SQP110 Series
User's Manual V1.0.3
SQP110V103-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SQP110 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision SQP110 Series

Summary of Contents for GeoVision SQP110 Series

  • Page 1 SQP110 Series User’s Manual V1.0.3 SQP110V103-B...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    4.3.4 Inserting a Video on a Page ................30 4.3.5 Generating a QR Code on a Page ..............32 4.3.6 Creating a Ticker on a Page................34 4.3.7 Verifying the Slideshow with the Flowchart ..........36 4.4 Playing the Interactive Slideshow on SQP110 Series ..........37...
  • Page 4 4.5 Customizing the Screen Saver for SQP110 Series ..........38 Chapter 5 Content Schedule ...............40 5.1 Installing the Schedule..................40 5.2 Setting the Content Schedule ................41 Chapter 6 CMS Lite ................48 6.1 Additional System Requirements................49 6.2 Installing the CMS Lite ..................51 6.3 Connecting SQP110 Series to the CMS ...............52 6.4 The Main Screen....................54...
  • Page 5 7.8.4 Device Event Analysis (Counts) ..............81 7.8.5 Device Event Analysis (Elapsed Time)............82 7.9 Server Setting .......................83 7.9.1 User Account ....................83 7.9.2 Network Setting ...................84 7.9.3 Email Service ....................85 7.9.4 Package Management ................87 7.10 Upgrading the Firmware ..................88 Chapter 8 Dynamic DNS ..............89 8.1 Installing the Dynamic DNS ..................89 8.2 Registering Domain Name..................90 8.3 Starting Dynamic DNS ..................92...

  • Page 6: Note

    The demonstration examples included in the Software CD are created by the Clip Design software. You can store and play these examples on the SQP110 series before you start to create your own slideshows. For details, see Appendix A. Playing the Demonstration...

  • Page 7: Chapter 1 Introduction

    The device is available in black or white color. SQP110 series is built in a SD card slot and a USB port. The SD card slot is for connection to the SD card that stores the slideshow files, and the USB port is for connection to the USB storage device, which is used for firmware upgrade or files transfer to the SD card.

  • Page 8: Packing List

    1.2 Packing List SQP110 device × 1 AC/DC adapter × 1 IR remote control × 1 Software CD × 1 Magnetic rear rack × 1 1.3 Optional Accessory USB to RJ-45 Cable...

  • Page 9: Overview

    Introduction 1.4 Overview This section identifies the components of the SQP110 series. 1.4.1 The Right Panel Figure 1-1 No. Name Function Navigate the OSD menu to go up. RIGHT Navigate the OSD menu to go right. ENTER Enter the OSD menu or select a desired item from the menu.

  • Page 10: The Left Panel

    1.4.2 The Left Panel Figure 1-2 No. Name Function Built-in IR receiver to receive the IR signals from the IR remote control. The green LED indicates the power is supplied. LED Indicators The red LED indicates the USB port or the SD card slot is used.

  • Page 11: The Ir Remote Control

    Introduction 1.5 The IR Remote Control Figure 1-3 No. Name Function POWER Turn on the power. Display the initial screen, or display the first page of the MENU slideshow when the storage device that contains the Scenario folder is connected. MUTE Turn volume mute.
  • Page 12 Increase or decrease volume. Display the initial screen, or display the first page of the BACK slideshow when the SD card that contains the Scenario folder is connected. SETUP Activate OSD menu in the state of initial screen.

  • Page 13: Chapter 2 Getting Started

    Chapter 2 Getting Started 2.1 Turning on the Power 1. Plug the power adapter into the DC socket (No. 9, Figure 1-1). 2. Turn on the SQP110 series (No. 8, Figure 1-1). The main screen with a Setup icon appears. Setup...

  • Page 14: The Main Screen Of The Touch Screen Model

    2.2 The Main Screen of the Touch Screen Model You can find 4 touch buttons on the main screen of the touch screen model (SQP110T): Volume Down Volume Up Setup Return Figure 2-2 Button Name Function Setup Enter the OSD menu. Return Return to the previous page.

  • Page 15: Playing The Slideshow

    2. Copy image or video files to the Loop_Video folder. 3. Connect the SD card to the SQP110 series. 4. Turn on the SQP110 series. It will repeatedly play the files. Note: 1. Ensure not to store the Loop_Video folder and the Scenario folder in the SD card.

