Summary of Contents for Audio 2000 AWM6014U
- Page 3 WARNING AND SAFETY INSTRUCTIONS ....... FEATURES ..............HANDLING PRECAUTIONS ..
- Page 6 UHF Band Frequencies Including One AEM6014U Headset Microphone, One AWX6014U Wireless Transmitter, and One AWR6014U Receiver One 3.5mm Mono Microphone Output on the AWR6014U One 3.5mm Mono Headphone Output on the AWR6014U Power ON/OFF Switch and Audio Level Control on the AWR6014U Power LED Indicator, AF LED Indicator, and RF LED Indicator on the AWR6014U One 3.5mm Microphone Input on the AWX6014U One Low Battery (LOW BATT) LED Indicator on the AWX6014U...
- Page 7 Cartridge 3 5mm Plug Cable 3ft Head-Band Support LOW BATT LOW BATT Low Battery LED Indicator MIC Headset Microphone Input Jack...
- Page 8 DC 4 5V OUTPUT VOLUME DC 4 5V DC 4 5V Input Jack AF Audio Signal LED Indicator OUTPUT Microphone Output Jack Output Volume Control (for Microphone)
-
Page 9: Output Connections
1 Headset Microphone Connection Connect the 3.5mm plug of the headset microphone to the MIC input jack on the AWX6014U transmitter. 3 5mm Plug LOW BATT 2 Headphone Connection Connect the 3.5mm plug of the headphones to the Headphone Output jack on the AWR6014U receiver. - Page 10 2 Install two AA batteries (not included) to the AWX6014U transmitter and the AWR6014U receiver respectively. Make sure that the polarities of the AA batteries are oriented as indicated in the battery compartment. Connect the AWR6014U receiver microphone output to the microphone input of a video recording device via the included 3.5mm audio cable.
- Page 13 AWR6014U SYSTEM AWR6014U TRANSMITTER Batteries AWR6014U RECEIVER ACCESSORIES AWR6014U Transmitter AWR6014U Receiver One Cable ( 3.5mm Stereo-3.5mm Mono) OWNER S MANUAL Headset Microphone AA Batteries Lanyards or DC 4.5V...
