BATTERY CHARGER

OWNER'S MANUAL
HIBERNATING BATTERY CHARGER
Part# 74018
12-16 Volt 5 Amp
----CAUTION----
READ THIS MANUAL CAREFULLY FOR
RULES OF SAFE OPERATION AND
PROPER USE OF THIS CHARGER
***SAVE THESE INSTRUCTIONS***
" CAUTION DO NOT USE WITH LITHIUM BATTERIES ! "
STANDARD FEATURES
♦ HIGH ENERGY RETURN, FAST CHARGING
♦ CONSTANT CURRENT FIRST STAGE
♦ DUAL VOLTAGE LIMIT (CYCLIC/ STANDBY)
♦ AUTOMATIC SAFETY OVERRIDE TIMER
♦ START DELAY ON BATTERY CONNECT
♦ SHORT AND REV. CONNECTION SHUTDOWN
♦RUGGED SCR PHASE CONTROL
♦MAINS ZERO-CROSSING BATTERY SENSING
For Technical Assistance, Call Moroso's Tech Line at
(203) 458-0542, 458-0546 8:30am – 5:00pm Eastern Time
MOROSO PERFORMANCE PRODUCTS, INC
•
80 CARTER DR
GUILFORD, CT 06437
Phone: (203) 453-6571
Rev.A
V i s i t U s A t w w w . m o r o s o . c o m
021708
•
Fax: (203) 453-6906
74018INST
BATTERY CHARGER
OWNER'S MANUAL
HIBERNATING BATTERY CHARGER
Part# 74018
12-16 Volt 5 Amp
----CAUTION----
READ THIS MANUAL CAREFULLY FOR
RULES OF SAFE OPERATION AND
PROPER USE OF THIS CHARGER
***SAVE THESE INSTRUCTIONS***
" CAUTION DO NOT USE WITH LITHIUM BATTERIES ! "
STANDARD FEATURES
♦ HIGH ENERGY RETURN, FAST CHARGING
♦ CONSTANT CURRENT FIRST STAGE
♦ DUAL VOLTAGE LIMIT (CYCLIC/ STANDBY)
♦ AUTOMATIC SAFETY OVERRIDE TIMER
♦ START DELAY ON BATTERY CONNECT
♦ SHORT AND REV. CONNECTION SHUTDOWN
♦RUGGED SCR PHASE CONTROL
♦MAINS ZERO-CROSSING BATTERY SENSING
For Technical Assistance, Call Moroso's Tech Line at
(203) 458-0542, 458-0546 8:30am – 5:00pm Eastern Time
MOROSO PERFORMANCE PRODUCTS, INC
•
80 CARTER DR
GUILFORD, CT 06437
Phone: (203) 453-6571
Rev.A
V i s i t U s A t w w w . m o r o s o . c o m
021708
•
Fax: (203) 453-6906
74018INST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 74018 and is the answer not in the manual?

Questions and answers

Related Manuals for Moroso 74018

Summary of Contents for Moroso 74018

  • Page 1: Battery Charger

    ♦RUGGED SCR PHASE CONTROL ♦MAINS ZERO-CROSSING BATTERY SENSING ♦MAINS ZERO-CROSSING BATTERY SENSING For Technical Assistance, Call Moroso’s Tech Line at For Technical Assistance, Call Moroso’s Tech Line at (203) 458-0542, 458-0546 8:30am – 5:00pm Eastern Time (203) 458-0542, 458-0546 8:30am – 5:00pm Eastern Time...
  • Page 2 Installation Instructions Cont. Page 2 of 14 Installation Instructions Cont. Page 2 of 14 HIBERNATING BATTERY CHARGER HIBERNATING BATTERY CHARGER 12 & 16 VOLT 12 & 16 VOLT SPECIFICATIONS SPECIFICATIONS POWER CHARGER POWER CHARGER MODEL EX 1216/4 MODEL EX 1216/4 INPUT: 117 Volts AC 60Hz, 110 VA 1Amps INPUT: 117 Volts AC 60Hz, 110 VA 1Amps OUTPUT: 12 or 16 Volts DC, 5 Amps...

