CXR DS-8124 Installation Manual

Adsl2+ ip dslam
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADSL2+ IP DSLAM
DS-8124
Release 1.2

Installation Guide

Aug. 2007 Release 1.2
Copyright © 2006 CXR Anderson Jacobson. All Rights Reserved.
This document contains information that is the property of CXR. This document may not
be copied, reproduced, reduced to any electronic medium or machine readable form, or
otherwise duplicated, and the information herein may not be used, disseminated or
otherwise disclosed, except with the prior written consent of CXR AJ.
CXR ANDERSON JACOBSON
Sales, Research & Development, Manufacturing :
Rue de l'Ornette - 28410 Abondant FRANCE
Tel: +33 237.62.88.00 – Fax: +33 237.62.88.01
WEB Site:
http://www.cxr.anderson-jacobson.com
Support:
support@cxr.fr
Tel: +33 237.62.88.04
Part Number : 8000 602 338 Indice: 02
Version .1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-8124 and is the answer not in the manual?

Questions and answers

Summary of Contents for CXR DS-8124

  • Page 1: Installation Guide

    Aug. 2007 Release 1.2 Copyright © 2006 CXR Anderson Jacobson. All Rights Reserved. This document contains information that is the property of CXR. This document may not be copied, reproduced, reduced to any electronic medium or machine readable form, or otherwise duplicated, and the information herein may not be used, disseminated or otherwise disclosed, except with the prior written consent of CXR AJ.

  • Page 2: Table Of Contents

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Table of Content INTRODUCTION ..........................4 ..............................5 EATURES SYSTEM APPLICATION ........................6 SYSTEM REQUIREMENT ........................ 7 LED D ............................7 EFINITION ..............................7 ARDWARE ........................... 8 OFTWARE EATURE INSTALLATION PROCEDURE...................... 10 ..........................10...
  • Page 3 Change History Document Description This document contains information that is the property of CXR. This document may not be copied, reproduced, reduced to any electronic medium or machine readable form, or otherwise duplicated, and the information herein may not be used, disseminated or otherwise disclosed, except with the prior written consent of CXR.

  • Page 4: Introduction

    DSL. The DS-8124 / DS-8124c Access system contains 24 ADSL2/2+ circuits to deliver high-speed data service over twisted copper pairs using industry standard Discrete Multi-Tone (DMT) line coding technology.

  • Page 5: Features

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Features • 24 ports ADSL2+ interface • Variety of GE uplink interface o RJ45 connector for 10/100/1000 Base-TX o SFP for 1000 Base-SX, LX, LHX and ZX • Intelligent L2 switch feature • Intelligent DSL interworking feature...

  • Page 6: System Application

    Release 1.2 2. System Application The following figures present the system application in the access network. DS-8124/DS-8124c provides video, voice and data service for different users, such as Hotels, SOHOs, residential users and enterprises. The end user can use DSL for Various applications such as Telecommuting, Video streaming, On-line game, IPTV, Distance learning, Telemedicine, Voice over IP and Video conferencing...etc.

  • Page 7: System Requirement

    1. One Ethernet interface (RJ45) support Full Duplex and Half Duplex transceiver function, conforms to IEEE 802.3 Auto-Negotiation standard and comply with IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet. (only in DS-8124) 2. One RS232 console interface (DB9) support Full Duplex, 1、2 stop bits and odd、...

  • Page 8: Software Feature

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Power Supply 1. 60Wt. (input 90~260 VAC(10%), 50~60Hz) 60Wt. (input –36~-72 VDC) Operating Requirement Temperature : -10ºC ~ 60ºC. Humidity : 10~90% (non-condensing). EMC/ESD Certification : FCC Part15 Class A. Safety Certification : UL60950 ADSL/ADSL2+ Interface ITU-T G.992.1 (G.dmt) [Annex A], ITU-T G.992.2 (G.lite) [Annex A]...
  • Page 9 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Remote software upgrade Remote file backup and restore...

  • Page 10: Installation Procedure

    Note that these devices can be installed on any suitably large flat surface or in a standard EIA 19-inch rack. Package Contents A DS-8124/DS-8124c ADSL2+ IP DSLAM A Bracket Mounting Kit containing two brackets and four screws for attaching the brackets to the DSLAM...

  • Page 11: Mounting

    Release 1.2 Mounting The DS-8124/DS-8124c may be mounted on any flat surface, such as a shelf, or in a rack. Before you start installing the access switch, make sure you can provide the right operating environment, including power requirements, sufficient physical space, and proximity to other network devices that are to be connected.