  • Page 16: Chapter 3 System Setup

    Chapter 3 System Setup Before playing media files on the SQP110 series, you can set up the system preferences, the display effects and the date and time using the on-screen display (OSD) menus. To enter the OSD menu, press the Setup touch button on the main screen or press the Setup button (No.10, Figure 1-3) on the IR remote control.

  • Page 17: Setting The System Preferences

    System Setup 3.1 Setting the System Preferences To set the system preferences, enter the OSD menu and select Setup. Figure 3-2 Language: Select English, French, German, Japanese or Traditional Chinese to be the system language. Contrast: Select the display’s contrast ratio. Default Setting: Restore the default settings.

  • Page 18: Setting The Display Effect

    3.2 Setting the Display Effect To set the slideshow display effect, enter the OSD menu and select Slideshow. Figure 3-3 Interval Time: Select the interval time of each slideshow page from 1, 3, 5, 10, and 30 seconds. Transition Effect: Select the transition effect of the slideshow from the following 13 options: Top down, Bottom up, Horizontal close, Horizontal open, Left to right, Right to left, Vertical close, Vertical open, Blind (left to right), Blind (top to down), Box in, and Fade out and in or Random.

  • Page 19: Setting The Network

    Figure 3-4 Setup IP Address: Select Automatically to obtain a dynamic IP from the DHCP Server or Manually to enter an IP address, subnet mask and gateway of the SQP110 series. IP Information: Display the IP address of the SQP110 series.

  • Page 20: Setting The Clock And The Display Schedule

    3.4 Setting the Clock and the Display Schedule To set up the date and time, select the Clock button. Figure 3-5 Button Description The Calendar The Clock Time for the device to turn on and start playing the media files. After you specify the On/Off time, select On to enable this schedule.

  • Page 21: Copying Files From The Usb Storage Device

    Copy All File, Copy Scenario, Copy Loop_Video, Copy Upgrade, Copy Opening, or Copy Schedule. 4. The SQP110 series will restart automatically when the file transfer is complete. After that, the files will be replaced. Note: For the descriptions of each necessary folder, see Appendix B. Definitions of Folder...

  • Page 22: Upgrading The Firmware

    3. Enter the Setup menu, select Firmware Upgrade, and then select USB or SD storage that stores the firmware file. 4. Click OK. The firmware upgrade runs automatically, and the SQP110 series will restart after the firmware upgrade is complete.

  • Page 23: Customizing The Initial Screen

    Copy the home.jpg file to the 855P_Opening folder. Connect the SD card to the SQP110 series. Turn on the SQP110 series and wait for about 30 seconds. The SQP110 series is now replacing the initial screen image. Restart the SQP110 series. The new image appears on the initial screen.

  • Page 24: Chapter 4 Clip Design

    Chapter 4 Clip Design The Clip Design software allows you to create an interactive slideshow by adding various of command buttons on the slideshow pages. When you click the command button, it will set off an action, such as jumping to a specific page, generating an inset window, inserting a video, and creating a QR code.

  • Page 25: Installing The Clip Design

    Clip Design 4.1 Installing the Clip Design To install the Clip Design software to your computer: 1. Insert the Software CD to your computer. It runs automatically and a window pops up. Figure 4-1 2. Select Install DirectX 9.0c and follow the on-screen instructions. 3.

  • Page 26: The Main Screen

    4.2 The Main Screen Start the Clip Design program. You are prompted to select the preferred language between the English, Traditional Chinese, French, German, and Japanese. After language selection, the main screen will appear. Figure 4-3 No. Name Function Menu bar See The Menu Bar later in this chapter.
  • Page 27 Clip Design Type figures in the dimension description box to modify Object Type the size and the location of the command buttons. Select Layout to see the background image of a page, and to Layout Window add the command buttons on it. Preview Window Select Preview to view the setting result.

  • Page 28: Creating An Interactive Slideshow

    4.3 Creating an Interactive Slideshow In addition to create an ordinary slideshow made of images and videos, you can make the slideshow interactive by adding the following command buttons on each page. Jump Button: Jump from one page to a specific page in a slideshow. Media Button: Generate an inset window on a page to display different types of information.
  • Page 29 Figure 4-3). This dialog box appears. Figure 4-6 Note: The SQP110 series supports image format of JPEG or PNG with the resolution of 800 × 480. To display the best image quality, ensure the image you select is subject to the resolution.

