Block Diagrams, Testpoint Overview, and Waveforms
6. Block Diagrams, Testpoint Overview, and Waveforms
6.1 Block Diagram for Logic circuit
42" SDv2
LOGIC CONTROL
LVDS
DATA_R
8Bits
DATA_G
8Bits
DATA_B
8Bits
DCLK
Vs ync
Hsync
Enable
42" SDv3
Display
DRIVER CIRCUIT & PANEL
Data
852× 480 Pixels
Driver
852× 3× 480 Cells
Timing
Scan
Timing
V5
Vset Vsc Ve V3.3
- V3.3 : Voltage for LOGIC Control
- V5 :
Voltage for COF driver
Voltage for FET driver
- Vdd :
- Va :
Voltage for address pulse
Voltage for sustain driver
- Vs :
Voltage for scan pulse
- Vsc :
Voltage for X ramppulse
- Ve :
- Vset : Voltage for Y ramppulse
S/SD/HD 3.1 PDP
Column Driver
Vdd
Va Vs
Reference
6. EN 27
