Ver. 1.0
XNET
(IGP1030)
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XNET IGP1030 and is the answer not in the manual?

Questions and answers

Summary of Contents for CBN XNET IGP1030

  • Page 1 Ver. 1.0 XNET (IGP1030) User Manual...

  • Page 2: About This Manual

    XNET User Manual About this Manual A compatibility and durability test ensures this product’s high performance. This manual is for XNET Network product users only, and it describes operations related to XNET Network products. Please read this manual thoroughly paying attention to cautions and warnings before using the product even if you have used similar products before.

  • Page 3: Table Of Contents

    XNET User Manual Index 1. System Administration ....................4 1.1. Logging On ..........................4 1.1.1. Using Internet Explorer ....................... 4 1.1.2. ID and Password ......................... 4 1.2. Configuring Camera ....................... 6 1.3. Web Viewer (Index.html) ......................8 1.4. Status Window ........................10 1.5.

  • Page 4: System Administration

    XNET User Manual 1. System Administration You can log on as an administrator using either Internet browser or ‘CMS’ software. (This manual will describe about using Internet browser only.) Type the IP Address of the XNET product in the address bar and press enter. e.g.) : http://192.168.123.100 If the HTTP port has been changed from the default value, enter the new port as shown below:...
  • Page 5 XNET User Manual Figure 1-1 Log-in window The default user name and password is “root” and “admin” respectively. For security purpose, it is recommended to change the administrator’s id and password from their default values. Please be careful not to forget them or expose them to others.

  • Page 6: Configuring Camera

    XNET User Manual When you log in as an administrator, XNET’s Basic Setup page will appear as shown in Figure 1-2. Setup pages for different features can be accessed from this page. Access to each feature are controlled by different Figure 1-2 Basic Setup Page 6 / 53...
  • Page 7 XNET User Manual Basic Setup Page can be accessed from Operator group level and up. If you want to access Administrator level page in this user level, you need to log in as Administrator. Please refer to the following table for access authority: ●...

  • Page 8: Web Viewer (Index.html)

    XNET User Manual When you access an XNET product, Web Viewer page will appear automatically. Viewer area displays the video output from the camera, and menu bar contains taps that lead to each feature setting page. Figure 1-3 Web Viewer Page 8 / 53...
  • Page 9 XNET User Manual ITEM DESCRIPTION Captures the still image and displays on a pop-up window. Capture [Save to] c:₩xNetCapture Opens up Basic Setup Page. Setup page for each XNET feature can be opened from this Menu Setting screen. (Please refer to 1.4 for detail) Opens up PTZ page.

  • Page 10: Status Window

    XNET User Manual Status page displays XNET System’s Version and its Ethernet address. Click [▷ Status] button to open the page shown in Figure 1-4. Figure 1-4 Status Page (Internet Explorer 7.0) 10 / 53...

  • Page 11: Configuring Users

    XNET User Manual This can give or limit authority to users for controlling Video and other features of XNET system. Click [ ▷ Users] button to open the page shown in Figure 1-5. Figure 1-5 Users Configuration Page 11 / 53...
  • Page 12 XNET User Manual ITEM DESCRIPTION Displays list of registered users. User List "root" is the system’s administrator. "root" cannot be added or deleted. Only the password for “root” can be changed. This adds a new user. Select “[Add_User]” tap in User List Box. To add a new user, enter User name, Password, and User group then click Add button.

  • Page 13: Setting Date &Time

    XNET User Manual & & This page will change Date and Time of XNET system. Click [ ▷ Date & Time] to open the page shown in Figure 1-6. Figure 1-6 Date and Time Page 13 / 53...
  • Page 14 XNET User Manual ITEM DESCRIPTION Current Server Time Displays time of XNET system. Time Zone Selects Time Zone. <Default : GMT+09> Enable Daylight Enables/ Disables Daylight Saving time. Time Sets Date and Time of the Server. <Default : None> New Server Time [Synchronize with computer time] - Synchronizes time and date of Client PC to Server.

