AMCON AUTOMATIC
CHART PROJECTOR
USER'S MANUAL
EQ-6002
1-800-255-6161• Fax 1-800-397-0013
www.amconlabs.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EQ-6002 and is the answer not in the manual?

Questions and answers

Related Manuals for AMCON EQ-6002

Summary of Contents for AMCON EQ-6002

  • Page 1 AMCON AUTOMATIC CHART PROJECTOR USER’S MANUAL EQ-6002 1-800-255-6161• Fax 1-800-397-0013 www.amconlabs.com...

  • Page 2: Table Of Contents

    Disclaimer......................2 1. Introduction...................... 3 2. Safety Instructions..................3 3. Charts and Specifications................4 4. Parts of the Instrument................... 6 4.1 Projector Parts..................6 4.2 Remote Control Parts................. 6 5. Operating Procedures ..................7 5.1 Preparation ..................7 5.2 Operation of the Remote Control.........

  • Page 3: Disclaimer

    Further, Amcon, The Eyecare Supply Center reserves the right to revise this publication and to make changes from time to time in the contents hereof without...

  • Page 4: Introduction

    Thank you for purchasing the Amcon Automatic Chart Projector. Please read this instruction manual and keep it in a convenient location for future reference. The remote controlled Amcon Automatic Chart Projector is used to test visual acuity. The Amcon Automatic Chart Projector provides operational convenience in a high quality instrument.

  • Page 5: Charts And Specifications

    Automatic Chart Projector - EQ-6002 ________________________________________________________________ 3. Charts and Specifications Letter Charts: Tumbling E Charts: Number Charts: Picture Charts: Worth Four Dot Chart: Astigmatic Chart: Red / Green Charts:...
  • Page 6 Automatic Chart Projector - EQ-6002 ________________________________________________________________ Binocular Vision Testing Charts: Refraction distance 5 ft – 20 ft Projection distance 5 ft – 20 ft Projection magnification 30X (at 20 ft refraction) Number of charts Chart changeover 1 frame / 0.3 sec.

  • Page 7: Parts Of The Instrument

    Automatic Chart Projector - EQ-6002 ________________________________________________________________ 4. Parts of the Instrument 4.1 Projector Parts 1) Top Cover 2) Remote Sensor 3) Front Panel 4) Lamp Cover 5) Barrel Screw 6) Projection Window 7) Base 8) Power Switch 9) Power Socket 4.2 Remote Control Parts...

  • Page 8: Operating Procedures

    Automatic Chart Projector - EQ-6002 ________________________________________________________________ 5. Operating Procedures Caution: Do not tilt the projector or place in an unstable place. The projector may topple over, drop or cause injury. Warning: Connect the power plug to a properly grounded three-prong AC outlet.

  • Page 9: Using The Program Function

    Automatic Chart Projector - EQ-6002 ________________________________________________________________ 5.3 Using the Program Function Accessing the Programming Mode a) Turn on the power switch. The projector goes into initialization state. b) Press the “RESET” button on the remote control. c) Press the “R and G filter” button on the remote control.

  • Page 10: Maintenance And Care

    If the bulb is touched by accident, wipe the fingerprint off with alcohol. Replacement bulbs are available from Amcon Product number: RQ-6200. Match the protruded part of the lamp attaching area with the lamp flange notch and tighten with the lamp attaching screw to secure the lamp.

  • Page 11: Changing The Channel Setting Of The Remote Control

    Automatic Chart Projector - EQ-6002 ________________________________________________________________ Turn the power switch off and disconnect the power supply plug. The fuse holder is located just below the power supply socket. Pull on the fuse holder to remove it. The fuse will be removed together with the holder. Remove the blown fuses and insert the new fuses on the cap of the fuse holder and install it as before.

  • Page 12: Troubleshooting

    Automatic Chart Projector - EQ-6002 ________________________________________________________________ 7. Troubleshooting Warning: Do not break down, modify or repair the equipment. Doing so can cause electric shock. Request a repair from your dealer. Check the situations covered in the following table for the problem you are experiencing. If your situation is not covered or if the recommended action does not solve the problem, contact your dealer for further support.
