ENPHASE QUICKSTART GUIDE
4 Easy Steps
1 2
1 2
BROADBAND ROUTER
LAN CABLE
980000000366-B 980000000364-B
980000000364-B 980000000362-B 980000000367-B
REGISTER
1
Installers: Begin the activation process
• Log in to: enlighten.enphaseenergy.com/register and complete the form.
• First-time installers: Go to enlighten.enphaseenergy.com/register and complete
the form. Your login credentials will be sent to you.
• Self-installers: Click on the "Self-installed" checkbox.
• Existing installers: Log into Enlighten, click "Activations" and then "Add New System"
(If you are not sure your company is registered, contact Enphase support to find out)
For guidance on how to use the Array Builder, please visit
www.enphaseenergy.com/learningcenter
3
INSTALL
2
3
Install the PV modules and microinverters
Consult the microinverter installation guide for more details.
CONNECT
3
Install the Envoy Communications Gateway
• Connect to a broadband router and plug into a dedicated wall outlet.
• Wait 15 minutes to allow the Envoy to scan all the microinverters in your array.
• Ensure at least 2 level bars and the correct number of microinverters are showing
(see overleaf for troubleshooting).
05:00
LEVEL
ASSIGN
4
Use the Array Builder to generate the array
Once all microinverters have been detected, log in to Enlighten to
use the Enlighten Array Builder.
support@enphaseenergy.com
1 877 797 4743
+WEB
Devices: 15
Solar PV power systems should be
installed by qualified personnel.
