antenna Radome ON to energize both units. -
Page 12: Antenna Polarization Operation
2406-7 Broadband At Sea Operation DishScan continuously drives the antenna in a very small circular pattern at 60 RPM. The ACU evaluates the received signal throughout each rotation to determine where the strongest signal level is (Up, Right, Down or Left) and then issues the appropriate Azimuth and/or Elevation steps to move the antenna toward where stronger signal is. -
Page 13: Basic System Information
Basic System Information 2406-7 Broadband At Sea Basic System Information This section provides you with some basic information about your antenna system and other equipment within your system configuration. 3.1. Satellite Basics The satellites are in orbit at an altitude of 22,753.2 Statute Miles positioned directly above... -
Page 14: Signal Level
2406-7 Broadband At Sea Basic System Information 3.1.2. Signal level The level of the receive signal on a point on the globe is dependant upon how powerful the transmission is and how wide the signal beam is coverage area is. Focusing the signal into a narrower beam concentrates its energy over a smaller geographic area, thereby increasing the signal level throughout that area of coverage. -
Page 15: Elevation
3.2.6. Stabilization This Sea Tel antenna is stabilized in three axes of motion. Stabilization is the process of de-coupling the ships motion from the antenna. Simply put, this allows the antenna to remain pointed at the satellite while the boat turns, rolls or pitches under it. To accomplish this, the Pedestal Control Unit (PCU) on the antenna pedestal senses any motion of the antenna and immediately applies drive to the appropriate motor(s) to oppose the sensed motion. -
Page 16: Tracking
2406-7 Broadband At Sea Basic System Information the satellite are saved to expedite future acquisition of the desired satellite. The system must have adequate satellite signal level to stop searching (and begin tracking the acquired satellite). 3.2.9. Tracking The ACU actively optimizes the pointing of the dish for maximum signal reception. This process is called tracking and is accomplished by continuously making small movements of the dish while monitoring the level of the received signal. -
Page 17: Above Decks Ac Power Supply
Basic System Information 2406-7 Broadband At Sea The Antenna Control Unit (ACU) communicates via an RS-422 full duplex data link with the Pedestal Control Unit (PCU) located on the antenna. This control signal to/from the antenna is on the Coax cable along with the L-Band Receive IF from the LNB. -
Page 18: Interface Requirements
2406-7 Broadband At Sea Basic System Information 3.5.2. Interface requirements: 3.5.2.1. Hardware Sea Tel Antenna Control Units Model DAC2202 or DAC2302. Any Satellite modem manufacturer that is compatible with OpenAMIP CAT5 Patch cable 3.5.2.2. Software Sea Tel model DAC2202: ACU software version 6.06 or greater CommIF module software version 1.11 or greater... -
Page 19: Installation
Installation 2406-7 Broadband At Sea Installation Your antenna pedestal comes completely assembled in its radome. This section contains instructions for unpacking, final assembly and installation of the equipment. It is highly recommended that installation of the system be performed by trained technicians. -
Page 20: Installing The Above-Decks Equipment (Ade)
2406-7 Broadband At Sea Installation 4.4. Installing the Above-Decks Equipment (ADE) 4.4.1. 34” Radome Assembly The antenna pedestal is shipped completely assembled in its 34” radome. WARNING: Hoisting with other than a webbed four-part sling may result in catastrophic crushing of the radome. Refer to the specifications and drawings for the fully assembled weight of your model Antenna/Radome and assure that equipment used to lift/hoist this system is rated accordingly. -
Page 21: Cable Installation
Installation 2406-7 Broadband At Sea Remove the radome top to access the pedestal. Inspect the pedestal assembly and reflector for signs of shipping damage. Remove the web strap shipping restraints from the pedestal. Save these straps to restrain the antenna in the event that the AC power will be turned off while the ship is underway. -
Page 22: Below Decks Equipment
2406-7 Broadband At Sea Installation Route AC Power cable into the breaker box and terminate to the breaker terminals. Attach the TX and RX cables from below decks to the adapters. See the Radome Assembly and System Block Diagram drawings. -
Page 23: Set-Up & Configuration
Contact Sea Tel for the Internet Service Provider (ISP) Network Operation Center (NOC) ASSIGNED IP address, SubNet Mask and the Primary & Secondary DNS addresses if they have not been previously provided to you, or if you have changed providers. -
Page 24: Optimizing Auto-Polarization Tx/Rx
2406-7 Broadband At Sea Set-up & Configuration 5.4. Optimizing Auto-Polarization TX/RX This procedure optimizes the linear polarization of the feed, if your system is fitted with a circular feed you do not need to optimize the polarity angle and can skip this procedure. At the ACU, turn tracking and DishScan Drive off. - Page 25 Set-up & Configuration 2406-7 Broadband At Sea If Targeting has NOT been optimized, allow the antenna to initialize to its home flag position. Visually compare the antennas pointing to the bow-line of the ship (parallel to the Bow). Note the antennas position relative to the Bow.