  • Page 12: Installing Optional Modules

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Installing Optional Modules Before mounting the switch, be sure you install any optional modules. If you have purchased an optional slide-in 1000BASE-T, SFP 1000BASE-X, install it now, and following the instructions below. To rack-mount devices: 1.
  • Page 13 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 DS-8124c Figure 4-1. Attaching the Brackets 4. Mount the device in the rack, using four rack-mounting screws.
  • Page 14 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 DS-8124...
  • Page 15 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 DS-8124c Figure 4-2. Installing the Switch in a Rack 3. If installing a single switch only, turn to “Powering On the Switch” at the end of this chapter. 4. If installing several devices, we recommend using one stack for the switch, and another for...

  • Page 16: Desktop Or Shelf Mounting

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Desktop or Shelf Mounting 1. Attach the four adhesive feet to the bottom of the first switch. DS-8124 DS-8124c...
  • Page 17 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Figure 4-3. Attaching the Adhesive Feet 2. Set the device on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow.

  • Page 18: Wall Mount Mounting

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Wall mount Mounting 1.Attach the four adhesive feet to the bottom of the first switch. DS-8124...
  • Page 19 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 DS-8124c Figure 4-4. Installing the Switch on a Wall 2. Set the device on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow.
  • Page 20 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 3. If installing a single switch only, go to “Powering On the Switch” at the end of this chapter. 4. If installing multiple switches, attach four adhesive feet to each one. Place each device...

  • Page 21: Proper Grounding ( Earth )

    Release 1.2 Proper grounding ( earth ) Proper Grounding is a very important part of the electrical installation for DS-8124 , if noise is present in the Electrical ground this noise can leak to the ADSL circuit through the Surge protectors and interfere with the proper operation of ADSL links.

  • Page 22: Installing An Sfp Transceiver

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Installing an SFP Transceiver DS-8124 DS-8124c...

  • Page 23: Connecting To The 1000Base-Tand 10/100Base-Tx Interface

    Category 5 cable is required; for 10BASE-TX, Category 3,4, or 5 cable can be used. The RJ-45 ports on the DS-8124/DS-8124c modules support automatic MDI/MDI-X operation, so you can use standard straight-through twisted-pair cables to connect to any other network device (PCs, servers, switches, routers, or hubs).

  • Page 24: Connecting Rj-21 Cables

    The EE lines from the splitter interface of DS-8124/DS-8124c are connected to the punch-down block that connects the phone lines that run up to the end users. If the DS-8124/DS-8124c is installed in a rack, it may be convenient to use a patch panel between the splitter interface and the punch-down block.
  • Page 25 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2...

  • Page 26: Console Management

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Console management 1. HyperTerminal setting 2. Bootloader startup If you not press any key in the below state, system will load the default startup sequence to do boot our system. U-Boot 1.1.3 (Jun 29 2006 - 16:38:55) BAS ver:1.00.07 U-Boot code: 00200000 ->...
  • Page 27 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Net: No ethernet found. Hit any key to stop autoboot: 3 RTC clock initial start !!! RTC clock initial end !!! Scanning JFFS2 FS: U-Boot 1.1.3 (Jun 29 2006 - 16:38:55) BAS ver:1.00.07 U-Boot code: 00200000 ->...
  • Page 28 ### JFFS2 loading 'update/newramdisk.image' to 0x5000000 In this state, system will take two~three minutes to do system initialize, so please have patience with this procedure. BAS> Before you connect PC to DS-8124/DS-8124c system, you should configure Ethernet first. BAS>ip BAS/ip>? help...
  • Page 29 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 BAS/ip>set Set the management ip address and subnet mask set <ip|netmask> netmask . BAS/ip>set ip ixp0 192.168.0.220 Done BAS/ip>set netmask ixp0 255.255.255.0 BAS/ip>show ixp0 ip addr: 192.168.0.210 mac addr: 00:05:ca:00:42:11 gateway: 0.0.0.0 net mask: 255.255.255.0...
  • Page 30 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 seven groups: sys, adsl, switch, isolation, ip, staticstics, and config. User can type end to terminate this program, or to type test to enter the test program. BAS>help help Display command list Display command list <...
  • Page 31 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 date The system's current date timeserver The system's time server alarm The recorded system alarm exit Return to upper level BAS0/sys> Ex. type “help info” command, system will show the message about this argument of info. Like following figure, program will display the command of info and its arguments.
  • Page 32 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 BAS>end BAS comand line program ended ! Above description, we only tell user the method about group sys, and the methods of other groups like the same way. And we can type help to show the purpose of each group and its command.

  • Page 33: Troubleshooting

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 5. Troubleshooting Troubleshooting guide Trouble Possible cause Solution PWR indicator does Power outlet, power cord, • Check the power outlet by plugging in not light up after or internal power supply another device that is functioning Turning on the may be defective.