  • Page 15: Configuring Multi-Viewer

    XNET User Manual Up to 3 cameras connected to XNET’s network can be displayed as sub-cameras simultaneously in Multi-View page. Click [ ▷ Multi Viewer] to open the page shown in Figure 1-7. Figure 1-7 Multi-Viewer Configuration Page 15 / 53...
  • Page 16 XNET User Manual DESCRIPTION ITEM Enables viewing of 1st sub Channel Video from the IP address Enable 1st entered. This can only be enabled when IP Address, User Name, and Sub Channel Password is properly entered. Video <Default : Disable> 1st Sub- Channel Video 1st IP Address...

  • Page 17: Configuring Ptz

    XNET User Manual This configures XNET’s PTZ server information, Click [ ▷ PTZ Configuration] to open the page shown in Figure 1-8. Figure 1-8 PTZ Configuration page 17 / 53...
  • Page 18 XNET User Manual ITEM DESCRIPTION PTZ Protocol Uploads a Protocol to be used by the PTZ. Upload The uploaded file can be viewed in PTZ Protocol List. Configures PTZ Protocol. Select Protocol File from PTZ Protocol List and click Set button to PTZ Protocol activate the protocol.

  • Page 19: Maintaining Server Configurations

    XNET User Manual This page configures system parameters such as system restart, factory default settings, system upgrade, saving configurations, saving images, and other additional features. Click [ ▷ Maintain Server] to open the page shown in Figure 1-9. Figure 1-9 Server Maintenance Page 19 / 53...
  • Page 20 XNET User Manual ITEM DESCRIPTION Restart Restarts the system. It takes about 45 seconds. Maintain Resets all parameters except for TCP/IP settings. Restore Server This restore will be followed by a 45 seconds system reset. Resets all parameters to Facory Default setting. Default This will be followed by a 45 seconds system restart.

  • Page 21: Generating Log Report

    XNET User Manual Log report contains detailed information about XNET’s image, setup, and error. Click [ ▷ Log Report] button to open the page shown in Figure 1-10. Figure 1-10 Log Report Page 21 / 53...

  • Page 22: Settings Overview

    XNET User Manual ITEM DESCRIPTION System System Displays current configurations for XNet option pages. Settings Overview Loads up Log Message file stored in the xNet product. Load List Log Message file can be sorted with date and index. Click Load List button to view message list in the Listbox.

  • Page 23: Configuring Audio

    XNET User Manual Xnet’s Audio features can be configured in this page. Click [ ▷ Audio] button to open the page shown in Figure 1-11. Figure 1-11 Audio configuration Page 23 / 53...
  • Page 24 XNET User Manual ITEM DESCRIPTION Audio Enables or Disables Audio feature Enable audio Enable <Default : Disable> Select audio input source between Microphone and line. <Default : Microphone> Microphone input can be used when users send their voice over XNET Source system.

  • Page 25: Configuring Video

    XNET User Manual XNET’s Video features can be configured in this page. Click [ ▷ Video] button to open the page shown in Figure 1-12. Figure 1-12 Video Configuration Page 25 / 53...
  • Page 26 XNET User Manual DESCRIPTION ITEM Select a resolution of the video image. Selectable resolutions differ by models like the following: IGP1030 : CIF | VGA | XGA | SXGA <Default : VGA> Resolution IDP4000/IVP4000 : CIF | VGA <Default : VGA> IDP4030/IVP4030 : CIF | VGA | XGA | SXGA <Default : VGA>...

  • Page 27: Configuring Rtp/Rtsp

    XNET User Manual This is related to XNET’s DDNS server information. Click [ ▷ RTP/RTSP] to open the page shown in Figure 1-13. Figure 1-13 RTP/RTSP Page 27 / 53...
  • Page 28 XNET User Manual ITEM DESCRIPTION Enter RTSP Port of the Main Stream between 1 and 65535. RTSP Port RTSP The default is 554. Configuration Multiple-RTSP Enter RTSP Port of the Sub Stream between 1 and 65535. The Port default is 665. Enter RTP Start Port between 1024 and 65534.