  • Page 30: Jumping From One Page To A Specific Page

    4.3.2 Jumping from One Page to a Specific Page After you create a new page, you can add a Jump Button on the page to make it link to a specific page of the slideshow. 1. Select a slideshow page. 2.
  • Page 31 Note: With the Clip Design software, you can focus on the Button image by moving the mouse to the Jump Button on the main screen. With the SQP110 series, you can focus on the Button image by pressing the Jump Button on the screen or selecting the Jump Button with the IR remote control.
  • Page 32 Image (When focus) User Control: Select this option to define the Button image in the focused status. Click Set to select an image from the files. The image will be the Button image when it is in the focus status. Image Map: Select this option to frame the Jump Button on the unaltered background image when the Jump Button is in the focus status.
  • Page 33 Clip Design 1. After the settings, a Jump Button is created on the background page as shown below. Figure 4-14 2. To modify the location and the size of the Button, drag the Jump Button to the desired location on the page, and drag four corners and the sides of the Button to enlarge or narrow the button size.

  • Page 34: Generating An Inset Window On A Page

    4.3.3 Generating an Inset Window on a Page To generate an inset window on a page, you can add a Media Button. After the settings, an inset window will appear on the page for you to display additional information. Note: You can add multiple Media Buttons on one page, but there will be only one inset window.
  • Page 35 Clip Design 6. Click OK. A Media Button and a Media Monitor, which is used as the inset window, are created on the page as shown below. Figure 4-16 7. To modify the location and the size of the Media Button and the Media Monitor, drag the Button to the desired location on the page, and drag four corners and the sides of the Button to enlarge or narrow the button size.

  • Page 36: Inserting A Video On A Page

    4.3.4 Inserting a Video on a Page You can create a Video Button on a page to display video. Note: The SQP110 series supports multiple video codec. 1. Select a slideshow page. 2. Click the Add Object icon , select Button in the Object Type section and select Video in the Button Type section.
  • Page 37 Clip Design 6. Click OK. A Video Button is created on the page as shown blow. Figure 4-19 7. To modify the location and the size of the Video Button, drag the Video Button to the desired location on the page, and drag four corners and the sides of the Button to enlarge or narrow the button size.

  • Page 38: Generating A Qr Code On A Page

    4.3.5 Generating a QR Code on a Page You can generate a QR code on the page. Users can access the text content by scanning the QR code with a compatible mobile phone. Note: 1. The QR (Quick Response) code is a matrix code that allows its contents to be decoded at high speed.
  • Page 39 Clip Design 4. Type the information in the Text box. The text is required to be within 60 characters. 5. Click Setting to specify the color of the QR code. 6. Specify Scale from 1 to 9 to define the size of the QR code. 7.

  • Page 40: Creating A Ticker On A Page

    4.3.6 Creating a Ticker on a Page You can add a horizontal scrolling Ticker on the page to present additional information, such as a website or the latest news. Note: 1. The maximum number of the characters for the Ticker text is 200. 2.
  • Page 41 Clip Design Click OK. A ticker is created on the page as shown below. Figure 4-27 To modify the location and the size of the Ticker, drag the Ticker to the desired location on the page, and drag four corners and the sides of the Button to enlarge or narrow the button size.

  • Page 42: Verifying The Slideshow With The Flowchart

    4.3.7 Verifying the Slideshow with the Flowchart When creating an interactive slideshow, you can arrange the slideshow to display in the desired order by adding the Jump Buttons. The Flowchart can be used as a reference for slideshow order management. It allows you to verify page by page if the result is as your wish, and if each slideshow page is correctly connected to its previous page and its next page.

  • Page 43: Playing The Interactive Slideshow On Sqp110 Series

    Figure 4-31 Store the folder to a SD card. Connect the SD card to the SQP110 series. It will automatically play the slideshow. Note: The SQP 110 series can basically play an interactive slideshow at a time. So, ensure to store only one Scenario folder in the SD card for the SQP 110 series to play. To play multiple interactive slideshows, it is required to program the content schedule with the Schedule software.