  • Page 34: Alarm Definition

    Alarm definition 1. Information about this Alarm Definition. The DS-8124 alarm system have two ways that to make a sound by external alarm out or LED signal on faceplate to indicate an error condition. In this document, we declare the alarm as follow format:...
  • Page 35 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Major GEMINAX Loss-of-power Major GEMINAX Loss-of-frame Major GEMINAX Loss-of-signal Major GEMINAX loss-of-margin Major GEMINAX Loss of Link Major GEMINAX No Cell Delineation Major GEMINAX Loss of Cell Delineation 15M FECS Major GEMINAX 15 minutes threshold error...
  • Page 36 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Loss of Signal Seconds 1D LOFS Major GEMINAX 1 Day threshold error Loss of Frame Seconds 1D LOLS Major GEMINAX 1 Day threshold error Loss of Link Seconds. 1D LPRS Major GEMINAX 1 Day threshold error Loss of Power Seconds.
  • Page 37 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 15M CV_P Major GEMINAX 15 minutes threshold error non pre-emptive packets with coding violation bearer channel threshold crossing. 15M CVP_P Major GEMINAX 15 minutes threshold error pre-emptive packets with coding violation bearer channel threshold crossing.

  • Page 38: Cable And Pin Assignment

    Pin Number Assignment Because the ports on the DS-8124/DS-8124c support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable.

  • Page 39: 1000Base-T Pin Assignments

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 MDI-X Assignment MDI Assignment Input Receive Data + Output Transmit Data + Input Receive Data - Output Transmit Data - Output Transmit Data + Input Receive Data + Output Transmit Data - Input Receive Data - Note: Auto-negotiation must be enabled for automatic MDI/MDI-X pinout configuration.

  • Page 40: Console Port Pin Assignments

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Pins Circuit Pins Circuit Pins Circuit Pins Circuit 1,26 1,Ring/Tip 7,32 7,Ring/Tip 13,38 13,Ring/Tip 19,44 19,Ring/Tip 2,27 2,Ring/Tip 8,33 8,Ring/Tip 14,39 14,Ring/Tip 20,45 20,Ring/Tip 3,28 3,Ring/Tip 9,34 9,Ring/Tip 15,40 15,Ring/Tip 21,46 21,Ring/Tip 4,29...
  • Page 41 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Figure 5-1. Connecting to the Punch-down Blocks DB-9 Port Pin Assignments EIA Circuit CCITT Signal Description Switch’s DB-9 PC DB-9 DTE Pin DTE Pin # RxD (Received Data) TxD (Transmitted Data) SGND (Signal Ground) Console Port to 9-Pin DTE Port on PC Switch’s 9-pin Serial Port...

  • Page 42: Related Documentation

    Aug 2006 release 1.1 DS-8124/DS-8124c Management guide Sept 2006 release 1.2 DS-8124/DS-8124c Management guide Oct 2006 release 1.3 DS-8124/DS-8124c Management guide Apr 2007 release 1.4 Application notes – random Please contact the CXR service representative for more information regarding to DS-8124/DS-8124c.

  • Page 43: Obtaining Technical Assistance

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 8. Obtaining Technical Assistance For this DS-8124/DS-8124c installation procedures, please contact CXR. Accessories for DS-8124/DS-8124c 1. A Bracket Mounting Kit It contains two brackets and four screws for attaching the brackets to the DSLAM 2.

  • Page 44: Specification

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 9. Specification Hardware Dimensions (WxDxH) : 440 x 320 x 44.4 mm Weight 5.2 Kg System : Power, System, Major and Minor alarm. ADSL port : link Uplink Port : TX link and FX link.

  • Page 45: Software Feature

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 ANSI T1.413 Issue 2 Line loop back and diagnostic Software Feature L2/L3 Functionality Switch capability : IEEE802.3x flow control, IEEE802.1d bridging. VLAN : IEEE802.1p/q VLAN (4094), stacked VLAN, Port-based and Tag-based. Multicasting : IGMP snooping, 250 groups, Dynamic&Static Configuration.

  • Page 46: Glossary

    DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 10. Glossary 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 UTP cable.
  • Page 47 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 method. Gigabit Ethernet A 1000 Mbps network communication system based on Ethernet and the CSMA/CD access method. Full-Duplex Transmission method that allows two network devices to transmit and receive concurrently, effectively doubling the bandwidth of that link.
  • Page 48 DS-8124/DS-8124c Installation Guide Oct 2006 Release 1.2 Equipment where outside telephone lines are terminated at a building or site. An acronym for Management Information Base. It is a set of database objects that contains information about the device. MPOE (Minimum or Main Point of Entry) The location in a building where cables from the telephone service provider are terminated.
