- Page 1 DiViS DVR – MPG Series Rev. 1.2 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. *All contents of this document may change without prior notice.
- Page 2 2-2. Accessories 3. Board Description 3-1. DiViS MPG12004 3-2. DiViS MPG24008 3-3. DiViS MPG48016 4. Installation 4-2. DiViS MPG12004 Installation 4-3. DiViS MPG24008 Installation 4-3-1. Pigtail type 4-3-2. Back panel type 4-4. DiViS MPG48016 Installation 4-4-1. Pigtail type 4-4-2. Back panel type 5.
- Page 3 DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, DiViS MPG12004, DiViS MPG24008, and DiViS MPG48016 board. The pictures and names of the products are subject to change depending on hardware upgrade.
- Page 4 Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
- Page 5 Network Support (PSTN, TCP/IP, LAN , Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. POS, Access Control, ATM Support Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images.
- Page 6 DiViS CHANCE-i USA Corp w w w . D V R . c o m 2. Products and Components 2.1 DiViS MPG Series Board DiViS MPG12004 DiViS MPG24008 DiViS MPG48016 (2 of MPG24008) 2.2 Accessories Video Pigtail Cable Audio Pigtail Cable...
-
Page 7: Board Description
DiViS CHANCE-i USA Corp w w w . D V R . c o m 3. Board Description 3-1. DiViS MPG12004 3-2. DiViS MPG24008 DiViS... - Page 8 DiViS CHANCE-i USA Corp w w w . D V R . c o m 3-3. DiViS MPG48016 Master Slave DiViS...
-
Page 9: Installation
CHANCE-i USA Corp w w w . D V R . c o m 4. Installation 4-1. DiViS MPG12004 1) Connect video pigtail cable to the port. 2) Connect audio pigtail cable to the port. 3) Sensor cable connects to Sensor port. - Page 10 DiViS CHANCE-i USA Corp w w w . D V R . c o m 4-2. DiViS MPG24008 4-2-1. Pigtail Type 1) Connect video pigtail cable to the port. 2) Connect audio pigtail cable to the port. 3) Sensor cable connects to Sensor port.
- Page 11 DiViS CHANCE-i USA Corp w w w . D V R . c o m 4-2-2. Back Panel Type 1) Back panel. 2) Sensor Cable. 3) When connect cable to back panel make sure to leave one pin from right end.
- Page 12 CHANCE-i USA Corp w w w . D V R . c o m 4-3. DiViS MPG48016 4-3-1. Pigtail Type 1) ~ 4) Connect video & audio pigtail cable to the port. 5) ~ 8) Sensor cables connect between Sensor boards and IO socket on the DVR boards.
- Page 13 DiViS CHANCE-i USA Corp w w w . D V R . c o m 4-3-2. Back Panel Type 1) Back panel. 2) Sensor Cable connects to the back panel. (right below video connection) 3) The other side of sensor cable connects to IO socket on the DVR board.
-
Page 14: Back Panel
DiViS CHANCE-i USA Corp w w w . D V R . c o m 5. Accessories 5-1. Back Panel Camera I/O Camera Ground 3, 5, ~ 31, 33 Camera Signal 4, 6, ~ 32, 34 TV Out Ground TV Out Signal Sensor &... - Page 15 Sensor port pin number 1 ~ 8: Signal input G: Ground 4, 3, 2, 1: Relay output Note: For MPG12004, signal input only available 1 ~ 4. For MPG48016, use 2 sensor boards. Refer to the connection diagram on section 4-3. DiViS...
- Page 16 DiViS CHANCE-i USA Corp w w w . D V R . c o m 5-5. RS232 to RS422/485 Converter * Use Rx+ and Rx- for RS 485 method. - TxData + TxData - RxData + RxData Signal 1) Connect to system’s Com port.
- Page 17 DiViS CHANCE-i USA Corp w w w . D V R . c o m 5-6. PORT Converter 5-6-1. Specification RS-232 from POS DB9 Female Input Parallel Port from POS DB25 Male RS-232 to Printer DB9 Male Serial RS-485(S) to DVR...
- Page 18 DiViS CHANCE-i USA Corp w w w . D V R . c o m 10, Terminal Block - TxData + TxData - RxData + RxData Signal 11, SW1, SW2: Used in output of Parallel port 12, SW3, SW4: Used in output of Serial 5-6-3.
