Rambler 15 & 40
Owner's Manual
DC Developments
Musical Equipment Design & Development
Unit 13 Rosshill Industrial Park, Southend-on-Sea, Essex SS2 5PZ England
Tel/Fax +44 (0)1702 610964
www.dc-developments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rambler 15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cornell Rambler 15

Summary of Contents for Cornell Rambler 15

  • Page 1 Rambler 15 & 40 Owner’s Manual DC Developments Musical Equipment Design & Development Unit 13 Rosshill Industrial Park, Southend-on-Sea, Essex SS2 5PZ England Tel/Fax +44 (0)1702 610964 www.dc-developments.com...

  • Page 2: Construction And Design

    This unit must be earthed. Use the correct mains cord. If you require any further information regarding the Rambler amplifier, or any other CORNELL products, please do not hesitate in contacting us (details on front page). © 1995-2007 CORNELL Musical Equipment Design & Development...
  • Page 3 Introduction Thank you for choosing a Cornell Rambler 15 / Rambler 40 amplifier. Your amplifier employs valve technology, and is hand built to the highest standards. Only top quality components are used in our amplifiers, so that you can enjoy years of trouble-free use.

  • Page 4: Technical Design

    Cornell ‘Cream Box’ Part of the Cornell Rambler 15 sound is due to our little ‘cream box’. We can’t tell you what’s inside - it’s our little secret. We think it makes our Rambler 15 sound rather special.

  • Page 5: Mains Fuse

    Controls Input - Hi & Lo Both inputs offer high impedance connections for instruments. The Hi input provides 6dB more gain than the Lo input. Volume - Adjusts the overall volume of the amplifier. Bass - Adjusts the amount of low frequency boost. Treble - Adjusts the amount of high frequency boost.

  • Page 6: Specifications

    Specifications POWER Rambler 15 ....... 230 Volt AC, 50Hz, 120 Watts Rambler 40 ....... 230 Volt AC, 50Hz, 280 Watts FUSES Rambler 15 ......500mA, 240v Slo-blow 250mA Slo-blow HT Fuse Rambler 40 ......1Amp, 240v Slo-blow 500mA Slo-blow HT Fuse INPUT IMPEDANCE .......

  • Page 7: Valve Replacement

    Your Cornell Rambler amplifier has eight valves: three pre-amp valves (12AX7/ ECC83), two 12AT7/ECC81 valves for the reverb, two power valves (EL84 for the Rambler 15, and EL34 or 6L6 for the Rambler 40), and a rectifier valve (GZ34). Warning...