-
Page 26: To Enter The Hfo Value
2406-7 Broadband At Sea Set-up & Configuration 5.5.2. To Enter the HFO value: To enter the calculated HFO value, press & hold both LEFT and RIGHT arrows for six seconds to enter the parameter menu at the EL TRIM parameter window. Press DOWN arrow key numerous times (about 21) until you have selected the REMOTE COMMAND window. -
Page 27: Tx Polarity Setup
Set-up & Configuration 2406-7 Broadband At Sea 5.7. TX Polarity Setup With the feed in the center of its polarization adjustment range, observe the transmit port polarity (vector across the short dimension of the transmit wave-guide). If the transmit polarity in the center of the travel range is vertical, use the following entries:... -
Page 28: Default Setup Parameters
2406-7 Broadband At Sea Set-up & Configuration 5.9. Default Setup Parameters The following table shows the factory default parameters for the DAC-2200, or DAC-2202, Antenna Control Unit interfaced to a Series 06 Antenna PCU. When the installation & setup of your system is finished you can record the “optimized”... -
Page 29: Functional Testing
6.1. ACU / Antenna System Check Press RESET on the ACU front panel to initialize the system. Verify the display shows "SEA TEL INC - MASTER" and the ACU software version number. Wait 10 seconds for the display to change to "SEA TEL INC - REMOTE"... -
Page 30: Blockage Simulation Test
• When used as simple “BLOCKED” logic output for a single Sea Tel antenna, this output could be used to light a remote LED and/or sound a buzzer to alert someone that the antenna is blocked, and signal is lost. -
Page 31: Maintenance And Troubleshooting
7.1. Warranty Information Sea Tel Inc. supports its Series 97, 00, 06 and 07 systems with a ONE YEAR warranty on parts and labor. What’s Covered by the Limited Warranty? The Sea Tel Limited Warranty is applicable for parts and labor coverage to the complete antenna system, including all above-decks equipment (radome, pedestal, antenna, motors, electronics, wiring, etc.) and the Antenna Control Unit... -
Page 32: Check Acu Parameters
2406-7 Broadband At Sea Maintenance and Troubleshooting 7.2.1. Check ACU Parameters Assure that the parameters are set correctly (you may wish to record them in the Factory Default Settings, in section 5 of this manual). 7.2.2. Latitude/Longitude Auto-Update check Refer to the Latitude & Longitude Update check procedure in the Functional Testing section of this manual. -
Page 33: Troubleshooting
Maintenance and Troubleshooting 2406-7 Broadband At Sea 7.3. Troubleshooting 7.3.1. Theory Of Stabilization Operation The antenna system is mounted on a three axis stabilization assembly that provides free motion with 3 degrees of freedom. This assembly allows the inertia of the antenna system to hold the antenna pointed motionless in inertial space while the ship rolls, pitches and yaws beneath the assembly. -
Page 34: Troubleshooting Using Dacremp
7.3.3. Troubleshooting using DacRemP While troubleshooting a Sea Tel 3-Axis Antenna System, you must classify the fault you are dealing with as a failure within one of 3 major system functions, Targeting, Stabilization, and Tracking. Should there be a failure with any one of these functions, your system will not operate properly. A few simple checks may help determine which fault (if any) that you are dealing with. -