  • Page 44: Customizing The Screen Saver For Sqp110 Series

    4.5 Customizing the Screen Saver for SQP110 Series When you play the interactive slideshow on the SQP 110 Series, the Clip Design software allows you to enable the Screen Saver function with the default screen saver, or to design your own screen saver.
  • Page 45 Clip Design Mode 2: Jump root page: Specify the idle time in second(s) before the slideshow jumps to the first page. Play Video: Specify the idle time in second(s) before the screen saver is activated. After the settings, the slideshow will jump to the first page after the first idle time you set.

  • Page 46: Chapter 5 Content Schedule

    Chapter 5 Content Schedule The Schedule software allows you to create a weekly schedule to automatically start up SQP110 series and present media content at a specific date and time. 5.1 Installing the Schedule Insert the Software CD to your computer. It runs automatically and a window pops up.

  • Page 47: Setting The Content Schedule

    Power On and Power Off settings. Figure 5-3 To create the first content schedule, specify the time for the SQP110 series to automatically turn on and turn off in the Power On and Power Off drop-down lists.
  • Page 48 Click the Setting 1 button to set up the first schedule. This dialog box appears. Figure 5-5 Specify the date to play the media files in the Start Date and End Date drop-down lists. Figure 5-6 Specify the day(s) to play the media files. Figure 5-7...
  • Page 49 Content Schedule To exclude certain dates from the schedule, select the dates from the drop-down list, and click Add. Figure 5-8 Click OK. This calendar appears and the scheduled dates are displayed in black color. Figure 5-9...
  • Page 50 Double-click any of the scheduled dates in black. This setup box appears. You can further specify a period of time in a day to play the media files. Figure 5-10 Click any time column. This dialog box appears. You can specify the type of media files and time to play.
  • Page 51 Content Schedule 10. Select Scenario to play the interactive slideshow created using the Clip Design, or Loop_Video to play some image and/or video files. If you select Scenario: Click the button to locate the Scenario folder, select SQP110.NOE, and click Open.
  • Page 52 12. Click OK in the following dialog box to apply the time settings to the selected date. Figure 5-13 13. Repeat steps 2 to 12 to set up the second and the third content schedules, if necessary. If the three content schedules are created, they can be distinguished by color: the first scheduled dates are black, the second ones are light blue and the third ones are dark blue, as shown below.
  • Page 53 Loop_Video folder first and then include the Loop_Video folder in the SD card too. 17. Connect the SD card to the SQP110 series. It will automatically play the media files according to the schedule.

  • Page 54: Chapter 6 Cms Lite

    Chapter 6 CMS Lite The CMS Lite is Content Management System, allowing you to remotely upload media files or firmware to multiple SQP110 series. Figure 6-1 Note: For information on PN300 and SQP133, refer to PN300 & SQP133 User’s Manual.

  • Page 55: Additional System Requirements

    CMS Lite 6.1 Additional System Requirements To connect the SQP110 series to the CMS Lite, an additional USB to RJ-45 cable is required. The CMS Lite supports 50 units of SQP110 series for free. If you want to connect more SQP110 series to the CMS Lite, an additional dongle is required.
  • Page 56 USB drivers for dongle; otherwise the additional number of connections will not be applied. 1. Insert the Software CD to your computer. It runs automatically and a window pops up. Figure 6-2 2. Select Install GeoVision USB Devices Driver and follow the on-screen instructions.

  • Page 57: Installing The Cms Lite

    CMS Lite 6.2 Installing the CMS Lite To install the CMS Lite, follow the steps below. 1. Insert the Software CD to your computer. It runs automatically and a window pops up. Figure 6-3 2. Select Install Content Management System and then select Install CMS Lite (Only for PN300 &...

  • Page 58: Connecting Sqp110 Series To The Cms

    6.3 Connecting SQP110 Series to the CMS To connect the SQP110 series to the CMS Lite, you have to set up the network settings. 1. Use the USB to RJ-45 cable, connect the SQP110 series to the network. 2. Enter the OSD menu of the SQP110 series and then select Network Setup.
  • Page 59 CMS Lite When the CMS Lite is started, the SQP110 series will be connected to the CMS Lite automatically, the connection information will be listed. Figure 6-6...

