Summary of Contents for Phoenix MT107E-HD
- Page 1 USER MANUAL MT107E-HD Single Channel 16KHz Echo Canceling System www.phnxaudio.com info@phnxaudio.com...
- Page 2 MT107E-HD Single Channel 16KHz Echo Canceling System The MT107E-HD is a DSP based, single channel, echo cancellation system designed to remove noise picked up by microphones in standard to complex audio conferencing environments. The MT107E-HD utilizes your own microphone and loudspeakers to create a complete audio conferencing solution.
- Page 3 CONNECTIVITY: Microphone input is connected to "IN 2". Units are preset to line level with 6dB boost and phantom power off. Far-end input is connected to "IN 1". Connect your system speakers output into this jack. Units are preset to line level. *Note: Far-end input will be received through the USB channel if active.
- Page 4 HOW TO CONNECT - ANALOG CONNECTION (when USB is not available): "IN 1" Far-end Input: Connect system's loudspeaker output into this jack. Input level is defaulted as line level. "IN 2" Microphone Input: Connect your microphone into this jack. Input level is defaulted as line level.
- Page 5 HOW TO CONNECT - DIGITAL CONNECTION (when USB is available): "IN 1" Far-end Input: No connection needed. Received through USB channel. "IN 2" Microphone Input: Connect your microphone input into this jack. Input level is defaulted as line level. "OUT 1" Audio Output: Connect your amplified speaker (or amplifier) into this jack. "OUT 2"...
- Page 6 SDK. The SDK is a free utility, compatible with Windows, available to download on our website. The SDK enables the parameters of the MT107E-HD to be controlled, modified, and stored onto the unit. The SDK communicates with the MT107E-HD through a standard USB connection.
- Page 7 The following warranty statement is effective for all Phoenix Audio Technologies’ products as of October 1st, 2007: Phoenix Audio Technologies warrants that this product is free of defects in both materials and workmanship. Should any part of this product be defective, the Manufacturer agrees, at its option, to repair or replace with a like new replacement any defective part(s) free of charge (except transportation charges) for a period of two years for all products.
