Midcontinent Standard Digital Adapter Quick Start Manual

Standard Digital Adapter

Quick Start Guide

Installation and Activation Steps:
Step 1:
Connect the Digital Adapter
to the Cable Outlet
1: Locate the cable that currently
runs from the cable wall outlet to
the back of your TV. Leave one end
of the cable connected to the wall,
but disconnect the other end from
the back of your TV.
2: Reconnect this end of the cable to
the "Cable In" input on the back of
the Adapter.
1
2
Step 4:
Set the Channel
1: Turn on your TV and tune it to
channel 3. Make sure your volume
is on.
2: Set the switch on the back of the
Adapter to channel 3.
Note: If you do not have a picture
after completing the activation, you
may need to switch both your TV
and Adapter to channel 4.
1
NOTE: Illustrations used in this installation guide are for reference only and may differ from the actual product.
Step 2:
Connect the Digital Adapter
to the TV
1: Find the 3-foot coax cable included in
this kit. Connect one end of the cable
to the "To TV" input on the back of
the Adapter.
2: Connect the other end to the
"Cable In/RF In" input on the
back of your TV.
2
ADAPTER
Step 5:
Activate
1: You must connect all Digital Adapters
before activating. If you are going
to mount the Adapter to the back of
the TV, do not do so until after the
Adapter is activated.
2: Your Digital Adapter needs up to
15 minutes to sync before activating.
Check the green light on the front
panel. If it's blinking twice, you're
ready for activation.
3: Ensure your remote control has
ADAPTER
been programmed for your TV.
Note: See the "Using Your Remote
Control" panel on page 3 for
2
programming steps.
4: To activate your device,
call 1.800.888.1300 and
follow the prompts or visit
123Free.midcocomm.com.
TV
1
Step 3:
Power Up
1: Plug the round end of the power cord
into the "Power" input on the back of
the Adapter.
2: Plug the other end into a live power
outlet or surge protector.
ADAPTER
Step 6:
Confirm Your Service
1: After completing Step 5,
wait a few minutes.
2: Make sure your TV is on.
3: Confirm that the Adapter is
connected to the power outlet
and that the light on the front is
solid (not blinking).
4: Using the remote control to operate
your Digital Adapter, scroll through
your channels and make sure they
are all working.
Note: If the light is blinking, or your
channels are not showing up, turn
to the Troubleshooting section of
this guide.
Digital Adapter Quick Start Guide - 1
