MULTIMETER CURRENT CLAMP (Code: M80430) INSTRUCTION MANUAL ( M98111201-03-10A ) © © © © CIRCUTOR S.A. -
Page 2: Safety Notes
--------- MULTIMETER CURRENT CLAMP -------- PG No. 1 CPM ANALYZER INDEX page no. SAFETY NOTES Before using the equipment please read the user manual, paying special attention to the SAFETY REQUIREMENTS section. The symbol on the equipment means "CONSULT THE INSTRUCTION MANUAL". - Page 3 --------- MULTIMETER CURRENT CLAMP -------- PG No. 2 The analyzer is powered by a 9 V battery. Its design and its double insulation makes the CPM a robust and secure instrument.
-
Page 4: Specifications
--------- MULTIMETER CURRENT CLAMP -------- PG No. 3 1.2.- Specifications Display 3 ½ digit LCD display with a maximum reading of 1999. Display functions Measurement value hold. Hold Maximum measurement value hold. Automatic, positive by default and indication Polarity of negative polarity (-). (OL) or (-OL) appears on the display. - Page 5 --------- MULTIMETER CURRENT CLAMP -------- PG No. 4 9 V, IEC 6F22 battery. Power Supply Battery life Typically 200 hours for a zinc-carbon battery Environmental conditions 0 ° C to 40 ° C (H.R. 0-70%) Operating temperature 20 ° C to 60 ° C, (H.R. 0-80%) with the Storage temperature battery removed 250 (W) x 100 (H) x 46 mm.
- Page 6 --------- MULTIMETER CURRENT CLAMP -------- PG No. 5 DC Voltage 600 V Range ± (0.5% read. + 1 digit) Accuracy 10 MΩ Input impedance 600 V DC or AC rms Overload protection AC Voltage (50-500 Hz) 200 V, 600 V Ranges ±...
- Page 7 --------- MULTIMETER CURRENT CLAMP -------- PG No. 6 Continuity Sound alarm Less than 30Ω in the range of 2kΩ. 600 V DC or AC rms Overload protection Diode test 1.0 mA ± 0.6 mA Test current ± (6.0% read. + 3 digits) Accuracy 3.0 V DC typically Open circuit tension...
- Page 8 --------- MULTIMETER CURRENT CLAMP -------- PG No. 7 700 A AC Max. during 1 minute.
-
Page 9: Safety Requirements
--------- MULTIMETER CURRENT CLAMP -------- PG No. 8 2.- SAFETY REQUIREMENTS 2.1.- General This equipment can be used in environments of Pollution Degree 2. Overvoltage Category: See sections 2.2 and 2.3. In order to ensure safety only the following specified types of the accessories must be used: Test probes: Always keep the specified ranges in mind for both power supply and... - Page 10 --------- MULTIMETER CURRENT CLAMP -------- PG No. 9 Symbols: The analyzer is protected by double or reinforced insulation. Caution! Risk of electric shock. Caution! See this manual before using the analyzer. Fuse Alternating current Direct current Alternate and direct Earth terminal Protection terminal Shell terminal Equipotentiality...
-
Page 11: Special Precautions
--------- MULTIMETER CURRENT CLAMP -------- PG No. 10 2.2.- Special precautions This equipment can be used for Overvoltage Category II installations. The clamp can be used exclusively for the measurement of current for installations of up to 600 V with Overvoltage Category IV. When using the test probes fingers must be kept behind the protection outcrops. - Page 12 --------- MULTIMETER CURRENT CLAMP -------- PG No. 11 3.- INSTRUCTIONS FOR USE 3.1.- Description of controls and elements...
- Page 13 --------- MULTIMETER CURRENT CLAMP -------- PG No. 12 [1] Rotary function switch Analyzer off DC voltage measurement, range 600 V DC current measurement, range 700 A DC current measurement, range 200 A Resistance measurement, range 200 kΩ Continuity test and resistance measurement, range 2 kΩ Diode test Hz Frequency measurement AC current measurement, range 200 A...
- Page 14 --------- MULTIMETER CURRENT CLAMP -------- PG No. 13 [3] V input terminal for AC/DC voltage measurement [4] COM common input terminal for test probes for all measurements. [5] Input terminal for resistance measurements, frequency and diode tests. [6] DISPLAY Display of measured values and operating mode [7] MAX maximum value hold key This key selects/deselects the MAX measuring mode.
- Page 15 --------- MULTIMETER CURRENT CLAMP -------- PG No. 14 3.2.- Use ATTENTION When the value to be measured is unknown always place the rotary switch to the highest range and reduce it progressively in function of the value in question. 3.2.1.- Voltage measurement 1.
- Page 16 --------- MULTIMETER CURRENT CLAMP -------- PG No. 15 3.2.2.- Current measurement 1. Set the rotary switch [1] to the desired higher range 700 A (AC or DC). In DC current measurement mode use the DCA ZERO button [2] to delete the offset due to the residual magnetism of the clamp.
- Page 17 --------- MULTIMETER CURRENT CLAMP -------- PG No. 16 3.2.4.- Frequency measurement 1. Set the rotary switch [1] to the Hz position. 2. Connect the red test probe to the terminal [5] and the black test probe to the COM terminal [4]. 3.
- Page 18 --------- MULTIMETER CURRENT CLAMP -------- PG No. 17 3.2.6.- Diode test 1. Connect the black test probe to the COM terminal [4] and the red test probe to the terminal [5]. 2. Set the rotary switch [1] to the position “ “...
-
Page 19: Maintenance
--------- MULTIMETER CURRENT CLAMP -------- PG No. 18 4.- MAINTENANCE Attention : Disconnect the test probes before changing the battery or performing any maintenance service. 4.1.- Battery replacement When the symbol “ ” appears on the lower left corner of the LCD indicator, the batteries must be replaced: 1. -
Page 20: Technical Service
Do not use abrasives or solvents. Dry thoroughly before reusing the equipment. 4.3.- TECHNICAL SERVICE In the case of any query regarding the operation or fault of the equipment contact the CIRCUTOR S.A technical service. CIRCUTOR S.A. - Post-sales service Vial Sant Jordi, s/n 08232 – Viladecavalls Tel.