  • Page 60: The Main Screen

    Upload the content schedule to the SQP110 series. See 6.7 Upload Schedule Uploading the Schedule. Upload firmware to the SQP110 series. See 6.8 Uploading Upload Firmware the Firmware. Cacel Uploading Cancel the process of uploading. Edit Device Information Change the device name of the SQP110 series. See 6.9...
  • Page 61 Reboot Reboot the SQP110 series. Reload Refresh the information. Display the information of the connected SQP110 series, including device type, device name, IP address, MAC Information address, status, last update time, transfer status, file name, transfer speed, free space, resolution and firmware version.

  • Page 62: Uploading Video And Image Files

    (Loop_Video, Scenario and Schedule) will be removed from the SD card on the SQP110 series. After that, the CMS Lite will reconnect to the SQP110 series again, and the SQP110 will automatically play the uploaded video or image files.

  • Page 63: Uploading The Scenario

    (Loop_Video, Scenario and Schedule) will be removed from the SD card on the SQP110 series. After that, the CMS Lite will reconnect to the SQP110 series again, and the SQP110 will automatically play the uploaded interactive slideshows.

  • Page 64: Uploading The Schedule

    Important: The upload action will remove all the Loop_Video, Scenario and Schedule folders from the SD card. 1. On the CMS Lite, select the desired SQP110 series and click the Upload Schedule button Figure 6-10 2. Type a name in the Package Name field for the uploading folder.

  • Page 65: Uploading The Firmware

    CMS Lite 6.8 Uploading the Firmware To upload the firmware to the SQP110 series, follow the steps below. 1. On the CMS Lite, select the desired SQP110 series and click the Upload Firmware button to locate the firmware file (.tar).

  • Page 66: Changing The Device Name

    2. Type a name for the SQP110 series. 3. Click OK. The CMS Lite will disconnect and then reconnect to the SQP110 series automatically. Note: You can find the device name in the OSD menu of the SQP110 series. See 3.3 Setting the Network.

  • Page 67: Chapter 7 Cms Server

    CMS Server Chapter 7 CMS Server CMS Server is a Content Management System server that allows you to upload media files, or firmware to up to 1000 digital signage devices using a Web interface. You can also look up records and analysis of user and device activities. TCP / IP PN 300 SQP133...

  • Page 68: System Requirements

    7.1 System Requirements The system requirements for CMS Server are listed below. 7.1.1 Minimum System Requirements 500 Devices or Below 500 Devices or Above 32-bit and 64-bit Windows 7 / XP / Vista / Server 2008 Core Duo, 2.6 GHz Core Duo, 3.0 GHz Memory 1 GB...
  • Page 69 Note: Before starting CMS Server, make sure you have inserted the dongle to the computer and installed the USB drivers for dongle. 1. Insert the Software CD to your computer. It runs automatically and a window pops up. Figure 7-2 2. Select Install GeoVision USB Devices Driver and follow the on-screen instructions.

  • Page 70: Installing Cms Server

    7.2 Installing CMS Server To install CMS Server, follow the steps below. 1. Insert the Software CD to your computer. It runs automatically and a window pops up. 2. Select Install Content Management System, select Install CMS Server (Only for PN300 &...

  • Page 71: Connecting The Devices To Cms Server

    CMS Server 7.3 Connecting the Devices to CMS Server To connect the device to CMS Server, you have to set up the CMS settings. Make sure the device is already connected to the network. See 3.6 Setting the Network for more details. 1.

  • Page 72: Starting Cms Server

    7.4 Starting CMS Server After installing CMS Server, the CMS Server icon will appear in the system tray. Follow the steps below to configure general settings and access the Web interface of CMS Server. 1. To configure the general settings, right-click the CMS Server icon , click Stop Service, and click Configure to access the following options.
  • Page 73 Note: 1. To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one-time installation of GeoVision’s ActiveX component onto your computer. 2. If CMS Server is installed behind a firewall or router, you may need to open these default...
  • Page 74 List of Menu Options After logging in the Web interface, the following menu options are available in the left panel. Refer to the section number below to see more details on each menu option. 7.6.1 Device Information 7.6.2 System Information 7.6 Information 7.6.3 User Information 7.6.4 Package Information...

  • Page 75: Getting Started

    Download Tools button and select Download Content Design Tool for PN300 / SQP133 or Download Clip Design Tool for SQP110. To create a scenario, see Content Designer in PN300 User’s Manual or see Clip Design in SQP110 Series User’s Manual. •...