  • Page 3: Important Safety Instructions

    Installation Instructions Cont. Page 3 of 14 Installation Instructions Cont. Page 3 of 14 IMPORTANT SAFETY IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS 1. SAVE THESE INSTRUCTIONS-- This manual contains 1. SAVE THESE INSTRUCTIONS-- This manual contains important safety and operating instructions. important safety and operating instructions. 2.

  • Page 4: Warning Risk Of Explosive Gases

    Installation Instructions Cont. Page 4 of 14 Installation Instructions Cont. Page 4 of 14 10. Do not operate charger if it has received a sharp blow, 10. Do not operate charger if it has received a sharp blow, been dropped or otherwise damaged in any way; return it to been dropped or otherwise damaged in any way;...

  • Page 5: Preparing To Charge

    Installation Instructions Cont. Page 5 of 14 Installation Instructions Cont. Page 5 of 14 6. Be extra cautious to reduce risk of dropping a metal tool onto 6. Be extra cautious to reduce risk of dropping a metal tool onto battery.

  • Page 6: Voltage Selector Switch

    Installation Instructions Cont. Page 6 of 14 Installation Instructions Cont. Page 6 of 14 VOLTAGE SELECTOR SWITCH VOLTAGE SELECTOR SWITCH WARNING The front panel switch has two settings, marked WARNING The front panel switch has two settings, marked 12V and 16V, with OFF in the center. 12V and 16V, with OFF in the center.

  • Page 7: Dc Connection Precautions

    Installation Instructions Cont. Page 7 of 14 Installation Instructions Cont. Page 7 of 14 DC CONNECTION PRECAUTIONS DC CONNECTION PRECAUTIONS 1. Connect and disconnect DC output only after removing AC 1. Connect and disconnect DC output only after removing AC cord from electric outlet.
  • Page 8 Installation Instructions Cont. Page 8 of 14 Installation Instructions Cont. Page 8 of 14 7. When disconnecting charger, turn switches to off, 7. When disconnecting charger, turn switches to off, disconnect AC cord, remove clip from vehicle chassis disconnect AC cord, remove clip from vehicle chassis and then remove clip from battery terminal.
  • Page 9 Installation Instructions Cont. Page 9 of 14 Installation Instructions Cont. Page 9 of 14 This battery charger is for use on a nominal 117 volt AC circuit This battery charger is for use on a nominal 117 volt AC circuit and has a grounded plug that looks like the plug illustrated in and has a grounded plug that looks like the plug illustrated in sketch (A).
  • Page 10 Installation Instructions Cont. Page 10 of 14 Installation Instructions Cont. Page 10 of 14 1. Disconnect vehicle battery cables. 1. Disconnect vehicle battery cables. 2. Connect charger to battery. Ensure correct polarity. - BLACK 2. Connect charger to battery. Ensure correct polarity. - BLACK lead to Negative (-) terminal and RED lead to Positive lead to Negative (-) terminal and RED lead to Positive (+) terminal.

  • Page 11: Troubleshooting Guide

    Installation Instructions Cont. Page 11 of 14 Installation Instructions Cont. Page 11 of 14 4. . NOTE : The length of time the charger remains in the 4. NOTE : The length of time the charger remains in the Yellow charging mode depends on the size and Yellow charging mode depends on the size and “Sate of Charge”...
  • Page 12 Installation Instructions Cont. Page 12 of 14 Installation Instructions Cont. Page 12 of 14 3. The Microprocessor Control can indicate a problem with the 3. The Microprocessor Control can indicate a problem with the battery. If the battery has not reached the First Stage of the battery.
  • Page 13 Installation Instructions Cont. Installation Instructions Cont. Page 13 of 17 Page 13 of 14 Installation Instructions Cont. Page 13 of 14 2. Two or more 12 volt batteries may be bank charged with 2. Two or more 12 volt batteries may be bank charged with (1) charger if they are connected in parallel as shown (1) charger if they are connected in parallel as shown .
  • Page 14 (1) return the product and sales receipt to Moroso Performance Products, at your own expense. to the above address so that it is received by Moroso no later your own expense. to the above address so that it is received by Moroso no later than ninety (90) days after the date it was purchased;...
