Summary of Contents for Element 8085
- Page 1 HI-DEFINITION A/V ROUTING SYSTEM Version 1.0 Please read this user manual carefully before using this product. Failure to understand operation procedures may result in injury.
-
Page 2: Table Of Contents
Contents Brief Introduction Product Features Technical Speci cations Packing List Structure Installation and Use Meanings Of Indicator Statuses Speci cations FAQs FCC Information Back cover... -
Page 3: Brief Introduction
Brief Introduction Thank you for choosing our ELEMENT8085 high-de nition (HD) wireless audio/video (AV) transmission system devices. The device can be wirelessly connected from an HD source device to an HD display device such as TV, projector, HD disc player, game machine, recorder, and set-top-box at home. -
Page 4: Technical Speci Cations
Technical Speci cations 1080p, 1080i, 720p, 576p,480p PC: VGA(640X480), SVGA(800X600), Video formats supported XGA(1024X768), SXGA(1280X1024) Audio formats supported PCM,DTS, DOCBY DIGITAL RF communication system MIMO Modulation mode OFDM Maximum transmission power 12dBm Image transmission distance Image delay <1 ms Transmission/receiving Built-in antenna mode Operating frequency... -
Page 5: Packing List
Packing List HD wireless video HD wireless video Base x 2 transmitter x 1 receiver x 1 IR remote extension Power supply x 2 connector x 1 Structure Transmitter Power Input Port This port is connected to the 5V/2A power adapter which is 5.5mm in diameter and positive outside and nega tive inside. - Page 6 HDMI Input Port This port is connected to a video cable supporting the HDMI1.3 protocol. Output Interface for IR Remote Signals This interface is connected to an IR extension cable for extending the IR remote receiving function. Wireless Network Status Indica If this indicator turns green after the power supply is connected, it indicates that wireless network connection is made successfully;...
- Page 7 Power Input Port This port is connected to the 5V/2A power adapter which is 5.5mm in diameter and positive outside and negative inside. HDMI input port This port is connected to a video cable supporting the HDMI1.3 protocol. Output Interface for IR Remote Signals This interface is connected to an IR extension cable for extending the IR remote receiving function.
-
Page 8: Installation And Use
Installation and Use * It is recommended to place a transmitter and a receiver verticall or horizontally at the same time during installation. If the transmitter and the receiver are placed across each other, for example the transmitter is put vertically and the receiver is placed horizontally, the image transmission distance may be a ected. - Page 9 DVD player POO3 Set-top-box Game machine * Any video source with the HDMI video output interface can be connected. 4. Connect the IR remote extension connector to the IR remote signal output hole of the transmitter. Installation and Use for Receiver 1.
- Page 10 * The transmission distance between the transmitter and the receiver is 30 meters at most. If signals are obtained by penetrating a wall, the transmission distance and may be a ected. 2. The wireless network status indicator is ON after the receiver power supply is connected and wireless network connection is made successfully.
-
Page 11: Meanings Of Indicator Statuses
Meanings of Indicator Statuses Working status Indicator Indicator status Green on The transmitter is connected Wireless connection successfully in the wireless mode status indicator The transmitter fails to be ( t r a n s m i t t e r ) connected in the wireless mode Flash rapidly The device is abnormal... -
Page 12: Specifications
SPECIFICATIONS Transmission Frequency 5.1~5.9GHz Frequency Stability 4PPM Bandwidth 40MHz Transmission Power 12dBm Receiving Sensitivity -75dBm System Latency Sending/receiving channel 4 channels for sending/1channel for receiving HD video protocol HDMI 1.3 HD video encryption protocol HDCP 1.2 Unobstructed E ective Range Power Supply Consumption Current Dimensions (W x D x H) -
Page 13: Faqs
Trobleshooting Symptom Possible Reasons/Solutions It may take 15-30 seconds for initiation and connection Why no images aredisplayed after the transmitter and receiver are powered on. on TV afterthe transmitter and Please wait patiently. If no images appear after 1 minute, receiver are poweredon? check whether the connection between the transmitter and the player as well as the connection between the receiver... - Page 14 Why no signals are input to Please check whether the receiver is properly the TV? connected to the TV. In addition, adjust the input source of the TV to the HDMI interface connected to the receiver. Images appear on TVnormally but Please con rm whether the player is muted or no voice is output.
-
Page 15: Fcc Information
Why there are so many noises or Possibly the transmitter and receiver are too far mosaics on the image displayed away or there are many obstacles. Please adjust on TV? the position of both devices. In addition, to achieve better receiving e ect, it is recommended that you place both devices vertically. - Page 16 EU Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice.