  • Page 76: Transferring The Package

    7.5.2 Transferring the Package Before uploading the content package to the device, you need to first transfer the content package to the designated storage path on the computer. 1. In the Server Setting section, click Package Management. This page appears. Figure 7-9 2.
  • Page 77 CMS Server Note: Schedule files must be zipped and the Schedule option is only available when Compressed is selected in step 2. 5. Click the Browse button to locate the file(s) for the package. You can press the Ctrl and Shift key to select multiple files in the dialog box.

  • Page 78: Uploading The Package

    Figure 7-12 4. Select a package and click Upload Package. The package is now uploaded and will replace any existing packages. Note: SQP110 series will reboot after the package is uploaded.

  • Page 79: Applying The Scrolling Ticker

    Figure 7-13 To disable strolling ticker, click the Stop Strolling Ticker button in the Device Setup page. Note: Scrolling Ticker is not supported on SQP110 series.

  • Page 80: Information

    7.6 Information This section introduces how to look up device information, system information, user information and package information. 7.6.1 Device Information The Device Information page shows device details such as device name, IP address, the package being played and connection status. After logging in CMS Server, the Device Information page is displayed by default and can later on be accessed by clicking the Device Information tab labeled in red.

  • Page 81: User Information

    CMS Server 7.6.3 User Information The User Information page shows the user accounts created, the password hint and the email address associated with the account. Figure 7-16 7.6.4 Package Information The Package Information page shows the name, type, size, version, owner and upload time of the content packages stored.

  • Page 82: Device Setup

    7.7 Device Setup The device setup page allows you to see the devices available, connect to devices, upload content to devices and apply scrolling ticker. After you connect the device to CMS server, the device will be listed as Invalid in the device list as shown below. Figure 7-18 To add the invalid device, double-click the device name.
  • Page 83 CMS Server Note: Scrolling Ticker is not supported on SQP110 series. If you upload a package or firmware to a device that is not connected, the command will be stored in the Command List until the device is connected. The Command List can be accessed by double-clicking the IP address of the device.

  • Page 84: Event Query

    7.8 Event Query In the Event Query section, you can look up record of user activities and device activities. 7.8.1 Behavior Log Query Using the Behavior Log Query, you can search user activities such as login, adding packages, adding devices and applying scrolling ticker. Figure 7-21 1.

  • Page 85: Behavior Log Analysis

    CMS Server 7.8.2 Behavior Log Analysis Using the Behavior Log Query, you can see user activities displayed in bar graph, pie graph or line graph. Figure 7-22 1. Use the Event Type drop-down list to select the type of event to search or click Select All. 2.

  • Page 86: Device Event Query

    7.8.3 Device Event Query Using the Device Event Query, you can search device events such as connection to devices and uploading packages to devices. Figure 7-23 1. Use the Event Type drop-down list to select the type of event to search. 2.

  • Page 87: Device Event Analysis (Counts)

    CMS Server 7.8.4 Device Event Analysis (Counts) Using the Device Event Analysis (Counts), you can see the number of connections made to devices and the number of packages uploaded in bar graph, pie graph or line graph. Figure 7-24 1. Use the Event Type drop-down list to select the type of event to search or click Select All. 2.

  • Page 88: Device Event Analysis (Elapsed Time)

    7.8.5 Device Event Analysis (Elapsed Time) Using the Device Event Analysis (Elapsed Time), you can see the total connection time and package upload time for each device in bar graph, pie graph or line graph. Figure 7-25 1. Use the Event Type drop-down list to select the type of event. Select Login to see the total connection time of each device or select Upload Package to see the total package upload time of each device.

  • Page 89: Server Setting

    CMS Server 7.9 Server Setting In the Server Setting section, you can create user accounts, configure network settings, set up mail server for password retrieval and manage packages. 7.9.1 User Account You can create administrator accounts to access CMS Server. Figure 7-26 Click the Add button.

  • Page 90: Network Setting

    7.9.2 Network Setting In the Network Setting page, you can configure basic network settings as well as set up SSL protocol and Dynamic DNS. Figure 7-28 [Setup] HTTP Port: The default HTTP port is 80. SSL: Enable the Secure Sockets Layer (SSL) protocol for a more secure Internet connection.