Page 35: Antenna Loop Error Monitoring
Maintenance and Troubleshooting 2406-7 Broadband At Sea 7.3.4. Antenna Loop Error Monitoring The DacRemP DISPIVC graph chart provides a means for monitoring the accumulated velocity errors of the antenna for diagnostic purposes. If this error is excessive, it indicates external forces are acting on the antenna. -
Page 36: Reference Sensor Monitoring
2406-7 Broadband At Sea Maintenance and Troubleshooting Elevation Axis physically moved CW. (reflector slightly pushed up) and then physically moved CCW. (reflector slightly pushed down.) At the end of chart recording shows • DishScan Drive turned Off, notice the lack of accumulated IVC errors. -
Page 37: Open Loop Rate Sensor Monitoring
Maintenance and Troubleshooting 2406-7 Broadband At Sea • The Level tilt display should plot on the red reference line when the level cage is level, referenced to the horizon. It should decrease (plots below red line) when the antenna is tilted forward (EL down) and increase (plots above red line) when tilted back (EL up). - Page 38 2406-7 Broadband At Sea Maintenance and Troubleshooting • The Cross Level display should decrease (plots below red line) as the antenna is tilted to the left and increase (plots above red line) as the antenna tilted to the right. •...
-
Page 39: Open Loop Motor Test
Maintenance and Troubleshooting 2406-7 Broadband At Sea 7.3.7. Open Loop Motor Test The DacRemP Comm Diagnostics Window provides a means to enter in Remote Commands for driving each individual torque motor to test that motors functionality. By driving each axis and observing the resulting motion of the antenna, a coarse operational status of the motor and motor driver may be established. -
Page 40: To Read/Decode An Acu Error Code 0008 (Pedestal Function Error)
2406-7 Broadband At Sea Maintenance and Troubleshooting • GPS Satellite Compass is being used To view, or change, the Satellite Reference Mode status, select the SAT REF remote parameter: Press the RIGHT arrow, then press the UP arrow and last press the ENTER key to turn Satellite Reference Mode ON. - Page 41 Maintenance and Troubleshooting 2406-7 Broadband At Sea Right mouse click on the icon. This will display a list box with the status of the above decks pedestal filtered into 3 sections. Items preceded with a check marks indicate a flagged status. See matrix below for further information on each state.
-
Page 42: Remote Gps Lat/Lon Position
2406-7 Broadband At Sea Maintenance and Troubleshooting PCU Error Status (Word 3) Sensor Limit **Not a valid state** Stability Limit Indicates that the above decks equipment is mis-pointed from its intended target by more than 0.5°. (FCC Tx Mute Compliance) -
Page 43: Maintenance
Furuno default value is in Japan at 34.4N 135.2E (@3444,N,13521,E,,_). After acquiring a good fix at Sea Tel the string is @3800,N,12202,W,A^ for our 38N 122W Latitude and Longitude position. The status character tells you the status of the GPS. -
Page 44: To Adjust Tilt
2406-7 Broadband At Sea Maintenance and Troubleshooting The recommend balancing order is Elevation Axis with the antenna pointed at the horizon (referred to as front to back balance). Elevation Axis with the antenna pointed at zenith (referred to as top to bottom balance). -
Page 45: To Reset/Reinitialize The Antenna
