Summary of Contents for Cocoon AV6185
- Page 1 HD CAMERA PEN RECORD HIGH DEFINITION VIDEOS Model Number: AV6185 INSTRUCTION MANUAL...
-
Page 2: Safety Warnings & Cautions
Safety Warnings & Cautions - Do not expose or immerse the Camera Pen in liquid - Keep away from heat sources such as heaters and ovens - The Camera Pen can be unscrewed to access the USB port. Other than the Ink cartridge there are no other user-serviceable parts inside. -
Page 3: Introduction/ Technical Specifications
Introduction Congratulations on the purchase of your Cocoon Camera Pen. This product is designed to record video and photos and provide many years of reliable use. Please read and follow these instructions carefully. If you experience any difficulties setting up or using this product, please see back... -
Page 4: Product Overview
Product Overview under clip Power / Record Button Record / Standby LED Camera Lens Reset Button Microphone Pen Tip – twist for pen USB Plug 30cm USB Extension Cable Video / Photo Switch 10. 2 x Ink Refills After Sales Support Telephone: 1300 663 907 Internet:... -
Page 5: Table Of Contents
Contents Safety Warnings & Cautions Introduction/ Technical Specifications Product Overview 1. Charging the Camera Pen 2. Turning the Camera Pen ON or OFF 3. Video Mode 4. Photo Mode 5. Transferring Videos and Photos to Your Computer 6. Deleting Files 7. -
Page 6: Charging The Camera Pen
1. Charging the Camera Pen Unscrew to expose USB Plug the USB end of the pen into a USB port on your computer. If required, use the included USB Extension Cable USB Extension Cable The orange light will flash indicating it is charging Once the orange light stops flashing and stays on the Camera Pen has finished charging. -
Page 7: Video Mode
3. Video Mode Video mode will record video with sound, and save it to the internal memory of your Camera Pen. Unscrew the Camera Pen and set the switch located on the USB end of the pen to “V” video mode “V”... - Page 8 3. Video Mode (cont.) Push and release the top button to stop recording. The light will turn to a solid orange to indicate standby mode To capture a second video, push and release the top button when in standby mode. The light will turn solid blue, to indicate that video is currently recording.
-
Page 9: Photo Mode
4. Photo Mode Photo mode will capture still images and save them to the internal memory of your Camera Pen. Unscrew the Camera Pen and set the switch to “P” photo mode “P” or Photo switch Hold the top button for 3 seconds The orange and blue lights will turn on The light will then flash orange once, indicating you are in photo mode. -
Page 10: Transferring Videos And Photos To Your Computer
5. Transferring Videos and Photos to Your Computer Unscrew the Cocoon Camera Pen Plug into a USB port on your computer. If required, use the included USB Extension Cable Your computer will automatically detect the Camera Pen as a removable drive - like a USB memory stick. -
Page 11: Setting The Time
7. Setting the Time Setting the time allows photos and videos to appear with the correct capture time and date. The date and time can be set using the WriteTime wizard (Windows only) or by editing time.txt on the Camera Pen internal memory. Setting the time using the WriteTime wizard (Windows only) Connect the Camera Pen to your computer Navigate to the camera pen drive as per the steps in section 5. - Page 12 7. Setting the Time (cont.) Click OK The file will automatically save and sync the computer time to a file called time.txt Tip: If you delete the WriteTime application by accident. You can download the file again to your Camera Pen from the Winplus website at www.winplus.com.au Setting the time manually (Mac or Windows) Connect Camera Pen to your computer.
-
Page 13: Using The Camera Pen As A Webcam
8. Using the Camera Pen as a Webcam Connect the Camera Pen to the USB extension cable Plug the extension cable into a USB port on your computer Once the Camera Pen has entered charging mode press and release the button to enter webcam mode The first time webcam mode is activated the operating system will automatically detect and install the correct drivers’... -
Page 14: Resetting The Camera Pen To Factory Settings
9. Resetting the Camera Pen to Factory Settings Turn on the Camera Pen into standby mode Insert a small object such as a pin into the reset hole to push the hidden button If the button is pushed correctly the LED lights will immediately turn off Reset hole Note: Videos and photos will not be deleted when resetting the Camera Pen. -
Page 15: Replacing The Ink Cartridge
10. Replacing the Ink Cartridge Unscrew the Camera Pen Using a Phillips head screwdriver, unscrew the ink cartridge Insert the new ink cartridge and screw in After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au... -
Page 16: Troubleshooting
11. Troubleshooting PROBLEM SOLUTION My Camera Pen is not - Make sure the Camera Pen is charged recording video - Download all videos and photos from the Camera Pen and then delete them to free space - Unscrew and set the switch to V for video mode The time is not correct 1. -
Page 17: Support & Warranty Details
This product is warranted against defects for a period of One year If the product is faulty, Winplus will repair or replace the product (at its discretion) at no cost to you provided the Cocoon HD Camera Pen has been used in accordance with instructions provided. The benefits under our Warranty are in addition to other rights and remedies under consumer law in relation to these goods. - Page 18 Notes:...
- Page 19 Notes:...