  • Page 91: Email Service

    Server when using a dynamic IP address. Enable: Select to enable DDNS. Service Provider: Click the link on the right to register a GeoVision DDNS Server. User Name: Type the username used to enable the service from the DDNS. Password: Type the password used to enable the service from the DDNS.
  • Page 92 [SMTP] SMTP Server: Type your SMTP Server’s URL address or IP address. Port: The default port for most SMTP servers is 25. However webmail Yahoo and Hotmail generally use different SMTP port. In this case, check your e-mail provider for the SMTP port number.

  • Page 93: Package Management

    CMS Server 7.9.4 Package Management Before uploading video or image to the device, you need to transfer the content to the specified storage location in the Package Management page. Figure 7-30 Add Package: Adds packages to the specified storage location. Refer to 7.5.2 Transferring the Package for more details.

  • Page 94: Upgrading The Firmware

    7.10 Upgrading the Firmware To upload firmware to the device, follow the steps below. In the left menu, select Package Management and click the Add Firmware button. Select Compressed if the firmware is zipped or click Uncompressed for unzipped files. This dialog box appears.

  • Page 95: Chapter 8 Dynamic Dns

    Dynamic DNS Chapter 8 Dynamic DNS Dynamic DNS (Domain Name System) provides a convenient way of accessing the CMS Lite when using a dynamic IP address. Dynamic DNS can direct the changing IP address of the CMS Lite to a same domain name, so that you don’t need to go through the trouble of checking if the IP address assigned by the DHCP server or ISP has changed.

  • Page 96: Registering Domain Name

    8.2 Registering Domain Name 1. Start the DNS Client, and click Register. Figure 8-2 2. The Register page of Dynamic DNS Server appears. Figure 8-3...
  • Page 97 Dynamic DNS 3. Type a username. The username can be up to 16 characters. The username accepts “a ~ z”, “0~9”, and “-“, but does not accept space or “-“ as the first character. 4. Type a password. The password is case-sensitive and must be at least 6 characters. Re-type the password for confirmation.

  • Page 98: Starting Dynamic Dns

    8.3 Starting Dynamic DNS After registering a domain name with DDNS service, you can now enable the DDNS function. Figure 8-5 1. Run the DNS Client. 2. Type the Username and Password used to enable the service from the Dynamic DNS server.

  • Page 99: Specifications

    Specifications Specifications Model SQP110 series 11” touch (SQP110T) Panel Size (inch) 11” non-touch (SQP110P) Aspect Ratio 16 : 10 Pixel Pitch (mm) 0.1 x 0.3 Video Format Multimedia support Audio Format Multimedia support Photo Format JPEG, PNG Color 262 K...

  • Page 100: Appendix

    The demonstration examples are the interactive slideshows created by the Clip Design software. To play those slideshows on the SQP110 series, follow the steps below: Insert the Software CD to your computer. It runs automatically and a window pops up.
  • Page 101 GeoVision website, and the Loop_Video folder, which contains the video files used as the screen saver. Store these two folders in a SD card, and connect the SD card to the SQP110 series. The SQP110 series will automatically play the demonstration example.

  • Page 102: Definitions Of Folder Names

    Clip Design software. The folder name should be the same Scenario as the Scenario name. See 4.4 Playing the Interactive Slideshow on SQP110 Series. The folder stores the schedule setting files created by the Schedule Schedule software. See Chapter 5 Content Schedule.

  • Page 103: Warranty Policy

    Products purchased via authorized distribution and sales channels. If a defect arises and a valid claim is received by GeoVision within Limited Warranties Period, at its option, GeoVision will (1) repair Products at no charge, using new or refurbished...
  • Page 104 Limited Warranties apply only to Products manufactured by or for GeoVision that can be identified by the "iDi Signage" or "GeoVision" trademark, trade name, or logo affixed to them. Limited Warranties do not apply to any non-iDi Signage and non-GeoVision products including counterfeited products.
  • Page 105 Regardless whether any remedy set forth herein fails of its essential purpose or otherwise, in no event will GeoVision, iDi Signage or its suppliers be liable for any lost revenue, profit or lost or damaged data, business interruption, loss of capital, or for special, indirect, consequential,...