  • Page 29: Configuring Camera Condition

    XNET User Manual This is related to camera features of the XNET products. Click Reset Camera Figure button in System Setup Menu₩Main Server₩ to initialize the Camera during its operation. Click [ ▷ Camera Condition] button to open the page shown in Figure 1-14. Figure 1-14 Camera Conditions Page 29 / 53...
  • Page 30 XNET User Manual ITEM DESCRIPTION Selects Video format at Video Out terminal between Video Format NTSC and PAL.<Default : Disable> Video Output Format Enable Video Turns the Video Out feature on or off. Output <Note: IGP1030, IxP4030 outputs video in VGA level or less. > Configures Video’s White Balance.

  • Page 31: Configuring The Network(Tcp/Ip) Parameters

    XNET User Manual This configures XNET’s network related parameters. Click [ ▷ TCP/IP] button to open the page shown in Figure 1-15. Figure 1-15 Network Setup Page 31 / 53...
  • Page 32 XNET User Manual ITEM DESCRIPTION Turns DHCP on or off. Check DHCP checkbox to get an IP address automatically from the network using DHCP protocol. Obtained IP address can be viewed by Enable DHCP IP Installer. (Note) If the network does not use DHCP server, the product will wait for server’s response for two minutes and restart with its previous IP address.

  • Page 33: Configuring Ip Filtering

    XNET User Manual This configures IP Filters for XNET product. Click [ ▷ IP Filtering] button to open the page shown in Figure 1-16. Figure 1-16 IP Filtering Page 33 / 53...
  • Page 34 XNET User Manual ITEM DESCRIPTION Filter IP Displays list of currently established IP Filters. Addresses Adds an IP address to filter out. Enter the IP Address to block and click add button to add it to IP Filtering listbox. The updated list can be viewed in IP Address Listbox. - Up to 20 IP addresses can be added.

  • Page 35: Configuring Http

    XNET User Manual This configures HTTP port to access XNET’s webpage. Click [ ▷ HTTP] button to open the page shown in Figure 1-17. Figure 1-17 HTTP Page 35 / 53...
  • Page 36 XNET User Manual ITEM DESCRIPTION Enter HTTP Port to access the webpage. HTTP Default port is 80, and any other port number has to be entered at HTTP port the end of the ip address when accessing. (e.g. When using HTTP Port 8080, enter http://192.168.123.100:8080) Save Applies and saves changes.

  • Page 37: Configuring Upnp/Dyndns/Bonjour

    XNET User Manual UPnP is a protocol for IP installer software. You can enable or disable this UPnP, and you can also use a Friendly Name. DynDNS configures XNET’s DDNS server information. Click [ ▷ UPnP/DynDNS] to open the page shown in Figure 1-18. Figure 1-18 UPnP/DynDNS Page 37 / 53...
  • Page 38 XNET User Manual DESCRIPTION ITEM Enables or disables UPnP. UpnP Enable UPnP When enabled, you can use IP Installer’s XNET Auto Search feature. Setting Friendly Name Enter UPnP’s Friendly Name. Enables or disables DynDNS. Enable DynDNS When enabled, you can automatically obtain a domain from DDNS server by simply registering the XNET product.

  • Page 39: Configuring Cms

    XNET User Manual This configures XNET’s CMS Server information. Click [ ▷ CMS] to open the page shown in Figure 1-19. Figure 1-19 CMS Page ITEM DESCRIPTION Enter CMS port number for communication with CMS between 1 and CMS port 65535.