Maintenance and Troubleshooting 2406-7 Broadband At Sea Step 6: Press ENTER key to exit Remote Tilt Mode. Step 7: Verify Tilt Bias entered is within specifications. From antenna: Observe the bubble for approximately 3-5 minutes to ensure it remains centered. -
Page 46: Pedestal Control Unit Configuration - Series 06
2406-7 Broadband At Sea Maintenance and Troubleshooting 7.5. Pedestal Control Unit Configuration – Series 06 The PCU is designed to be used with a variety of antenna pedestal models. So, the PCU must be configured correctly for the model number of the antenna it is mounted on. The configuration information that is unique to each pedestal model is stored in a Non Volatile Random Access Memory (NVRAM) in the PCU enclosure. -
Page 47: Technical Specifications
2406-7 Technical Specifications 2406-7 Broadband At Sea 2406-7 Technical Specifications The specifications of your 4006 antenna system are below. 8.1. Antenna Reflector/Feed 2406 Type Spun Aluminum axis symmetric reflector Size 24 inch (61.0cm) Feed Center focus Cassegrain feed with Co-Pol or Cross-Pol OMT LNB (s) Single output Linear LNBs can be provided;... -
Page 48: Stabilized Antenna Pedestal Assembly
2406-7 Broadband At Sea 2406-7 Technical Specifications 8.4. Stabilized Antenna Pedestal Assembly Type: Three-axis (Level, Cross Level, AZ) Stabilization: Torque Mode Servo Stab Accuracy: 0.3 degrees MAX, 0.15 degrees RMS in presence of specified ship motions (see below). LV, CL, AZ motors: Size 23 Brushless DC Servo. -
Page 49: Unlimited Azimuth Modem/Multiplexer (3 Channel)
2406-7 Technical Specifications 2406-7 Broadband At Sea 8.6. Unlimited Azimuth Modem/Multiplexer (3 Channel) Combined Signals (-1,-2) Pass-Thru 70, 140, 950-2050 MHz RX IF, 22Khz Tone DC LNB Voltage Select Injected 1.1 / 1.5Mhz Pedestal M&C Connectors: RX IF F female... -
Page 50: Environmental Conditions (Above Decks Equipment)
2406-7 Broadband At Sea 2406-7 Technical Specifications 8.8. Environmental Conditions (Above Decks Equipment) Temperature: -20 degrees C to 55 degrees C. Humidity: Up to l00% @ 40 degrees C., non-condensing. Spray: Resistant to water penetration sprayed from any direction. Icing: Survive ice loads of 4.5 pounds per square foot. -
Page 51: Cables
DE-9P 8.10.2. Antenna L-Band IF Coax Cables (Customer Furnished) Due to the loss across the length of the RF coaxes at L-Band, Sea Tel recommends the following coax cable types (and their equivalent conductor size) for our standard pedestal installations:... - Page 52 2406-7 Broadband At Sea 2406-7 Technical Specifications This Page Intentionally Left Blank...
-
Page 53: Drawings
DRAWINGS 2406-7 Broadband At Sea DRAWINGS The drawings listed below are provided as apart of this manual for use as a diagnostic reference. 9.1. 2406-7 Ku-Band Model Specific Drawings Drawing Title 129070-2_A1 2406-7 System, 34” Radome 129073-1_B1 2406-7 System Block Diagram... - Page 54 2406-7 Broadband At Sea DRAWINGS This Page Intentionally Left Blank...
- Page 55 CUSTOMER DOC PACKET, 2406 2 EA 114239 SIGN, WARNING MICROWAVE 1 EA 123324-2 SHIP STOWAGE KIT, XX04 & XX03 & 24XX SYSTEM, 2406-7, LIN, 8W, NO LNB, 34 INCH DOME PROD FAMILY EFF. DATE DRAWING SHT 1 OF SERIES 06...
- Page 57 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 129071-1 GENERAL ASS'Y, 2406-7, 8W 1 EA 125808-1 RADOME ASS'Y, 24XX GA INSTALL, 34 IN FOR 34 IN SYSTEMS 1 EA 126088-1 RADOME ASS'Y, 2403 GA INSTALL, 40 IN...
