FETTO Deluxe Owner's Manual

FETTO Deluxe
Owner's Manual
Congratulations on your purchase of FETTO Deluxe, the distortion pedal which works well with both guitars
and bass guitars. With FETTO Deluxe you will get musical, shimmering harmonics regardless of volume with a
minimal coloration of your guitar and ampli er.
It's highly recommended to read this manual to get the best use and joy of FETTO Deluxe.
External controls:
Core: Tone/Treble:
A ects the character, Passive tone control. Start around
the feel, the core. 11 o' clock. Counter clockwise
Start at 12 o' clock and gives a treble cut.
experiment.
The function of the Core
control equates to the
di erence in feel between
low and high wattage amps,
where the low wattage amp
(minimum) distorts more
quickly and the high wattage
amp (maximum) has more
headroom.
Volume:
Output level. Start at
10-12 o' clock.
OUT:
Connect your
ampli er here.
Himmelstrutz Elektro Art, Sweden. www.himmelstrutz.com
Doc: 6403002_om_001- (#001–)
GIMME:
ON/OFF push switch*. True
mechanical (not electronic)
bypass. ON is indicated by a
magical, blue LED.
* The push switches in FETTO Deluxe is
not as sti as the ones you're probably
used to. So now you can play barefoot
without hurting yourself.
Mid:
Toggle switch which gives more
or less mid. Try both positions
to nd out what's best suited for
your equipment.
MORE:
A boost/solo push switch* which gives
MORE of FETTO Deluxe. ON is indicated by
a sunny, yellow, LED. The amount of Drive/
Volume for this switch is adjustable inside
the box (explained on next page).
NB: MORE can only be activated when the pedal is ON
(blue LED on). It's not a separate e ect.
Lowdrive:
Bass/overdrive character. Start
at 12 o' clock and experiment.
The Lowdrive knob controls the
"oomph" of the pedal, similar to the
di erence between a 1x12 cabinet
(minimum) and a 4x12 cabinet
(maximum).
Drive:
Drive/distortion control.
Start at 10-12 o' clock.
Clockwise gives more.
9V DC
External DC adapter.
Standard 2,1 mm barrel
jack, 9 volt regulated DC
with center-pin negative.
(BOSS standard). NEVER
power FETTO Deluxe with
more than 9 V DC!
The Himmelstrutz pedals are
designed to be used with straight
power cable plugs. Right angle plugs
may not make a secure connection
and are not recommended.
IN:
Connect your guitar or bass
guitar here.
1:2