  • Page 40: Configuring Event Type

    XNET User Manual This is related to XNET’s DDNS Server information. Click [ ▷ Event Types] to view page shown in Figure 1-20. Figure 1-20 Event Types Page 40 / 53...
  • Page 41 XNET User Manual ITEM DESCRIPTION Enables or disables event processing. <Default : Disable> <Note for IGP1030 users> When this is enabled in the SXGA Mode, the transmitted fame rate is Event Enable Enable Event reduced by up to 10 fps. When this is enabled in the XGA Mode, the transmitted fame rate is reduced by up to 6 fps.

  • Page 42: Configuring Sensor/Alarm

    XNET User Manual This is related to XNET’s DDNS server information. Click [ ▷ Sensor / Alarm] to open the page shown in Figure 1-21. Figure 1-21 Sensor / Alarm Page 42 / 53...
  • Page 43 XNET User Manual ITEM DESCRIPTION Sensor Selects the signal type for Alarm Input Port between Normally Close Signal Type Setting and Normally Open. Alarm Configures interval between repeating Alarm Out signals between Out Interval Setting 1 and 3 seconds. Save Applies and saves changes.

  • Page 44: Smtp Setup

    XNET User Manual This configures mailing out method of Alarm Images once ‘event’ occurred in the XNET system. Click [ ▷ SMTP] button to open the page shown in Figure 1-22. Figure 1-22 SMTP Page 44 / 53...
  • Page 45 XNET User Manual ITEM DESCRIPTION Turns Internal SMTP Server on or off. When this box is checked, Alarm Image gets mailed out through an Enable internal mail server. Mail Authentication cannot be used in this mode. Internal SMTP When this box is unchecked, Alarm Image gets mailed out through an Server external mail server.

  • Page 46: Configuring Ftp

    XNET User Manual This configures how the Alarm Images get sent out using FTP once ‘event’ occurred in the XNET system. Click [ ▷ FTP] button to open the page shown in Figure 1-23. Figure 1-23 FTP Page 46 / 53...
  • Page 47 XNET User Manual ITEM DESCRIPTION Enter the address of the FTP server to send Alarm Images to in the event processing. Name The client PC at that IP address has to run the FTP server in order to Server receive the Alarm Images. Enter the port number for the FTP server to send Alarm Images to in Port the event processing.

  • Page 48: Configuring And Operating Digital Ptz

    XNET User Manual This controls XNET IGP1030’s Digital PTZ. Click PTZ button in Operator mode to open the page shown in Figure 1-24. Figure 1-24 Digital PTZ page ITEM DESCRIPTION Digital This moves the viewable area within the active CCD region.

  • Page 49: Configuring And Operating Ptz

    XNET User Manual This controls XNET’s (IGP1030, INS2000 and IJB2000) PTZ movement. Click PTZ button in Operator mode to open the page shown in Figure 1-25. Figure 1-25 PTZ Page 49 / 53...
  • Page 50 XNET User Manual ITEM DESCRIPTION Direction Key Moves the view in the x and y direction. Wide Zooms Out Tele Zooms In Focuses Out Action Near Focuses in Push AF Automatically adjust the focus. Set Preset Saves the current position to the values in the Preset Edit box. Move Preset Moves the PTZ to the defined Preset position.

  • Page 51: Configuring Motion Detection Area

    XNET User Manual This defines areas that detect motion, and up to three different areas can be defined in each channel. Click Motion button in Operator mode to open the page shown in Figure 1-26. Figure 1-26 Motion Detection Page 51 / 53...
  • Page 52 XNET User Manual ITEM DESCRIPTION Displays currently defined Motion Detection area. Area When an area is selected from the list, its defined area gets displayed and highlighted in viewer window. Up to 3 motion detection area can be defined. Show selected area When this is checked, only the selected area gets displayed in viewer window.

  • Page 53: Configuring Multi View Option

    XNET User Manual This configures viewing of up to 4 different camera images simultaneously. Click button in Administrator mode to open the page shown in Figure 1-27. The video from the XNET product gets displayed on top left, and the rest display video signals coming from the IP addresses defined in the Multi-Viewer Setup page.
