- Page 1 D M X W i r e l e s s D M X 5 1 2 T R A N S M I T T E R USER’S MANUAL...
- Page 2 DESCRIPTION OF THE PANELS SMA antenna connector Power input 5 Vdc 650 mA (included) Blue led : Slow blinking: Transmitter O O K K , no D D M M X X 5 5 1 1 2 2 signal. Switched on : Transmitter O O K K , D D M M X X 5 5 1 1 2 2 signal O O K K .. Red Button for change channel and pairing operation Standard DMX 512 signal INPUT with a 3/5-pole XLR connector.
- Page 3 Hold the button until the Wi D Pen Pro led starts blinking r-g-b alternately Remove power supply from WiDMX PRO Holding the red button, connect power supply and wait until the WiDMX PRO led starts fast blinking When the led stops fast blinking, the Wi D Pen Pro receiver is paired...
- Page 4 TRANSMITTER USE Always connect the provided power supply In the event of radio problem, press the red button until Wi DMX PRO led do a fast blinking (a new radio channel is set) Technical features: Frequency range: 2,4 GHz - 2,483 GHz (ISM) Number of channels: 20 Transmitter range: 500 meters/1640 feet open air Voltage/current: 5 Vdc / 650 mA...