- Page 58 1 EA 119478-5 C3 CABLE ASS'Y, RJ-45 SERIAL, 60 IN. FOR CFE IDIRECT MODEM 1 EA 115492-1 C1 ADAPTER, N(F)-SMA(F), W/FLANGE 1 EA 110567-19 ADAPTER, N(F)-N(F), STRAIGHT, FLANGE SYSTEM BLOCK DIAGRAM, 2406-7/8W PROD FAMILY EFF. DATE DRAWING SHT 2 OF 12/16/2009 NUMBER...
- Page 60 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 127005-3 B3 PEDESTAL ASS'Y, 2406-7, 8W 1 EA 129299-3 ANTENNA ASS'Y, OPTIM 24 IN, TX/RX, W/ 1 EA 129072-1 EQUIPMENT FRAME ASS'Y, 2406-7/8W 1 EA 126537...
- Page 63 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 122137 REFLECTOR MACHINING, 24 IN 1 EA 122997 (SEE COMMENT) VERTEX FEED, 24 IN., 24 1 EA 129298-3 A1 FEED ASS'Y, CROSS POL, W/COAX RJ, 240 2 EA 124160 BRACKET, REFLECTOR 4 EA 114583-005...
- Page 64 REVISION HISTORY ECO# DESCRIPTION DATE 11-24-08 ADDED BOTTOM VIEW SHOWING POLANG ORIENTATION. K.D.H. DELETED DETAIL 'A'; MOVED NOTE "STUDS TO BE FLUSH WITH BORE SURFACE OF FEED PLATE" TO DRAWING 126990; 12-11-08 K.D.H. CORRECTED BUBBLING FOR SCREWS; RELEASED TO PRODUCTION, WAS X2. 70 71 71 71 71 ALIGN POLANG ASS'Y...
- Page 65 CABLE CLAMP, NYLON, 3/4 DIA, #10 MTG 1 OZ 125948-1 ADHESIVE, HOT MELT, 3M SCOTCH-WELD 37 NOT SHOWN 2 EA 110481-4 G DECAL, LOGO, SEA TEL, 16 X 6.3 IN 1 EA 123549 KIT, RADOME HARDWARE MOUNTING 2 EA 114588-190 SCREW, PAN HD, PHIL, 8-32 x 1/4, S.S.
- Page 70 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 127421-1 SPARE PARTS KIT, 2406, STANDARD 1 EA 117168-2 P1 MODEM ASS'Y, BASE, 3 CH, 75 OHM 1 EA 117168-1 P1 MODEM ASS'Y, PEDESTAL, 3 CH, 75 OHM 1 EA 125570-2 H POWER SUPPLY ASS'Y, COSEL 150W, RH EN 1 EA 114789-810...
- Page 71 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 127422-1 SPARE PARTS KIT, 2406, PREMIUM 1 EA 121250-1 C3 POWER RING ASS'Y, 22 IN, 66 IN. CONTA 1 EA 116466 D ROTARY JOINT, 4.5 GHz, DUAL COAX. 1 EA 121966 D2 GPS ANTENNA, RETERMINATED, 90.0 L SPARE PARTS KIT, 2406, MASTER...
- Page 73 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 112657 D MACHINING, TERMINAL MOUNTING STRIP 1 EA 126865-2 PCB ASS'Y, TERMINAL MOUNTING STRIP, 5 1 EA 112936-36 D1 CABLE ASS'Y, D-SDB, 25 PIN, 36 IN 1 EA 116669-36 B1 CABLE ASS'Y, D-SUB, 9-PIN, 36 IN.
- Page 75 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 116880 G PANEL MACHINING, RACK, BASE MUX 1 EA 117168-2 P1 MODEM ASS'Y, BASE, 3 CH, 75 OHM 1 EA 116388 D BRACKET, CONNECTOR 1 EA 115492-1 C1 ADAPTER, N(F)-SMA(F), W/FLANGE 8 EA 114588-107...
